UNISONIC TECHNOLOGIES CO., LTD
MJE3055T
HIGH VOLTAGE TRANSISTOR
DESCRIPTION
The UTC
MJE3055T
is designed for general purpose of
amplifier and switching applications.
NPN SILICON TRANSISTOR
Lead-free:
MJE3055TL
Halogen-free: MJE3055TG
ORDERING INFORMATION
Normal
MJE3055T-TA3-T
MJE3055T-TM3-T
MJE3055T-TN3-R
Ordering Number
Lead Free Plating
MJE3055TL-TA3-T
MJE3055TL-TM3-T
MJE3055TL-TN3-R
Halogen Free
MJE3055TG-TA3-T
MJE3055TG-TM3-T
MJE3055TG-TN3-R
Package
TO-220
TO-251
TO-252
Pin Assignment
1
2
3
B
C
E
B
C
E
B
C
E
Packing
Tube
Tube
Tape Reel
www.unisonic.com.tw
Copyright © 2009 Unisonic Technologies Co., Ltd
1 of 2
QW-R203-011.C
MJE3055T
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
SYMBOL
V
CBO
V
CEO
V
EBO
NPN SILICON TRANSISTOR
ABSOLUTE MAXIMUM RATINGS
(T
C
=25°С, unless otherwise specified)
RATINGS
UNIT
70
V
60
V
5
V
TO-220
75
W
Total Power Dissipation
P
D
TO-251/TO-252
20
W
Collector Current
I
C
10
A
Base Current
I
B
6
A
Junction Temperature
T
J
150
°С
Storage Temperature
T
STG
-55 ~ +150
°С
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS
(Ta=25°С, unless otherwise specified)
SYMBOL
BV
CEO
BV
CBO
BV
EBO
I
CBO
Collector Cut-off Current
I
CEO
I
CEX
Emitter Cut-off Current
I
EBO
V
CE(SAT)1
Collector-Emitter Saturation Voltage (Note)
V
CE(SAT)2
Base-Emitter on Voltage
V
BE(ON)
h
FE1
DC Current Gain (Note)
h
FE2
Current Gain Bandwidth Product
f
T
Note: Pulse test: PW≤300μs, duty cycle≤2% Pulse
PARAMETER
Collector-Emitter Breakdown Voltage
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
TEST CONDITIONS
I
C
=200mA
I
C
=10mA
I
E
=10mA
V
CB
=70V
V
CE
=30V
V
CE
=70V, V
EB(OFF)
=1.5V
V
EB
=5V
I
C
=4A, I
B
=0.4A
I
C
=10A, I
B
=3.3A
V
CE
=4V, I
C
=4A
V
CE
=4V , I
C
=4A
V
CE
=4V , I
C
=10A
V
CE
=10V, I
C
=0.5A, f=1MHz
MIN
60
70
5
TYP
MAX UNIT
V
V
V
1
mA
700
μA
1
mA
5
mA
1.1
V
8
V
1.8
V
100
MHZ
20
5
2
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
