RGF02G2701MG00NL: DescriptionRESISTOR, 2W, 2%, 350ppm, 2700ohm, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components The resistor; File Size242KB，2 Pages; ManufacturerFutaba Electric Co., Ltd.; Environmental Compliance

Download Datasheet Parametric View All

RGF02G2701MG00NL Overview

RESISTOR, 2W, 2%, 350ppm, 2700ohm, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

RGF02G2701MG00NL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	RADIAL LEADED, ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Manufacturer's serial number	RGF
Installation features	THROUGH HOLE MOUNT
Maximum operating temperature	235 °C
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	2 W
Rated temperature	70 °C
resistance	2700 Ω
Resistor type	FIXED RESISTOR
surface mount	NO
Temperature Coefficient	350 ppm/°C
Terminal shape	WIRE
Tolerance	2%
Operating Voltage	150 V

Preview

Download Datasheet

View All

CEMENT RESISTOR

RGW

RGF

水泥電阻器

CEMENT RESISTOR(Wire Type)

水泥電阻器

CEMENT RESISTOR(Film Type)

■結構圖

Construction

1

2

本體顏色

：Body

color

½

標

文

色

：White

示：Marking

字

：Alphanumeric

3

4

端

鐵

瓷

繞

子

線

Lead wire

½

Cap

棒

Ceramic base

線

Wire wound

5

6

7

標

示

Marking or colcr

code

絕緣塗料

Insulation coat

瓷

殼

Ceramic case

■料號編碼

Type composition

例

RG

型名

Type

Example

W

品名

Size

W:Wire

F:Film

■特性

Feature

◎不燃與絕緣之安全設計

◎Compact

type with safety design of non-flammability

and insulation.

◎可提供½電感

◎Low

inductance is available.

◎長期穩定性½

◎Stable

long life.

◎可依客戶需求½½

◎Can

be produced according to customer’s request.

◎產品符合歐盟RoHS要求

◎Products

meet EU-RoHS.

01

額定功率

J

誤差值

R100

電阻值(Ω)

PG00

二次加工

Forming

PG00=P Type

MG00=M Type

SG00=S Type

TG00=T Type

HG02=H Type

NH

端子線

Lead Wire

NH=Heat

Plated

NL=Electro

Plated

Rated Power Tolerance Resistance

01:1W

02:2W

05:5W

07:7W

A0:10W

B5:25W

F±1%

G±2%

J±5%

K±10%

R100=0.1

1R00=1

10R0=10

1000=100

1001=1K

1002=10K

■造型對應表

Type matrix

RG

Type

1

◎

2

◎

3

◎

5

◎

Rated Power(W)

7

◎

10

◎

15

◎

20

◎

25

◎

30

40

P

■參考規格

Reference standards

●

JIS C 5201-1

Z

M

T

S

H

■額定

Ratings

Rated

Power(W)

1

2

3

5

7

10

15

20

25

30

40

阻值範圍

Resistance Range(Ω)

皮膜型

Film Type

4~39K

4~50K

4~100K

RGK TYPE Available：4W 5W 6W 7W 9W 11W 17W

最高½用電壓

最高過負荷電壓

Max. Overload Voltage

500V

750V

1000V

1500V

1000V

≦1Ω:±600ppm/℃

＞1Ω:±350ppm/℃

耐電壓Dielectric

WithstandingVoltage

溫度係數

T.C.R

繞線型

Wire wound Type Max. Working Voltage

0.1~330

0.1~1K

0.1~2.2K

0.1~4.7K

1~5.1K

1~10K

150V

350V

500V

750V

1000V

36
