Part No.
SPECIFICATION
LM-W6-60* 10-2W
Features：
High radiometric power per LED
Very long operating life
(up to 100K hours)
Low voltage DC operated
More Energy Efficient than Incandescent
and most Halogen lamps
Good color uniformity
NO UV
Superior ESD protection
Easy installation with Screws
High Heat dissipstion Efficiency
NOTE:
All dimensions are millimeter.
Tolerance is ±0.1mm unless otherwise noted
It is strongly recommended that the temperature
of lead be not higher than 55
o
C
The appearance and specifications of the product may be
modified for improvement without notice.
+
Typical Applications：
Reading lights(car,bus,aircraft)
Portable(flashlight,bicycle)
Automotive Exterior(Stop-Tail-Turn,
CHMSL,Mirror Side Repeat)
Decorative/Entertainment
Dental curing lights
Uplighters/Downlighters
Bollards/Security/Garden
Cove/Undershelf/Task
Indoor/Outdoor Commercial and Residential Architectural
Automotive Ext(stop-Tail-Turn)
Lcd backlights
Street Lamp
Page 1 of 6
Hebei I.T. (Shanghai) Co., Ltd.
Part No.
Absolute maximum ratings（Ta = 25℃）
SPECIFICATION
LM-W6-60* 10-2W
Value
Parameter
DC Forward Current
Peak Pulse Current
Power Dissipation
LED Junction Temperature
Symbol
I
F
Ipeak
Pd
Tj
Topr
Tstr
---
---
Test
Condition
Min.
Max.
Unit
----
300
mA
----
350
mA
----
2.8
W
----
120
℃
-25
+80
℃
-40
+120
℃
8000
---
V
220℃ for 5 Seconds max
(CCT
5500k)
Operating Temperature
Storage Temperature
ESD Sensitivity
Soldering Temperature
----
Duty=0.1，1kHz
----
----
----
----
HBM
-----
Electrical and optical characteristics
（Ta
= 25℃）
Value
Parameter
Forward Voltage
Luminous Flux
Viewing Angle
Color Temperature
Color Rendering Index
Symbol
V
F
Φv
2θ
1/2
CCT
Ra
Test
Condition
Min.
9.0
140
----
5000
75
Typ.
9.5
180
120
----
Unit
Max.
10
-----
----
6500
V
lm
Deg.
K
-
I
F
= 200mA
Luminous Flux
Bins（Ta = 25℃）
Bin
Min
Max
Q
140
160
R
160
180
S
180
200
T
200
240
Unit:lm
Chromaticity Coordinates Ranks(IF=200mA
Bin
PT1
PT2
PT3
PT4
PV1
PV2
PV3
x1
0.3384
0.3381
0.3378
0.3374
0.3300
0.3302
0.3303
y1
0.3650
0.3550
0.3451
0.3352
0.3584
0.3484
0.3384
x2
0.3381
0.3378
0.3374
0.3371
0.3302
0.3303
0.3304
y2
0.3550
0.3451
0.3352
0.3252
0.3484
0.3384
0.3285
Ta=25℃)
x3
0.3461
0.3453
0.3444
0.3436
0.3381
0.3378
0.3374
y3
0.3617
0.3518
0.3418
0.3318
0.3550
0.3451
0.3352
x4
0.3469
0.3461
0.3453
0.3444
0.3384
0.3381
0.3378
y4
0.3717
0.3617
0.3518
0.3418
0.3650
0.3550
0.3451
Page 3 of 6
Hebei I.T. (Shanghai) Co., Ltd.
Part No.
Bin
PV4
PW1
PW2
PW3
PW4
PX1
PX2
PX3
PX4
PY1
PY2
PY3
PY4
x1
0.3304
0.3236
0.3242
0.3247
0.3253
0.3173
0.3182
0.3191
0.3201
0.3109
0.3122
0.3135
0.3149
y1
0.3285
0.3534
0.3434
0.3335
0.3235
0.3484
0.3385
0.3286
0.3186
0.3434
0.3335
0.3236
0.3136
x2
0.3306
0.3242
0.3247
0.3253
0.3258
0.3182
0.3191
0.3201
0.3210
0.3122
0.3135
0.3149
0.3162
y2
0.3185
0.3434
0.3335
0.3235
0.3136
0.3385
0.3286
0.3186
0.3086
0.3335
0.3236
0.3136
0.3037
x3
0.3371
0.3302
0.3303
0.3304
0.3306
0.3242
0.3247
0.3253
0.3258
0.3182
0.3191
0.3201
0.3210
SPECIFICATION
LM-W6-60* 10-2W
y3
0.3252
0.3484
0.3384
0.3285
0.3185
0.3434
0.3335
0.3235
0.3136
0.3385
0.3286
0.3186
0.3086
x4
0.3374
0.3300
0.3302
0.3303
0.3304
0.3236
0.3242
0.3247
0.3253
0.3173
0.3182
0.3191
0.3201
y4
0.3352
0.3584
0.3484
0.3384
0.3285
0.3534
0.3434
0.3335
0.3235
0.3484
0.3385
0.3286
0.3186
Y
5600K
0.370
6300K
0.360
1
PV
X1
1
PW
P
W2
2
PV
3
PV
PT
PT
PT
1
0.350
2
0.340
P
Y1
P
PY
2
3
0.330
2
PX
0.320
0.310
4
3
PV
PX
3
4
PY
PW
4
PX
4
PY
0.320
0.330
0.340
0.350
3
PW
4
PT
Note
0.300
0.300 0.310
5000K
X
1． Flux is measured with an accuracy of ±15%
2． Chromaticity Coordinates (x,y) is measured with an accuracy of ±0.01
3． Forward Voltage is measured with an accuracy of ± 0.2V
4． It is strongly recommended that the temperature of lead be not higher than 55
o
C
Page 4 of 6
Hebei I.T. (Shanghai) Co., Ltd.
SPECIFICATION
Part No. LM-W6-60* 10-2W
Color Spectrum, TJ=25
O
C
White
1.0
White
Relative Spectral Power
Distribution
0.8
0.6
0.4
0.2
Standard Eye Response Cruve
0.0
350 400 450 500 550 600 650 700 750 800 850
Wavelength
λ
(nm)
Typical electrical/optical characteristic curves：
FORWARD CURRENT Vs
FORWARD VOLTAGE
Forward Current(mA)
Relative Light Output(%)
250
200
150
100
50
0
0
3
6
9
12
Forward Voltage(V)
FORWARD CURRENT
DERATINE CERVE
Relative Light Output(%)
250
Forward Current(mA)
200
150
100
50
0
0
20 40 60 80 100
Ambient Temperature TA(
℃
)
2.5
2.0
1.5
1.0
0.5
0
0
100 200 300 400
IF-Forward Current(mA)
LUMINOUS FLUX Vs.
AMBIENT TEMPERATURE
2.5
2.0
1.5
1.0
0.5
0
-40 -20 0
20 40 60 80 100
Ambient Temperature TA(
℃
)
LUMINOUS FLUX Vs.
FORWARD CURRENT
Page 5 of 6
