5962F9764001VXC datasheet, PDF

Datasheet> All Categories > logic> logic> 5962F9764001VXC

5962F9764001VXC: DescriptionAC SERIES, 8 LINE TO 1 LINE MULTIPLEXER, COMPLEMENTARY OUTPUT, CDFP16; Categorylogic logic; File Size51KB，2 Pages; ManufacturerIntersil ( Renesas ); Websitehttp://www.intersil.com/cda/home/

Download Datasheet Parametric Compare View All

5962F9764001VXC Overview

AC SERIES, 8 LINE TO 1 LINE MULTIPLEXER, COMPLEMENTARY OUTPUT, CDFP16

5962F9764001VXC Parametric

Parameter Name	Attribute value
Parts packaging code	DFP
package instruction	DFP,
Contacts	16
Reach Compliance Code	unknown
series	AC
JESD-30 code	R-CDFP-F16
JESD-609 code	e4
Logic integrated circuit type	MULTIPLEXER
Number of functions	1
Number of entries	8
Output times	1
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output polarity	COMPLEMENTARY
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Package shape	RECTANGULAR
Package form	FLATPACK
propagation delay (tpd)	20 ns
Certification status	Not Qualified
Filter level	MIL-STD-883 Class V
Maximum seat height	2.92 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	GOLD
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
total dose	300k Rad(Si) V
width	6.73 mm

Preview

Download Datasheet

View All

ACS151MS

November 1997

Radiation Hardened 8-Input Multiplexer

Description

The Radiation Hardened ACS151MS is an 8-Channel Multi-

plexer having three binary control inputs and an active low

enable input. The three binary input signals select the input

from 1 of 8 channels.

Complementary data outputs are provided for ease of system

design. If the enable input is high, the input signals are disre-

garded, the Y output is set high and the Y output is set low. All

inputs and outputs are buffered and are designed for balanced

propagation delay and transition times.

The ACS151MS is fabricated on a CMOS Silicon on Sapphire

(SOS) process, which provides an immunity to Single Event

Latch-up and the capability of highly reliable performance in

any radiation environment. These devices offer signiﬁcant

power reduction and faster performance when compared to

ALSTTL types.

Speciﬁcations for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed below must be used when ordering.

Detailed Electrical Speciﬁcations for the ACS151 are

contained in SMD 5962-97640. A “hot-link” is provided

on our homepage with instructions for downloading.

http://www.intersil.com/data/sm/index.htm

Features

• QML Qualiﬁed Per MIL-PRF-38535 Requirements

• 1.25Micron Radiation Hardened SOS CMOS

• Radiation Environment

- Latch-up Free Under any Conditions

- Total Dose . . . . . . . . . . . . . . . . . . . . . . 3 x 10

RAD(Si)

- SEU Immunity . . . . . . . . . . . <1 x 10

-10

Errors/Bit/Day

- SEU LET Threshold . . . . . . . . . . . >100MeV/(mg/cm

)

• Input Logic Levels . . .V

= (0.3)(V

), V

= (0.7)(V

)

• Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . .

±8mA

• Quiescent Supply Current. . . . . . . . . . . . . . . . . . .400µA

• Propagation Delay

- Enable to Output . . . . . . . . . . . . . . . . . . . . . . . . . 12ns

- Input or Address to Output . . . . . . . . . . . . . . . . . 20ns

Applications

• Sensor Input Selection

• Data Routing

• High Frequency Switching

Ordering Information

SMD PART NUMBER

5962F9764001VEC

N/A

5962F9764001VXC

N/A

INTERSIL PART NUMBER

ACS151DMSR-02

ACS151D/Sample-02

ACS151KMSR-02

ACS151K/Sample-02

ACS151HMSR-02

TEMP. RANGE (

-55 to 125

PACKAGE

16 Ld SBDIP

16 Ld Flatpack

Die

CASE OUTLINE

CDIP2-T16

CDFP4-F16

N/A

Pinouts

ACS151 (SBDIP)

TOP VIEW

Y 5

Y 6

E 7

GND 8

16 V

15 I

14 I

13 I

12 I

11 S

10 S

9 S

ACS151 (FLATPACK)

TOP VIEW

GND

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

File Number

4430
