ES15M Overview

50V ~ 600V 1.0 Amp Surface Mount Efficient Fast Rectifiers

Preview

Download Datasheet

View All

ES11M~ES15M

Elektronische Bauelemente

50V ~ 600V

1.0 Amp Surface Mount Efficient Fast Rectifiers

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

DESCRIPTIONS

Batch process design, excellent power dissipation offers

better reverse leakage current and thermal resistance.

Low profile surface mounted application in order to

optimize board space.

Small plastic SMD package.

less than 25nS for high efficiency

Low forward drop down voltage

High surge and high current capability.

Superfast recovery time for switching mode application.

Glass-passivated chip junction.

SOD-123M

REF.

MECHANICAL DATA

Case: Molded plastic

Epoxy: UL94-V0 rate flame retardant

Weight: 0.0270 g (approximately)

Millimeter

Min.

Max.

3.50

3.90

1.40

1.80

1.30

1.70

REF.

Millimeter

Min.

Max.

3.60 (MAX.)

0.80 (TYP.)

0.30 (TYP.)

MARKING

Part Number

ES11M

ES12M

ES13M

Marking

Part Number

ES14M

ES15M

Marking

PACKAGING INFORMATION

Package

SOD-123M

MPQ

2.5K

Leader Size

7 inch

ABSOLUTE MAXIMUM RATINGS

=25°C unless otherwise specified)

Parameters

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum Reverse Voltage

Maximum Forward Voltage @ I

=1A

Maximum Average Forward Rectified Current

=55°C

Peak Forward Surge Current, 8.3ms single half

sine-wave superimposed on rated load (JEDEC

method)

Maximum DC Reverse Current at

Rated DC Blocking Voltage

Reverse Recovery Time

Typical Junction Capacitance

Symbol

ES11M

RRM

RMS

FSM

ES12M

100

0.875

Part Number

ES13M

200

140

200

ES14M

400

280

400

1.25

1.0

100

-65~175, -55~150

ES15M

600

420

600

1.75

Units

=25°C

=125°C

STG

, T

µA

Storage and Operating Temperature Range

Note:

1. f=1MHz and applied 4V DC reverse voltage

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

09-Dec-2011 Rev. B

Page 1 of 2
