NOTES: UNLESS OTHERWISE SPECIFIED
1. INTERPRET DRAWING IN ACCORDANCE WITH ASME Y14.5-1994.
2
PART SUPPLIED ON A CONTINUOUS REEL AS SHOWN,
25,000
±15%
PINS PER REEL. FEEDER COMPATIBLE SPLICES
PERMITTED, 2 SPLICES MAX PER REEL.
3
COMPLIANT TIPS ARE BARE AT CUT-OFF.
4. .010 [0.25] MAX RADII AND FILLET.
5. ASSEMBLY DIMENSIONS ARE MEASURED IN A RESTRAINED
STATE.
3
2
REV
REVISION RECORD
1
ECN
BY
APVD
DATE
A RELEASED PER EWR 102133
B REVISED PER EWR 104801
502716 Pete PVB
504295 BILL PVB
04/28/03
01/06/06
F
PART NO. / ORDERING CODE
23-1040 R 00
AA
FINISH
.000040”-.000120” [1.02-3.05 MICRONS]
TIN/LEAD (90/10) OVER .000050”
[1.27 MICRONS] MIN. NICKEL
DIMENSIONS
F
.100
NO OF POSITIONS x
[2.54]
TOTAL TOLERANCE = +.013/-.026
[+0.33/-0.66]
.05
1.3
TYP
25° REF
.025
0.64
.050
1.27
REF
REF
TYPE
1 ROW .100 [2.54]
CENTERS
RECT. PIN COMPLIANT
.025 X .0394
[0.64]
[1.000]
TOTAL NO. OF POS.
6
7
HEADER SIZES CUT FROM A REEL ARE PACKAGED IN BULK.
CONSULT AUTOSPLICE FOR INSERTION TOOLING.
E
8. RECOMMENDED .062” THICK PC BOARD HOLE:
DRILLED HOLE – Ø .0453±.0010 [Ø 1.151±0.025]
COPPER PLATED – Ø .0410±.0020 [Ø 1.041±0.051]
(HASL) TIN/LEAD PLATED – Ø .040±.003 [1.02±0.08]
DRILLED HOLE – Ø .0453±.0010 [Ø 1.151±0.025]
COPPER PLATED – Ø .0410±.0020 [Ø 1.041±0.051]
NICKEL PLATED – Ø .040±.002 [1.02±0.08]
GOLD PLATED – Ø .040±.002 [1.02±0.05]
DRILLED HOLE – Ø .0453±.0010 [Ø 1.151±0.025]
COPPER PLATED – Ø .0413±.0020 [Ø 1.041±0.051]
SILVER PLATED – Ø .040±.002 [1.02±0.05]
CODE
A1
A2
A3
Z
.419 [10.65]
.437 [11.10]
.531 [13.50]
E
2
.095 ±.005
2.41 ±0.13
.045
1.13
REF
1
.0394 ±.0020
1.00 ±0.05
.032 ±.006
0.80 ±0.15
7
00 = CONTINUOUS REEL
CUT HEADER SIZES:
2 TO 20 POSITIONS
BULK PACKAGED IN POLYBAG
POS. = QTY
2 = 4,000±15%
4 = 2,000±15%
ADDITIONAL PIN SIZES & LENGTHS UP TO
“Z”= 1.575 [40.00] CAN BE MADE UPON REQUEST
D
D
.010 ±.002
0.25 ±0.05
.006
0.15
MAX
A
R
.006
0.15
A
.024
0.60
.0250 ±.0008
0.64 ±0.02
C
1
2
MATERIAL:
INSULATOR:
GLASS FILLED
THERMOPLASTIC POLYESTER,
FLAMMABILITY RATED: UL 94HB
COLOR: BLACK
C
SECTION A-A
SCALE : 20:1
Z
.125
3.18
2
PIN:
COPPER ALLOY
FINISH:
SEE PART NO. / ORDERING CODE
B
AP/2 REEL
(24" O.D. X 20" I.D.)
.100
2.54
.120 INSTALLED
[3.04]
7
B
.047 ±.002
1.19 ±0.05
.149
3.78
MAX
CUSTOMER DRAWING
A
2
UNWIND
DIRECTION
.100 ±.002
2.54 ±0.05
INSULATOR PITCH
.015
0.38
3
.012
0.30
The drawing and the information
set forth hereon are the property
of Autosplice, Inc. and are to be
held in trust and confidence.
Publication, disclosure, or use for
any purpose not expressly
authorizing in writing by
Autosplice, Inc. is prohibited.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES
[mm]
TOLERANCES
C
DECIMAL :
THIRD ANGLE PROJECTION
DRAWN BY
ENGINEERED BY
Autosplice, Inc.
10121 Barnes Canyon Rd.
San Diego, CA 92121-2725
858-535-0077
DATE
DATE
A
REELED HEADER ORIENTION
.XX = ± .01
[X.X] ±[0.3]
.XXX = ± .004
[X.XX] ±[0.10]
± 5°
Pete
5-17-02
5-17-02
PVB
TITLE
ANGULAR :
AUTOHEADER , 1 ROW, .100 [2.54] CTRS
C
8:1
FSCM NO.
TM
SIZE
DENOTES SPECIAL
CHARACTERISTIC
OAE89
DRAWING NUMBER
C23-1040[][][][][][][]
MODEL N0.
REVISION
SCALE
CAD N0.
23-1040.dft
23-1040.asm
SHEET
1
B
OF
1
4
3
2
1
