TANTALUM DIPPED / RADIAL — POLAR

PERFORMANCE CHARACTERISTICS

• CAPACITANCE/VOLTAGE RANGE:

T35X/T39X: 0.1-680µF, 3-50 Volts.

T36X: 0.1-330µF, 6-50 Volts.

• CAPACITANCE TOLERANCE: Available in stan-

dard EIA nominal values with ±20% and ±10%

standard.

• DISSIPATION FACTOR: Maximum DF limits are

shown in corresponding series part number list-

ings. See Application Notes Section, page 76 for

additional information.

• DC LEAKAGE CURRENT: Maximum leakage val-

ues at 25° are shown in part number listings,

pages 63-65, 67, 68 and 70. See Application

Notes Section, pages 76 & 77 for additional infor-

mation.

• RATED VOLTAGE; WORKING VOLTAGE; SURGE

VOLTAGE; REVERSE VOLTAGE: See Application

Notes Section, pages 76 & 77 for description.

• IMPEDANCE and ESR: See Application Notes

Section, page 77 & 78 for description. Reference

ESR values are shown in table below.

• AC RIPPLE VOLTAGE: Permissible AC ripple volt-

age is related to equivalent series resistance

(ESR) and power dissipation capability. Maximum

power dissipation for each case size is listed in

Table below. For additional description see page

78.

Case

Size

T35X, A

T39X B

T36X A

Power Dissipation

(max.) @ 25°C (watts)

.040

.050

.060

.065

.070

.080

.090

.100

.110

.120

.130

.140

.050

.075

.090

.135

Maximum Power Dissipation Capability @ 25°C

Commercial T35X/T36X/T39X ESR (OHMS) at 100 kHz @ +25°C

(The ESR values provided below are for reference only. No warranty, as

stated on page 3 and reincorporated here, is made as to the accuracy

of these values for any particular T35X, T36X, T39X Series product.)

Cap.

µF

0.10

0.15

0.22

0.33

0.47

0.68

1.00

1.50

2.20

3.30

4.70

6.80

10.0

15.0

22.0

33.0

47.0

68.0

100.0

150.0

220.0

330.0

Volt

26.0

21.0

17.0

15.0

13.0

10.0

8.0

6.0

5.0

4.0

3.0

2.5

2.0

1.6

1.3

1.0

0.8

Volt

26.0

21.0

17.0

15.0

13.0

10.0

8.0

5.0

3.5

3.0

2.5

2.0

1.6

1.2

1.0

• ENVIRONMENTAL CONSIDERATIONS:

A. Shock Test: MIL-STD-202, Method 213.

B. Thermal Shock, MIL-STD-202, Method 107,

Condition A.

C. Moisture Resistance: MIL-STD-202,

Method 106.

D. Solderability: MIL-STD-202, Method 208.

For additional Environmental Test Information

see pages 80, 81 and 82.

• LEAD MATERIAL: Solder coated steel core with

copper ply per MIL-STD-127.

• LEAD TAPE and REEL: Reeling per specification

RS-468. See pages 72 - 74 for additional informa-

tion.

KEMET Electronics Corporation, P.O. Box 5928, Greenville, S.C. 29606 (864) 963-6300

Tantalum Dipped /

Radial — Polar

13.0

10.0

8.0

6.0

5.0

3.7

3.0

2.0

1.8

1.6

0.9

0.7

13.0

10.0

8.0

6.0

5.0

3.7

2.7

2.1

1.7

1.3

1.0

0.8

0.6

10.0

8.0

6.0

5.0

4.0

3.2

2.5

2.0

1.6

1.3

1.0

0.8

0.6

10.0

9.0

7.0

5.5

4.5

3.6

2.9

2.3

1.8

1.4

1.2

0.9

0.6

10.0

8.0

6.0

5.0

4.0

3.1

2.5

2.0

1.5

1.2

1.0

0.8
