ALUMINUM ELECTROLYTIC CAPACITORS
FX2 Series
(Warranty of 5,000 hours at 85°C)
Product Specifications
Features
• Developed specially for the demand of higher voltage with compact
size.
• The size is reduced by around 14% of conventional FXA type
through development of electrolyte liquid.
• 500V and 550V added in the series.
Items
Specifications
Temperature range
−40℃∼＋85℃
Capacitance tolerance
±20％（20℃,120Hz）
Rated voltage
400∼550V.DC
0.01 CV (μA) or 5 mA, whichever is smaller or less
Leakage current
[C = nominal capacitance (μF), V = rated voltage (V)]
400, 450 V DC ... 0.15 or less (20℃, 120 Hz)
500, 550 V DC ... 0.20 or less (20℃, 120 Hz)
Permissible ripple current
As per the following "Standard value and case size". (85℃, 120 Hz)
Dissipation factor
After the rated voltage (specified ripple current convolution) is applied at 85℃ for 5000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
Others
JIS C 5101-4.
Ripple current correction coefficient
Temperature (°C)
Correction coefficient
Frequency (Hz)
Correction coefficient
40
1.89
50/60
0.7
60
1.67
120
1.0
85
1.00
300
1.1
1K
1.3
≧10K
1.4
Ripple current should be under 60Arms at M5 (100Arms at M6 for G case)
in accordance with from the permissible current.
120Arms (M8 terminal, case code "G")
Product code : (Example) FX2 type 400V 10,000μF±20％
FX2
2G 103
Y
(
E
)
E case φD 77mm）
（ ：
product
Type name
Case code (*)
Type of bracket
Capacitance code
Rated voltage code
* ( ), case code: Put the first English letter of case code into ( ) in case
there are two case sizes in the same CV value.
Standard value and case size
Capacitance
μF
Code
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
C12R
C13R
D10R
D12R
D13R
E12R
E13R
E16R
E20R
F13R
F16R
F20R
F24R
G24R
8.8
10.2
11.0
12.8
14.8
16.2
18.7
22.0
26.7
24.2
28.5
34.8
41.2
47.0
F20R
G18R
F24R
G20R
G24R
29.7
29.3
35.9
34.2
40.5
Case code
Maximum ripple current (A)
at 85°C,120Hz
C12R
C13R
D10R
D12R
D13R
E12R
E13R
E16R
E20R
F13R
F17R
7.6
8.8
9.5
11.2
12.8
14.1
16.2
19.1
23.0
21.0
25.7
C12R
D10R
C13R
D10R
D12R
D13R
E12R
E13R
E16R
E17R
F13R
E20R
F16R
F17R
F20R
G18R
F24R
G20R
G24R
6.2
6.3
7.3
7.1
8.3
9.6
10.7
12.4
14.4
16.5
15.8
19.0
18.6
21.2
24.5
24.2
29.3
27.9
33.1
F24R
G24R
24.1
27.3
F20R
20.3
E12R
E13R
E16R
E16R
F16R
F17R
8.7
10.1
12.0
13.3
15.5
17.6
D13R
8.0
Rated voltage
V.DC (Code)
400
（2G）
450
（2W）
500
（2H）
C13R
D12R
550
（2L）
5.9
6.8
43
