SEMICONDUCTOR
TECHNICAL DATA
COLOR TV VERT. DEFELECTION OUTPUT APPLICATION.
COLOR TV CLASS B SOUND OUTPUT APPLICATION.
FEATURES
High Voltage : V
CEO
=-160V.
Large Continuous Collector Current Capability.
Complementary to KTC3228.
C
P
DEPTH:0.2
KTA1275
EPITAXIAL PLANAR PNP TRANSISTOR
B
D
A
S
Q
K
DIM
A
B
C
D
E
F
G
H
J
K
L
M
N
O
P
Q
R
S
MILLIMETERS
7.20 MAX
5.20 MAX
0.60 MAX
2.50 MAX
1.15 MAX
1.27
1.70 MAX
0.55 MAX
_
14.00 + 0.50
0.35 MIN
_
0.75 + 0.10
4
G
J
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Base Current
Collector Power Dissipation
Junction Temperature
Storage Temperature Range
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
RATING
-160
-160
-6
-1
-0.5
1
150
-55 150
UNIT
V
O
F
H
M
E
F
H
M
H
R
V
V
A
A
W
1
N
2
3
N
H
L
1. EMITTER
2. COLLECTOR
3. BASE
25
1.25
Φ1.50
0.10 MAX
_
12.50 + 0.50
1.00
TO-92L
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC
Collector Cut-off Current
Emitter Cut-off Current
Collector-Emitter Breakdown Voltage
DC Current Gain
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter Voltage
Transition Frequency
Collector Output Capacitance
Note : h
FE
Classification
R:60
120
SYMBOL
I
CBO
I
EBO
V
(BR)CEO
h
FE
(Note)
V
CE(sat)
V
BE(sat)
V
BE
f
T
C
ob
0:100 200,
TEST CONDITION
V
CB
=-150V, I
E
=0
V
EB
=-6V, I
C
=0
I
C
=-10mA, I
B
=0
V
CE
=-5V, I
C
=-200mA
I
C
=-500mA, I
B
=-50mA
I
C
=-500mA, I
B
=-50mA
V
CE
=-5V, I
C
=-5mA
V
CE
=-5V, I
C
=-200mA
V
CB
=-10V, I
E
=0, f=1MHz
Y:160
320
MIN.
-
-
-160
60
-
-
-0.45
15
-
TYP.
-
-
-
-
-
-
-
50
-
MAX.
-1.0
-1.0
-
320
-1.5
-1.2
-0.75
-
35
V
V
V
MHz
pF
UNIT
A
A
V
2007. 12. 20
Revision No : 3
D
1/3
