BCD DECADE/MODULO
16 BINARY SYNCHRONOUS
BI-DIRECTIONAL COUNTERS
The SN54 / 74LS168 and SN54 / 74LS169 are fully synchronous 4-stage
up/down counters featuring a preset capability for programmable operation,
carry lookahead for easy cascading and a U / D input to control the direction
of counting. The SN54 / 74LS168 counts in a BCD decade (8, 4, 2, 1)
sequence, while the SN54 / 74LS169 operates in a Modulo 16 binary
sequence. All state changes, whether in counting or parallel loading, are
initiated by the LOW-to-HIGH transition of the clock.
SN54/74LS168
SN54/74LS169
BCD DECADE / MODULO
16 BINARY SYNCHRONOUS
BI-DIRECTIONAL COUNTERS
LOW POWER SCHOTTKY
•
•
•
•
•
•
•
Low Power Dissipation 100 mW Typical
High-Speed Count Frequency 30 MHz Typical
Fully Synchronous Operation
Full Carry Lookahead for Easy Cascading
Single Up / Down Control Input
Positive Edge-Trigger Operation
Input Clamp Diodes Limit High-Speed Termination Effects
J SUFFIX
CERAMIC
CASE 620-09
16
1
CONNECTION DIAGRAM DIP
(TOP VIEW)
VCC
16
TC
15
Q0
14
Q1
13
Q2
12
Q3
11
CET
10
PE
9
NOTE:
The Flatpak version
has the same pinouts
(Connection Diagram) as
the Dual In-Line Package.
16
1
N SUFFIX
PLASTIC
CASE 648-08
16
1
D SUFFIX
SOIC
CASE 751B-03
1
U/D
2
CP
3
P0
4
P1
5
P2
6
P3
8
7
CEP GND
ORDERING INFORMATION
SN54LSXXXJ
SN74LSXXXN
SN74LSXXXD
Ceramic
Plastic
SOIC
PIN NAMES
LOADING
(Note a)
HIGH
LOW
0.25 U.L.
0.5 U.L.
0.25 U.L.
0.25 U.L.
0.25 U.L.
0.25 U.L.
5 (2.5) U.L.
5 (2.5) U.L.
CEP
CET
CP
PE
U/D
P0–P3
Q0–Q3
TC
Count Enable Parallel (Active LOW) Input
Count Enable Trickle (Active LOW) Input
Clock Pulse (Active positive going edge) Input
Parallel Enable (Active LOW) Input
Up-Down Count Control Input
Parallel Data Inputs
Flip-Flop Outputs
Terminal Count (Active LOW) Output
0.5 U.L.
1.0 U.L.
0.5 U.L.
0.5 U.L.
0.5 U.L.
0.5 U.L.
10 U.L.
10 U.L.
LOGIC SYMBOL
9
3
4
5
6
NOTES:
a. 1 TTL Unit Load (U.L.) = 40
µA
HIGH/1.6 mA LOW.
b. The Output LOW drive factor is 2.5 U.L. for Military (54) and 5 U.L. for Commercial (74)
b.
Temperature Ranges.
1
7
10
2
PE P0 P1 P2 P3
U/D
CEP
TC
CET
CP
Q0 Q1 Q2 Q3
15
14 13 12 11
VCC = PIN 16
GND = PIN 8
FAST AND LS TTL DATA
5-1
SN54/74LS168
•
SN54/74LS169
DC CHARACTERISTICS OVER OPERATING TEMPERATURE RANGE
(unless otherwise specified)
Limits
Symbol
S b l
VIH
VIL
VIK
VOH
Parameter
P
Input HIGH Voltage
54
Input LOW Voltage
74
Input Clamp Diode Voltage
54
Output HIGH Voltage
74
54, 74
VOL
Output LOW Voltage
74
Input HIGH Current
Other Inputs
CET Input
Other Input
CET Input
IIL
IOS
ICC
Input LOW Current
Other Input
CET Input
Short Circuit Current (Note 1)
Power Supply Current
– 20
0.35
0.5
20
40
0.1
0.2
– 0.4
– 0.8
– 100
34
V
µA
2.7
3.5
0.25
0.4
V
V
2.5
– 0.65
3.5
0.8
– 1.5
V
V
Min
2.0
0.7
V
Typ
Max
Unit
U i
V
Test C di i
T
Conditions
Guaranteed Input HIGH Voltage for
All Inputs
Guaranteed Input LOW Voltage for
p
g
All Inputs
VCC = MIN, IIN = – 18 mA
,
,
VCC = MIN, IOH = MAX, VIN = VIH
or VIL per Truth Table
IOL = 4.0 mA
IOL = 8.0 mA
VCC = VCC MIN,
VIN = VIL or VIH
per Truth Table
VCC = MAX, VIN = 2.7 V
IIH
mA
VCC = MAX, VIN = 7.0 V
mA
mA
mA
VCC = MAX, VIN = 0.4 V
VCC = MAX
VCC = MAX
Note 1: Not more than one output should be shorted at one time, nor for more than 1 second.
FUNCTIONAL DESCRIPTION
The SN54/74LS168 and SN54/74LS169 use edge-
triggered D-type flip-flops that have no constraints on
changing the control or data input signals in either state of the
Clock. The only requirement is that the various inputs attain
the desired state at least a set-up time before the rising edge of
the clock and remain valid for the recommended hold time
thereafter.
The parallel load operation takes precedence over the other
operations, as indicated in the Mode Select Table. When PE is
LOW, the data on the P0 – P3 inputs enters the flip-flops on the
next rising edge of the Clock. In order for counting to occur,
both CEP and CET must be LOW and PE must be HIGH. The
U/D input then determines the direction of counting.
The Terminal Count (TC) output is normally HIGH and goes
LOW, provided that CET is LOW, when a counter reaches zero
in the COUNT DOWN mode or reaches 15 (9 for the
SN54/74LS168) in the COUNT UP mode. The TC output state
is not a function of the Count Enable Parallel (CEP) input level.
The TC output of the SN54/74LS168 decade counter can also
be LOW in the illegal states 11, 13 and 15, which can occur
when power is turned on or via parallel loading. If illegal state
occurs, the SN54/74LS168 will return to the legitimate
sequence within two counts. Since the TC signal is derived by
decoding the flip-flop states, there exists the possibility of
decoding spikes on TC. For this reason the use of TC as a
clock signal is not recommended.
MODE SELECT TABLE
PE
L
H
H
H
H
CEP
X
L
L
H
X
CET
X
L
L
X
H
U/D
X
H
L
X
X
Action on Rising Clock Edge
Load (Pn
→
Qn)
Count Up (increment)
Count Down (decrement)
No Change (Hold)
No Change (Hold)
H = HIGH Voltage Level
L = LOW Voltage Level
X = Immaterial
FAST AND LS TTL DATA
5-4
