revision for dwg #
1PB-2PLBxLB-yyy
rev
-
ch.no.
-
description
original design
date
11/2/2007
revised by
Philipp E.
15 mm
[.6 in]
* = Pilot Light is supplied with mounting bracket, bulb holder and LED (ITEM 1,2,3,4 and 5)
ITEM DESCRIPTION
1*
yyy
=
Voltage
012
=
12V AC/DC
024
=
24V AC/DC
048
=
48V AC/DC
110
=
110V AC/DC
230
=
230V AC
230D
=
230V DC
R
22 mm LED Pilot Light
max. 6 mm
[.25 in]
40.4 mm
[1.6 in]
unless otherwise specified:
all dimensions are in millimeters
third angle projection
tolerance
XX
XX.X
XX.XX
ALL
2*
3*
4*
5*
6
titel
Mounting Bracket
LED Bulb
Mounting Bracket Screws
Blub Holder
Panel
CAT. NO.
2PLB1LB-yyy
2PLB3LB-yyy
2PLB4LB-yyy
2PLB5LB-yyy
2PLB6LB-yyy
2PLB7LB-yyy
2PLB8LB-yyy
2BRK
MCB9xyyy
incl. in 2BRK
2LHB
-
COLOR
White
Green
Red
Amber
Blue
Clear
Yellow
-
-
-
-
-
MIN. QTY. MAX. QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
-
-
This Drawing is the property of
=
=
=
=
±
0.5 mm
±
0.2 mm
−
mm
±
1 mm
M
E
T
R
I
C
35 Royal Road
Flemington, NJ 08822-6000
(908) 806-9400
Fax (908) 806-9490
and is a confidential
disclosurelent without
consideration other than the
borrower’s agreement that it
shall not be reproduced,
copied, lent or disposed of
directly or indirectly nor
used for any purpose other
than that for which it is
specifically furnished.
22 mm LED Metal Pilot Light 2PLBx-LB-yyy (x=color. yyy=voltage)
11/2/2007
11/2/2007
11/2/2007
drawn by:
Philipp Ernstberger
checked by:
Laszlo Gyorgypal
released by:
Laszlo Gyorgypal
drawing no.:
1PB-2PLBxLB-yyy
29 mm
[1.2 in]
rev.:
-
scale:
-
sheet:
1
of:
1
