TDFZ 170229, TDFZ 170311
Vishay Draloric
Pot Capacitors for Coupling Purposes
TDFZ 170229 40 KV
P
ø 169
(6.654 DIA)
ø 75
(2.953 DIA)
TDFZ 170311 32 KV
P
ø 169
(6.654 DIA)
2
(0.08)
ø 75
(2.953 DIA)
100
(3.937)
5/16 - 18 UNC*
Thread
5/16 - 18 UNC*
Thread
100
(3.937)
22
(0.866)
2
(0.08)
229
±
4
(9.016
±
0.157)
ø 120
(4.724 DIA)
ø 120
(4.724 DIA)
5/16 - 18 UNC*
Thread
5/16 - 18 UNC*
Thread
22
(0.866)
ø 65
(2.559 DIA)
ø 65
(2.559 DIA)
• Dimensions in millimeters (inches)
* Metric threads available on request
MODEL:
The ceramic capacitor element is housed in a rugged silver
plated copper can. This construction allows additional “Belt-
contacting” of the outer electrode terminal over the copper
can shaft.
The results are short conduction paths with low impedance
and low inductance as well as protection of the outer noble
metal electrode.
MATERIAL:
Capacitor elements made from Class 1 ceramic dielectric
with noble metal electrodes.
Connection terminals of the inner electrode and outer
electrode’s covering can made from copper/brass, silver
plated.
MARKING:
Type designator, Capacitance value and tolerance, Rated
voltage (peak value), Production date code, Ceramic
material code, DRALORIC Logo, Serial number.
FINISH:
Insulating rim protected with silicone rubber.
ORDERING INFORMATION
TDFZ 170311
MODEL
32 KVp
RATED VOLTAGE
4000 pF
CAPACITANCE VALUE
± 10 %
TOLERANCE
R
85
CERAMIC
www.vishay.com
1
For technical questions contact: powcap@vishay.com
Document Number: 22127
Revision: 24-Jan-02
311
±
4
(12.244
±
0.157)
