Series AM1D-RZ
1 Watt | DC-DC Converter
FEATURES:
•
•
•
•
RoHS compliant
High efficiency up to 89%
Low profile plastic package
7 pin SIP package
•
•
•
•
Operating temperature -40
o
C to + 85
o
C
Short circuit protection
Pin compatible with multiple manufacturers
Input / Output Isolation
1000 and 3000VDC
Models
Single output
Model
AM1D-0505S-RZ
AM1D-0509S-RZ
AM1D-0512S-RZ
AM1D-0515S-RZ
AM1D-1205S-RZ
AM1D-1209S-RZ
AM1D-1212S-RZ
AM1D-1215S-RZ
AM1D-1505S-RZ
AM1D-1509S-RZ
AM1D-1512S-RZ
AM1D-1515S-RZ
AM1D-2405S-RZ
AM1D-2409S-RZ
AM1D-2412S-RZ
AM1D-2415S-RZ
AM1D-4805S-RZ
AM1D-4809S-RZ
AM1D-4812S-RZ
AM1D-4815S-RZ
AM1D-0505SH30-RZ
AM1D-0509SH30-RZ
AM1D-0512SH30-RZ
AM1D-0515SH30-RZ
AM1D-1205SH30-RZ
AM1D-1209SH30-RZ
AM1D-1212SH30-RZ
AM1D-1215SH30-RZ
AM1D-1505SH30-RZ
AM1D-1509SH30-RZ
AM1D-1512SH30-RZ
AM1D-1515SH30-RZ
AM1D-2405SH30-RZ
AM1D-2409SH30-RZ
AM1D-2412SH30-RZ
AM1D-2415SH30-RZ
AM1D-4805SH30-RZ
AM1D-4809SH30-RZ
AM1D-4812SH30-RZ
AM1D-4815SH30-RZ
Input
Voltage
(V)
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
13.6-16.5
13.6-16.5
13.6-16.5
13.6-16.5
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
43.6-52.8
43.6-52.8
43.6-52.8
43.6-52.8
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
13.6-16.5
13.6-16.5
13.6-16.5
13.6-16.5
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
43.6-52.8
43.6-52.8
43.6-52.8
43.6-52.8
Output
Voltage
(V)
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
Output
Current
Max
(mA)
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
200
111.1
83.3
66.7
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
Input
Current
Full Load |
No Load
(mA)
230
230
228
228
98
95
94
94
78
76
76
75
51
49
48
48
27
26
26
26
230
230
228
228
98
95
94
94
78
76
76
75
51
49
48
48
27
26
26
26
20
30
20
20
15
15
15
15
10
10
10
10
7
7
7
7
5
5
5
5
20
30
20
20
15
15
15
15
10
10
10
10
7
7
7
7
5
5
5
5
Max
Capacitive
Load (uF)
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
220
220
100
100
Load
Regulation
(%)
6
5.5
5.5
5
4
3.5
3.5
3
4
3.5
3.5
3
4
3.5
3.5
2.5
4
3.5
3
3
6
5.5
5.5
5
4
3.5
3.5
3
4
3.5
3.5
3
4
3.5
3.5
2.5
4
3.5
3
3
Efficiency
(%)
83
86
87
87
84
86
88
88
84
86
87
89
81
84
85
86
78
80
81
81
83
86
87
87
84
86
88
88
84
86
87
89
81
84
85
86
78
80
81
81
www.aimtec.com
F 051e R12.D
Rev:05/20/A
Tel: +1 514 620 2722
1 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM1D-RZ
1 Watt | DC-DC Converter
Models
Dual output
Model
AM1D-0505D-RZ
AM1D-0509D-RZ
AM1D-0512D-RZ
AM1D-0515D-RZ
AM1D-1205D-RZ
AM1D-1209D-RZ
AM1D-1212D-RZ
AM1D-1215D-RZ
AM1D-1505D-RZ
AM1D-1509D-RZ
AM1D-1512D-RZ
AM1D-1515D-RZ
AM1D-2405D-RZ
AM1D-2409D-RZ
AM1D-2412D-RZ
AM1D-2415D-RZ
AM1D-4805D-RZ
AM1D-4809D-RZ
AM1D-4812D-RZ
AM1D-4815D-RZ
AM1D-0505DH30-RZ
AM1D-0509DH30-RZ
AM1D-0512DH30-RZ
AM1D-0515DH30-RZ
AM1D-1205DH30-RZ
AM1D-1209DH30-RZ
AM1D-1212DH30-RZ
AM1D-1215DH30-RZ
AM1D-1505DH30-RZ
AM1D-1509DH30-RZ
AM1D-1512DH30-RZ
AM1D-1515DH30-RZ
AM1D-2405DH30-RZ
AM1D-2409DH30-RZ
AM1D-2412DH30-RZ
AM1D-2415DH30-RZ
AM1D-4805DH30-RZ
AM1D-4809DH30-RZ
AM1D-4812DH30-RZ
AM1D-4815DH30-RZ
Input
Voltage
(V)
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
13.6-16.5
13.6-16.5
13.6-16.5
13.6-16.5
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
43.6-52.8
43.6-52.8
43.6-52.8
43.6-52.8
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
13.6-16.5
13.6-16.5
13.6-16.5
13.6-16.5
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
43.6-52.8
43.6-52.8
43.6-52.8
43.6-52.8
Output
Voltage
(V)
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
Output
Current
Max
(mA)
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
±100
±55.6
±41.7
±33.3
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
Input
Current
Full Load |
No Load
(mA)
230
230
228
228
98
95
94
94
78
76
76
75
51
49
48
48
27
26
26
26
230
230
228
228
98
95
94
94
78
76
76
75
51
49
48
48
27
26
26
26
20
30
20
20
15
15
15
15
10
10
10
10
7
7
7
7
5
5
5
5
20
30
20
20
15
15
15
15
10
10
10
10
7
7
7
7
5
5
5
5
Max
Capacitive
Load (uF)
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
±100
±100
±47
±47
Load
Regulation
(%)
6
5.5
5.5
5
4
3.5
3.5
3.5
3.5
2.5
2.5
2.5
3.5
2.5
2.5
2.5
3
3
3
2
6
5.5
5.5
5
4
3.5
3.5
3.5
3.5
2.5
2.5
2.5
3.5
2.5
2.5
2.5
3
3
3
2
Efficiency
(%)
84
86
87
87
85
86
87
87
85
87
87
88
82
85
87
87
77
81
82
81
84
86
87
87
85
86
87
87
85
87
87
88
82
85
87
87
77
81
82
81
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input
voltage and at rated output load unless otherwise specified.
Input Specifications
Parameters
Voltage range
Nominal
5
12
15
24
48
Typical
4.5-5.5
10.8-13.2
13.6-16.5
21.6-26.4
43.6-52.8
Capacitor
Tel: +1 514 620 2722
2 of 7
Maximum
Units
VDC
Filter
www.aimtec.com
F 051e R12.D
Rev:05/20/A
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM1D-RZ
1 Watt | DC-DC Converter
Input Specifications (continued)
Parameters
Voltage range
Nominal
5
12
15
24
48
5 Vin
12 Vin
15 Vin
24 Vin
48 Vin
5 & 12Vin
15 Vin
24Vin
48
Typical
4.5-5.5
10.8-13.2
13.6-16.5
21.6-26.4
43.6-52.8
Capacitor
9
18
20
30
54
100
20
30
40
50
Maximum
Units
VDC
Filter
Absolute Maximum Rating
VDC
Peak Input Voltage time
Input Reflected Ripple Current
ms
mA p-p
Isolation Specifications
Parameters
Tested I/O voltage
Resistance
Capacitance
Conditions
60 sec
Typical
> 1000
60
Rated
1000, 3000
Units
VDC
MOhm
pF
Output Specifications
Parameters
Voltage accuracy
Voltage balance (Dual Output model)
Line voltage regulation
Load voltage regulation
Temperature coefficient
Ripple & Noise
Conditions
Balanced Load
For 1.0% of Vin
load 10~100%
At 20MHz Bandwidth
Typical
±3
±1
±1.2
See table
±0.02
50
Maximum
Units
%
%
%
%
%/
o
C
mV p-p
General Specifications
Parameters
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Case material
Weight
Dimensions
(L x W x H)
MTBF
Conditions
100% load
Full Load without Derating
Typical
Variable 70
-40 to +85
-40 to +125
Maximum
Units
KHz
o
C
o
C
o
C
%
+100
Free air convection
95
Non-conductive black plastic (UL94V-0 rated)
Others
2.3
g
48V input models
2.8
g
Others
0.76 x 0.24 x 0.39 inch
19.50 x 6.00 x 10.00 mm
48V input models
0.76 x 0.28 x 0.39 inch
19.50 x 7.20 x 10.00 mm
>2 000 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Safety Specifications
www.aimtec.com
F 051e R12.D
Rev:05/20/A
Tel: +1 514 620 2722
3 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM1D-RZ
1 Watt | DC-DC Converter
Parameters
Agency Approval
CE
EN55032 , Class B
EN55024: 1998 + A1: 2001 + A2:2003
IEC61000-4-2:2008
IEC61000-4-3: 2006 + A1: 2007
IEC61000-4-4, 2004 (With the EFT circuit)
IEC61000-4-6: 2008
IEC61000-4-8: 1993 + A1:2000
Standards
Pin Out Specifications
Pin
1
2
4
5
6
7
1000VDC
Single
Dual
+ V Input
- V Input
- V Output
No pin
+ V Output
No pin
+ V Input
- V Input
- V Output
Common
+ V Output
No pin
3000VDC
Single
Dual
+ V Input
- V Input
No pin
- V Output
No pin
+ V Output
+ V Input
- V Input
No pin
- V Output
Common
+ V Output
Dimensions:
19.50
(0.76)
6.00
(0.24)
PRINTED
FACE
48V Input models
7.20
(0.28)
10.00
(0.39)
PRINTED
FACE
9.50
(0.37)
10.00
(0.39)
0.50
(0.02)
3.05
(0.12)
2.54
(0.10)
15.20
(0.60)
0.50
(0.02)
6.00
(0.24)
0.50
(0.02)
1.25
(0.05)
0.25
(0.01)
NOTE:
Unit:mm [inch]
Pin tolerances: ± 0.05mm [ ± 0.002inch]
General tolerances: ± 0.5mm [ ± 0.02inch]
Pin pitch and length tolerance: ±0.35 (±0.014)
7.20
(0.28)
0.50
(0.02)
1.25
(0.05)
0.25
(0.01)
www.aimtec.com
F 051e R12.D
Rev:05/20/A
Tel: +1 514 620 2722
4 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM1D-RZ
1 Watt | DC-DC Converter
Typical Efficiency Chart Examples
AM1D-0515S-RZ Efficiency vs. Loading
100
80
Eff %
60
40
20
0
20%
40%
60%
Loading %
80%
100%
AM1D-1209S-RZ Efficiency vs. Loading
100
80
Eff %
60
40
20
0
20%
40%
60%
Loading %
80%
100%
www.aimtec.com
F 051e R12.D
Rev:05/20/A
Tel: +1 514 620 2722
5 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
京公网安备 11010802033920号
EEWORLD
