Series AM1DS-Z
1 Watt | DC-DC Converter
FEATURES:
RoHS compliant
High efficiency up to 76%
Low profile plastic package
7 pin SIP package
Operating temperature -40
o
C to + 85
o
C
Continuous Short circuit protection
Pin compatible with multiple manufacturers
Input / Output Isolation
1000 to 6000 VDC
Models
Single output
Model
AM1DS-0505SZ
AM1DS-0512SZ
AM1DS-0515SZ
AM1DS-1205SZ
AM1DS-1212SZ
AM1DS-1215SZ
AM1DS-2405SZ
AM1DS-2412SZ
AM1DS-2415SZ
AM1DS-0505SH30Z
AM1DS-0512SH30Z
AM1DS-0515SH30Z
AM1DS-1205SH30Z
AM1DS-1212SH30Z
AM1DS-1215SH30Z
AM1DS-2405SH30Z
AM1DS-2412SH30Z
AM1DS-2415SH30Z
AM1DS-0505SH40Z
AM1DS-0512SH40Z
AM1DS-0515SH40Z
AM1DS-1205SH40Z
AM1DS-1212SH40Z
AM1DS-1215SH40Z
AM1DS-2405SH40Z
AM1DS-2412SH40Z
AM1DS-2415SH40Z
AM1DS-0505SH52Z
AM1DS-0512SH52Z
AM1DS-0515SH52Z
AM1DS-1205SH52Z
AM1DS-1212SH52Z
AM1DS-1215SH52Z
AM1DS-2405SH52Z
AM1DS-2412SH52Z
AM1DS-2415SH52Z
AM1DS-0505SH60Z
AM1DS-0512SH60Z
AM1DS-0515SH60Z
AM1DS-1205SH60Z
AM1DS-1212SH60Z
AM1DS-1215SH60Z
AM1DS-2405SH60Z
AM1DS-2412SH60Z
AM1DS-2415SH60Z
Input
Voltage
(V)
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
Output
Voltage
(V)
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
5
12
15
Output Current
max
(mA)
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
200
83
67
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
4000
4000
4000
4000
4000
4000
4000
4000
4000
5200
5200
5200
5200
5200
5200
5200
5200
5200
6000
6000
6000
6000
6000
6000
6000
6000
6000
Max
Capacitive
Load (uF)
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
Efficiency
71
74
74
72
74
75
73
75
75
71
74
74
72
74
75
73
75
75
71
74
74
72
74
75
73
75
75
71
74
74
72
74
75
73
75
75
71
74
74
72
74
75
73
75
75
www.aimtec.com
F 051e R12.C
Tel: +1 514 620 2722
1 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM1DS-Z
1 Watt | DC-DC Converter
Models
Dual output
Model
AM1DS-0505DZ
AM1DS-0512DZ
AM1DS-0515DZ
AM1DS-1205DZ
AM1DS-1212DZ
AM1DS-1215DZ
AM1DS-2405DZ
AM1DS-2412DZ
AM1DS-2415DZ
AM1DS-0505DH30Z
AM1DS-0512DH30Z
AM1DS-0515DH30Z
AM1DS-1205DH30Z
AM1DS-1212DH30Z
AM1DS-1215DH30Z
AM1DS-2405DH30Z
AM1DS-2412DH30Z
AM1DS-2415DH30Z
AM1DS-0505DH40Z
AM1DS-0512DH40Z
AM1DS-0515DH40Z
AM1DS-1205DH40Z
AM1DS-1212DH40Z
AM1DS-1215DH40Z
AM1DS-2405DH40Z
AM1DS-2412DH40Z
AM1DS-2415DH40Z
AM1DS-0505DH52Z
AM1DS-0512DH52Z
AM1DS-0515DH52Z
AM1DS-1205DH52Z
AM1DS-1212DH52Z
AM1DS-1215DH52Z
AM1DS-2405DH52Z
AM1DS-2412DH52Z
AM1DS-2415DH52Z
AM1DS-0505DH60Z
AM1DS-0512DH60Z
AM1DS-0515DH60Z
AM1DS-1205DH60Z
AM1DS-1212DH60Z
AM1DS-1215DH60Z
AM1DS-2405DH60Z
AM1DS-2412DH60Z
AM1DS-2415DH60Z
Input
Voltage (V)
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
Output
Voltage
(V)
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
Output Current
max (mA)
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
±100
±42
±33
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
4000
4000
4000
4000
4000
4000
4000
4000
4000
5200
5200
5200
5200
5200
5200
5200
5200
5200
6000
6000
6000
6000
6000
6000
6000
6000
6000
Max
Capacitive
Load (uF)
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
±100
Efficiency
(%)
70
71
71
73
76
76
72
74
76
70
71
71
73
76
76
72
74
76
70
71
71
73
76
76
72
74
76
70
71
71
73
76
76
72
74
76
70
71
71
73
76
76
72
74
76
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input
voltage and at rated output load unless otherwise specified.
www.aimtec.com
F 051e R12.C
Tel: +1 514 620 2722
2 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM1DS-Z
1 Watt | DC-DC Converter
Input Specifications
Parameters
Voltage range
Filter
Turn on Transient process time
Start up time
Absolute Maximum Rating
Peak Input Voltage time
Input reflected Ripple current
5 Vin
12 Vin
24 Vin
With 12µH inductance
Nominal
5
12
24
Typical
4.5-5.5
10.8-13.2
21.6-26.4
Capacitor
Maximum
Units
VDC
25
200
0-7
0-15
0-28
100
20
ms
ms
VDC
ms
mA p-p
Isolation Specifications
Parameters
Tested I/O voltage
Resistance
Capacitance
Conditions
3 sec
Typical
> 1000
10
Rated
1000, 3000, 4000, 5200 & 6000
Units
VDC
MOhm
pF
Output Specifications
Parameters
Voltage accuracy
Voltage balance (Dual Output model)
Short Circuit protection
Short circuit restart
Line voltage regulation (Single)
Line voltage regulation (Dual)
Load voltage regulation
Temperature coefficient
Ripple & Noise
Rising time
Conditions
Balanced Load
Typical
±3
±1
Continuous
Auto-Recovery
±1.2
±1.2
±10
±0.02
75
50
Maximum
Units
%
%
For 1.0% of Vin
For 1.0% of Vin
load 20~100%
At 20MHz Bandwidth
%
%
%
%/
o
C
mV p-p
ms
General Specifications
Parameters
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Case material
Weight
Dimensions
(L x W x H)
MTBF
Conditions
100% load, variable
Full load without derating
Typical
80
-40 to +85
-40 to +125
Maximum
Units
KHz
o
C
o
C
o
C
%
g
+100
Free air convection
95
Non-conductive black plastic UL 94 V-0
2.3
0.76 x 0.24 x 0.37 inch
19.50 x 6.00 x 9.50 mm
>1 121 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Safety Specifications
Parameters
Safety
Designed to meet IEC 60950-1
www.aimtec.com
F 051e R12.C
Tel: +1 514 620 2722
3 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM1DS-Z
1 Watt | DC-DC Converter
Pin Out Specifications
Pin
1
2
4
5
6
7
Single
1000 VDC
+ V Input
- V Input
- V Output
No pin
+ V Output
No pin
Dual
1000 VDC
+ V Input
- V Input
- V Output
Common
+ V Output
No pin
Single
3000, 4000, 5200 & 6000 VDC
+ V Input
- V Input
No pin
- V Output
No pin
+ V Output
Dual
3000, 4000, 5200 & 6000 VDC
+ V Input
- V Input
No pin
- V Output
Common
+ V Output
Dimensions:
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
www.aimtec.com
F 051e R12.C
Tel: +1 514 620 2722
4 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
