DR366-1 Series Radial Leaded Shielded Inductors
Features
Height: 9.8mm Max
Inductance Range: 1µH – 1.5mH
Non-RoHS Versions are Available (Note 4)
Meets UL 94V-0
OPERATING TEMPERATURE -20°C to +80°C
Q Test
Freq.
7.96MHz
7.96MHz
7.96MHz
7.96MHz
7.96MHz
7.96MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
252kHz
252kHz
ELECTRICAL SPECIFICATIONS AT 25°C
Part Number
Inductance
(µH) @1kHz
1
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
Q Min.
SRF (MHz)
Ref.
70
56
45
36
29
24
19
15
12
9.4
7.6
6.2
5.0
4.0
3.2
2.5
2.0
1.7
1.3
1.3
DCR (Ω)
Max.
0.006
0.008
0.011
0.018
0.022
0.028
0.043
0.056
0.086
0.14
0.17
0.28
0.33
0.56
0.72
1.1
1.7
2.3
4.3
5.0
Rated
Current (A)
Max. I sat
6.6
5.4
4.0
3.6
3.1
2.5
2.1
1.7
1.4
1.1
0.96
0.79
0.66
0.53
0.44
0.36
0.30
0.25
0.20
0.17
Rated
Current (A)
Max. I rms
5.0
4.3
3.7
2.9
2.6
2.3
1.9
1.6
1.3
1.0
0.94
0.73
0.67
0.52
0.46
0.37
0.30
0.26
0.19
0.16
DR366-1-102
DR366-1-152
DR366-1-222
DR366-1-332
DR366-1-472
DR366-1-682
DR366-1-103
DR366-1-153
DR366-1-223
DR366-1-333
DR366-1-473
DR366-1-683
DR366-1-104
DR366-1-154
DR366-1-224
DR366-1-334
DR366-1-474
DR366-1-684
DR366-1-105
DR366-1-155
10
10
10
10
10
10
20
20
20
20
20
20
20
20
20
20
20
20
70
50
MECHANICAL OUTLINE
1
XXX
.196
5,0
Ø .025
0,65
1
2
.385 MAX.
9,8
.236 MIN.
6,0
2
Ø .318 MAX.
8,1
SCHEMATIC
NOTES:
1.) All dimensions are in inches/mm
2.) Tolerance: .012/0.3
3.) DR366-1-102 to DR366-1-682 inductance tolerance is ±20%, DR366-1-103 to DR366-1-155
inductance tolerance is ±10%
4.) For non-RoHs parts, replace DR prefix with 42- (e.G. DR366-1-472 becomes 42-366-1-472)
5.) Terminal finish is compliant to RoHs requirements
6.) Isat is the current level when the inductance drops 20% from its initial value
7.) Irms is the current level when the part reaches a temperature rise of 25°C
