SMD
Low Power LED
45-21S/XK2C-HXXXXXXXXXXZ3/2T
Features
‧PLCC-2
package
‧
Top view white LED
˙High
luminous intensity output
˙Wide
viewing angle
˙Pb-free
˙RoHS
compliant
Description
The Everlight 45-21S package has high efficacy, high CRI, low power consumption, wide viewing angle and a
compact form factor. These features make this package an ideal LED for all lighting applications.
Applications
‧
General lighting
‧
Decorative and Entertainment Lighting
‧
Indicators
‧
Illumination
‧
Switch lights
1
Revision
Copyright ©
:1
LifecyclePhase:
2013, Everlight All Rights Reserved. Release Date 23.Jul.2013. Issue No:V1
Release
Issue No:DSE-0009300
Date:2013-08-14 13:47:49.0
www.everlight.com
Expired Period: Forever
DATASHEET
SMD
Low Power LED
45-21S/XK2C-HXXXXXXXXXXZ3/2T
Product Number Explanation
45–21S / X K 2 C – H XX XX XX XX XX / 2T
Bin Group of Forward Voltage
Bin Group of Max. Luminous
Flux
Bin Group of Min. Luminous
Flux
Max. Color temperature
Min. Color temperature
Bin Code of Color Rendering Index
Table of Color Rendering Index
Symbol
M
N
L
Q
K
H
Note:
Tolerance of Color Rendering Index: ±2
Description
CRI(Min.) : 60
CRI(Min.) : 65
CRI(Min.) : 70
CRI(Min.) : 75
CRI(Min.) : 80
CRI(Min.) : 90
Example:
45-21S/KK2C-H2727B7L1B2Z3/2T
CRI
CCT
Flux
V
F
I
F
80(Min.)
2700K
8.5~11lm
2.9~3.6V
30mA
2
Revision
Copyright ©
:1
LifecyclePhase:
2013, Everlight All Rights Reserved. Release Date : 23.Jul.2013. Issue No:V1
Release
Issue No:DSE-0009300
Date:2013-08-14 13:47:49.0
www.everlight.com
Expired Period: Forever
DATASHEET
SMD
Low Power LED
45-21S/XK2C-HXXXXXXXXXXZ3/2T
Mass Production List for CRI>80
Product
45-21S/KK2C-H2727B7L1B2Z3/2T
45-21S/KK2C-H3030B8L2B2Z3/2T
45-21S/KK2C-H3535B8L2B2Z3/2T
45-21S/KK2C-H4040B9L3B2Z3/2T
45-21S/KK2C-H5050B9L3B2Z3/2T
45-21S/KK2C-H5757B9L3B2Z3/2T
45-21S/KK2C-H6060B9L3B2Z3/2T
45-21S/KK2C-H6565B9L3B2Z3/2T
Note:
1. Tolerance of Color Rendering Index: ±2
2. Tolerance of Luminous flux: ±11%.
CRI
Min.
(1)
80
80
80
80
80
80
80
80
CCT(K)
2700K
3000K
3500K
4000K
5000K
5700K
6000K
6500K
Φ(lm)
Min.
(2)
8.5
9.0
9.0
9.5
9.5
9.5
9.5
9.5
Φ(lm)
Max.
(2)
11
12
12
13
13
13
13
13
3
Revision
Copyright ©
:1
LifecyclePhase:
2013, Everlight All Rights Reserved. Release Date : 23.Jul.2013. Issue No:V1
Release
Issue No:DSE-0009300
Date:2013-08-14 13:47:49.0
www.everlight.com
Expired Period: Forever
DATASHEET
SMD
Low Power LED
45-21S/XK2C-HXXXXXXXXXXZ3/2T
Device Selection Guide
Chip
Materials
InGaN
Emitted Color
Cool White
Netural White
Warm White
Water Clear
Resin Color
Absolute Maximum Ratings (T
Soldering
=25℃)
Parameter
Forward Current
Peak Forward Current (Duty 1/10 @10ms)
Power Dissipation
Operating Temperature
Storage Temperature
Thermal Resistance (Junction / Soldering point)
Junction Temperature
Soldering Temperature
Symbol
I
F
I
FP
P
d
T
opr
T
stg
R
th J-S
T
j
T
sol
Rating
30
100
110
-40 ~ +85
-40 ~ +100
50
125
Hand Soldering : 350
℃
for 3 sec.
Unit
mA
mA
mW
℃
℃
℃/W
℃
Reflow Soldering : 260
℃
for 10 sec.
Note:
The products are sensitive to static electricity and must be carefully taken when handling products
Electro-Optical Characteristics (T
Soldering
=25℃)
Parameter
Luminous Flux
(1)
Forward Voltage
(2)
Color Rendering Index
(3)
Viewing Angle
Reverse Current
Symbol
Min.
8.5
2.9
80
-----
-----
Typ.
-----
-----
-----
120
-----
Max.
13
3.6
-----
-----
50
deg
Unit
lm
V
Condition
I
F
=30mA
I
F
=30mA
I
F
=30mA
I
F
=30mA
V
R
=5V
Φ
V
F
Ra
2θ
1/2
I
R
Notes:
1. Tolerance of Luminous flux: ±11%.
2. Tolerance of Forward Voltage : ±0.1V.
3. Tolerance of Color Rendering Index: ±2
4
Revision
Copyright ©
:1
LifecyclePhase:
2013, Everlight All Rights Reserved. Release Date : 23.Jul.2013. Issue No:V1
Release
Issue No:DSE-0009300
Date:2013-08-14 13:47:49.0
www.everlight.com
Expired Period: Forever
DATASHEET
SMD
Low Power LED
45-21S/XK2C-HXXXXXXXXXXZ3/2T
Bin Range of Luminous intensity
Bin Code
B7
B8
B9
L1
L2
L3
Note:
Tolerance of Luminous flux: ±11%.
Min.
8.5
9.0
9.5
10
11
12
Max.
9.0
9.5
10
11
12
13
Unit
Condition
lm
I
F
=30mA
Bin Range of Forward Voltage
Group
Bin Code
36
37
38
B2
39
40
41
42
Note:
Tolerance of Forward Voltage: ±0.1V.
Min.
2.9
3.0
3.1
3.2
3.3
3.4
3.5
Max.
3.0
3.1
3.2
3.3
3.4
3.5
3.6
Unit
Condition
V
I
F
=30mA
5
Revision
Copyright ©
:1
LifecyclePhase:
2013, Everlight All Rights Reserved. Release Date : 23.Jul.2013. Issue No:V1
Release
Issue No:DSE-0009300
Date:2013-08-14 13:47:49.0
www.everlight.com
Expired Period: Forever
