L-53ED

Description
Single Color LED, Orange, Diffused, T-1 3/4, 5mm,
CategoryLED optoelectronic/LED    photoelectric
File Size826KB，6 Pages
ManufacturerKingbright
Websitehttp://www.us.kingbright.com
Environmental Compliance
Download Datasheet Parametric Compare View All

L-53ED Overview

Single Color LED, Orange, Diffused, T-1 3/4, 5mm,

L-53ED Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerKingbright
Reach Compliance Codecompli
ECCN codeEAR99
Other featuresHIGH RELIABILITY
colorORANGE
color@wavelengthAmbe
ConfigurationSINGLE
Maximum forward current0.03 A
Maximum forward voltage2.8 V
Lens typeDIFFUSED
minimum luminous intensity140 cd
Nominal luminous intensity25.0 mcd
Installation featuresRADIAL MOUNT
Number of functions1
Number of terminals2
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Optoelectronic device typesSINGLE COLOR LED
total height8.6 mm
method of packingTAPE AND REEL
peak wavelength627 nm
shapeROUND
size5 mm
surface mountNO
T codeT-1 3/4
Terminal pitch2.54 mm
perspective60 deg
Base Number Matches1

Preview

Download Datasheet
Kingbright
Features
®
T-1 3/4 (5mm) SOLID STATE LAMPS
L-53H BRIGHT RED
L-53E ORANGE
L-53I HIGH EFFICIENCY RED
L-53G GREEN
L-53N PURE ORANGE
L-53Y YELLOW
L-53PG PURE GREEN
L-53SRSG SUPER BRIGHT RED/ SUPER BRIGHT GREEN
Package Dimensions
l
LOW POWER CONSUMPTION.
l
HIGH INTENSITY.
l
VERSATILE MOUNTING ON P.C. BOARD OR PANEL.
l
LOW CURRENT REQUIREMENTS.
l
POPULAR T-1 3/4 DIAMETER, 1" LEAD LENGTH.
l
RELIABLE AND RUGGED
.
l
SUPER BRIGHT RED AND SUPER GREEN BI-COLOR
VERSION IS AVAILABLE.
l
AVAILABLE ON TAPE AND REEL.
l
DIFFUSED, TRANSPARENT AND WATER CLEAR TYPE.
Description
The Bright Red source color devices are made with Gallium
Phosphide Red Light Emitting Diode.
The Green and Super Bright Green source color devices are
made with Gallium Phosphide Green Light Emitting Diode.
The High Efficiency Red and Orange source color devices are
made with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
The Yellow source color devices are made with Gallium Arsenide
Phosphide on Gallium Phosphide Yellow Light Emitting Diode.
The Super Bright Red source color devices are made with Gallium
Aluminum Arsenide Red Light Emitting Diode.
The Pure Orange source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Pure Orange Light
Emitting Diode.
The Pure Green source color devices are made with Gallium
Phosphide Pure Green Light Emitting D iode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±
0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
Selection Guide
Part No.
L-53HD
L-53ID
L-53IT
L-53EC
L-53ED
L-53GD
L-53GT
L-53GC
L-53YD
L-53YT
L-53YC
L-53ND
L-53NT
L-53NC
L-53PGD
L-53PGT
L-53PGC
L-53SRSGW
BRIGHT RED (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
ORANGE (GaAsP/GaP)
GREEN (GaP)
Dice
Lens Type
RED DIFFUSED
RED DIFFUSED
RED TRANSPARENT
WATER CLEAR
ORANGE DIFFUSED
GREEN DIFFUSED
GREEN TRANSPARENT
WATER CLEAR
YELLOW DIFFUSED
YELLOW TRANSPARENT
WATER CLEAR
ORANGE DIFFUSED
ORANGE TRANSPARENT
WATER CLEAR
GREEN DIFFUSED
GREEN TRANSPARENT
WATER CLEAR
WHITE DIFFUSED
Iv (mcd)
@ 10 mA
Min.
Max.
2
12.5
50
50
12.5
5
20
20
5
20
20
12.5
50
50
2
5
5
*80
*12.5
5
80
200
200
80
32
150
150
32
80
80
80
200
200
8
32
32
*200
*40
Viewing
Angle
2θ1/2
60°
60°
30°
30°
60°
60°
30°
30°
60°
30°
30°
60°
30°
30°
60°
30°
30°
50°
YELLOW (GaAsP/GaP)
PURE ORANGE (GaAsP/GaP)
PURE GREEN (GaP)
SUPER BRIGHT RED (GaAlAs)
SUPER BRIGHT GREEN (GaP)
Notes:
1.
θ
1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
2-L53-1
