3130W201P

Description
RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.15W, 200ohm, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size114KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

3130W201P Overview

RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.15W, 200ohm, ROHS COMPLIANT

3130W201P Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionROHS COMPLIANT
Reach Compliance Codeunknown
ECCN codeEAR99
Actuator directionVERTICAL
Actuator typeSCREW
Manufacturer's serial number3130
Installation featuresSURFACE MOUNT
Number of terminals3
number of turns1
Package shapeRECTANGULAR PACKAGE
Rated power dissipation(P)0.15 W
resistance200 Ω
resistance lawLINEAR
Resistor typeTRIMMER
surface mountYES
technologyCERMET
Terminal surfaceNOT SPECIFIED
Terminal shapeWRAPAROUND
Tolerance25%
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Resistors
>
Product Feature Selector
> Product Details
3130W201P Product Details
Live Product Chat
Variable Resistors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3130W201P
(1623922-4)
T E I nternal N umber: 1 6 2 3 9 2 2 - 4
Product Highlights:
l
Variable Resistor
l
Resistor Type = Trimmer
l
Resistance Selection = <1K ?
l
Resistance = 200 ?
l
Power Rating = .15 W
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
SMD EC ONOMY TRIMMERS SERIES 3130W
(PDF, English)
Catalog Pages/Data Sheets:
l
SMD Economy Trimmers - Type 3130 Series - Tyco Elect...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Variable Resistor
l
Resistor Type
= Trimmer
l
Resistance (?)
= 200
l
Element
= C ermet
l
Sealed
= No
l
Mount Angle
= Horizontal
l
Termination Type
= Surface Mount Terminals
l
C omment = Open Frame
Electrical Characteristics:
l
Resistance Selection (?) = <1K
l
Power Rating (W)
= 0.15
l
Tolerance (%)
= 25
Termination Related Features:
l
Termination Post Orientation
= Delta
Body Related Features:
l
Series
= 3130
l
Package, C omponent Size
= 3
Configuration Related Features:
l
Sections
= Single
l
Adjustment Location
= Top
l
Adjustment Style
= C ross Slot
l
Operating Function
= Single Turn
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Conditions for Usage:
l
Temperature C oefficient (ppm/?C )
= 250
Other:
l
Brand = C itec
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
