Standard Variable Output LDO Regulators
1A Standard
Variable Output LDO Regulators
BD00C0AWFP,BD00C0AWCP-V5
No.11023EBT03
●Description
The BD00C0AW Series is low-saturation regulators. The output voltage can be arbitrarily configured using the external resistance.
This IC has a built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits and a
thermal shutdown circuit that protects the IC from thermal damage due to overloading.
●Features
1) Output Current: 1A
2) High Output Voltage Precision :
±1%
3) Low saturation with PDMOS output
4) Built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits
5) Built-in thermal shutdown circuit for protecting the IC from thermal damage due to overloading
6) Low ESR Capacitor
7) TO252-5,TO220CP-V5 packaging
●Applications
Audiovisual equipments, FPDs, televisions, personal computers or any other consumer device
●Absolute
maximum ratings (Ta=25℃)
Parameter
Supply Voltage
Output Control Voltage
Power Dissipation (TO252-5)
*2
*1
Symbol
Vcc
V
CTL
Pd
Pd
Topr
Tstg
Tjmax
Ratings
-0.3 ~ +35.0
-0.3 ~ +35.0
1.3
1.85
-40 ~ +105
-55 ~ +150
+150
Unit
V
V
W
W
℃
℃
℃
Power Dissipation (TO220CP-V5)
*3
Operating Temperature Range
Storage Temperature Range
Maximum Junction Temperature
*1 Not to exceed Pd.
*2 TO252-5:Reduced by 10.4mW /
℃
over Ta = 25℃, when mounted on glass epoxy board: 70mm×70mm×1.6mm.
*3 TO220CP-V5:Reduced by 14.8mW /
℃
over Ta = 25℃, when It’s without Aluminium heat dissipation board.
NOTE : This product is not designed for protection against radioactive rays.
●Operating
conditions (Ta=25℃)
Parameter
Supply Voltage
Output Control Voltage
Output Current
Output Voltage
Symbol
Vcc
V
CTL
Io
Vo
Min.
4.0
0
0
3.0
Max.
26.5
26.5
1.0
15.0
Unit
V
V
A
V
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
1/11
2011.08 - Rev.B
BD00C0AWFP,BD00C0AWCP-V5
●Electrical
characteristics
Unless otherwise specified, Ta=25℃, Vcc=10V,V
CTL
=5V,Io=0mA,Vo=5.0Vsetting
(The resistor of between ADJ and Vo =56.7kΩ,ADJ and GND =10kΩ)
Parameter
Shut Down Current
Bias Current
ADJ Terminal Voltage
Dropout Voltage
Ripple Rejection
Line Regulation
Load Regulation
Symbol
Isd
Ib
VADJ
ΔVd
R.R.
Reg.I
Reg.L
Tcvo.1
Tcvo.2
VthH
VthL
ICTL
Min.
－
－
0.742
－
45
－
－
－
－
2.0
－
－
Typ.
0
0.5
0.750
0.3
55
20
Max.
10
1.0
0.758
0.5
－
60
Unit
µA
mA
V
V
dB
mV
V
%/℃
%/℃
V
V
µA
Io=50mA
Technical Note
Conditions
V
CTL
=0V
Vcc=Vo×0.95, Io=500mA
*1
f=120Hz,ein =1Vrms,
Io=100mA
Vcc=6→25V
Io=5mA→1A
Io=5mA,Tj=-40 ~ -20℃
Io=5mA,Tj=-20 ~ +105℃
ACTIVE MODE
OFF MODE
Vo×0.010 Vo×0.015
+0.04
±0.005
－
－
25
－
－
－
0.8
50
Temperature Coefficient of
Output Voltage
CTL ON Mode Voltage
CTL OFF Mode Voltage
CTL Bias Current
*1
ein : Input Voltage Ripple
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
2/11
2011.08 - Rev.B
BD00C0AWFP,BD00C0AWCP-V5
●Electrical
characteristic curves (Reference data)
Unless otherwise specified, Ta=25℃, Vcc=10V,V
CTL
=5V,Io=0mA,Vo=5.0Vsetting
(The resistor of between ADJ and Vo =56.7kΩ,ADJ and GND =10kΩ)
CIRCUIT CURRENT:
I
b+
I
FEEDBACK_R
[mA]
1.0
STANBY CURRENT
：
Isd [µA]
18
15
12
9
6
3
0
Technical Note
6
5
4
3
2
1
0
0 2 4
6 8 10 12 14 16 18 20 22 24
SUPPLY VOLTAGE: Vcc [V]
0.8
0.6
0.4
0.2
0.0
0 2 4 6 8 10 12 14 16 18 20 22 24
SUPPLY VOLTAGE: Vcc [V]
OUTPUT VOLTAGE : Vo [V]
0 2 4 6 8 10 12 14 16 18 20 22 24
SUPPLY VOLTAGE: Vcc [V]
Fig.1 Circuit Current
(I
FEEDBACK_R
≒75µA)
6
5
4
3
2
1
0
0 2 4 6 8 10 12 14 16 18 20 22 24
SUPPLY VOLTAGE
：
Vcc [V]
6
Fig.2 Shut Down Current
600
DROPOUT VOLTAGE
：
ΔVd
[mV]
500
400
300
200
100
0
0
400
800
1200
1600
OUTPUT CURRENT
：
I
O
[mA]
2000
Fig.3 Line Regulation
(Io=0mA)
OUTPUT VOLTAGE
：
Vo [V]
OUTPUT VOLTAGE
：
Vo [V]
5
4
3
2
1
0
0
200
400
600
800
1000
OUTPUT CURRENT
：
Io [mA]
Fig.4 Line Regulation
(Io=500mA)
1.0
Fig.5 Load Regulation
Fig.6 Dropout Voltage
(Vcc=4.75V)
(lo=0mA→1000mA)
CIRCUIT CURRENT: Ib
+
I
FEEDBACK_R
[mA]
1.0
CIRCUIT CURRENT : Ib+ I
FEEDBACK_R
[mA]
6
5
4
3
2
1
0
0
200
400
600
800
1000
-40
-20
0
20
40
60
80
100
OUTPUT VOLTAGE : Vo [V]
0.8
0.8
0.6
0.6
0.4
0.4
0.2
0.2
0.0
OUTPUT CURRENT: Io [mA]
0.0
0
AMBIENT TEMPERATURE: Ta[
℃
]
200
400
600
800
OUTPUT CURRENT: Io [mA]
1000
Fig.7 Ripple Rejection
(lo=100mA)
100
90
CIRCUIT CURRENT: I
CTL
[µA]
OUTPUT VOLTAGE: Vo [V]
Fig.8 Output Voltage
Temperature Characteristics
6
5
4
3
2
1
0
6
5
4
3
2
1
0
130
Fig.9 Circuit Current
(lo=0mA→1000 mA)
(I
FEEDBACK_R
≒75µA)
70
60
50
40
30
20
10
0
0 2 4 6 8 10 12 14 16 18 20 22 24
CONTROL VOLTAGE: V
CTL
[V]
0 2 4 6 8 10 12 14 16 18 20 22 24
CONTROL VOLTAGE: V
CTL
[V]
OUTPUT VOLTAGE
：
Vo [V]
80
140
150
160
170
180
190
AMBIENT TEMPERATURE
：
Ta [
℃
]
Fig.10 CTL Voltage vs CTL Current
Fig.11 CTL Voltage vs Output Voltage
Fig.12 Thermal Shutdown
Circuit Characteristics
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
3/11
2011.08 - Rev.B
BD00C0AWFP,BD00C0AWCP-V5
●Measurement
circuit for reference data
Technical Note
A
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
1µF
CTL
GND
ADJ
1µF
1µF
CTL
GND
ADJ
1µF
1µF
CTL
GND
ADJ
1µF
V
5V
I
FEEDBACK _R
10kΩ
A
10kΩ
5V
10kΩ
Measurement Circuit of Fig.1
Measurement Circuit of Fig.2
Measurement Circuit of Fig.3
V
Vcc
Vo
56.7kΩ
1µF
CTL
1µF
GND
ADJ
500mA
5V
1µF
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
1µF
GND
ADJ
V
10V
CTL
A
4.75V
1µF
CTL
1µF
GND
ADJ
A
5V
10kΩ
10kΩ
5V
10kΩ
Measurement Circuit of Fig.4
Measurement Circuit of Fig.5
Measurement Circuit of Fig.6
Vcc
1Vrms
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
½
1µF
CTL
GND
ADJ
1µF
10V
1µF
CTL
1µF
GND
ADJ
1µF
V
10V
CTL
1µF
GND
ADJ
10kΩ
10V
5V
10kΩ
100mA
5V
10kΩ
5V
I
FEEDBACK _R
A
Measurement Circuit of Fig.7
Measurement Circuit of Fig.8
Measurement Circuit of Fig.9
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
Vcc
Vo
56.7kΩ
1µF
10V
A
1µF
CTL
GND
ADJ
10V
10kΩ
1µF
1µF
CTL
GND
ADJ
1µF
1µF
CTL
GND
ADJ
V
10V
10kΩ
5V
V
10kΩ
Measurement Circuit of Fig.10
Measurement Circuit of Fig.11
Measurement Circuit of Fig.12
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
4/11
2011.08 - Rev.B
BD00C0AWFP,BD00C0AWCP-V5
●
Block diagrams (BD00C0AWFP / BD00C0AWCP-V5)
Technical Note
GND /
－
FIN
VREF
OCP
TSD
Driver
: Bandgap Reference
: Over Current Protection Circuit
: Thermal Shut Down Circuit
: Power Transistor Driver
VREF
-
+
Driver
OCP
TSD
1
CTL
2
Vcc
3
N.C. / GND
Fig.13
Pin Name
(BD00C0AWFP / BD00C0AWCP-V5)
CTL
Vcc
N.C. / GND
Vo
ADJ
GND /
－
4
Vo
5
ADJ
Pin No.
1
2
3
4
5
Fin
Function
Output Control Pin
Power Supply Pin
N.C. Pin / GND
Output Pin
Adjustable Pin
GND / -
●
TOP VIEW
〈
Package dimension
〉
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
5/11
2011.08 - Rev.B
