ALUMINUM ELECTROLYTIC CAPACITORS
PM
Item
Extremely Low Impedance, High Reliability
series
(through 100V only)
High reliability withstanding 5000 hour load life at +105
°C
(3000/2000 hours
for smaller case sizes as specified below).
Capacitance ranges available based on the numerical values in E12 series
under JIS.
Compliant to the RoHS directive (2002/95/EC).
PM
Smaller
Specifications
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
PW
Performance Characteristics
– 55 to +105°C (6.3 to 100V), –40 to +105°C (160 to 400V), –25 to +105°C (450V)
6.3 to 450V
0.47 to 15000µF
± 20% at 120Hz, 20°C
Rated Voltage (V)
6.3 to 100
Leakage current
160 to 450
After 1 minute's application of rated voltage, leakage current is not more CV < 1000 :
I
= 0.1CV+40 (µA) max. (1 minute's)
=
than 0.03CV or 4 (µA), whichever is greater.
CV > 1000 :
I
= 0.04CV+100 (µA) max. (1 minute's)
Measurement frequency : 120Hz, Temperature : 20°C
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Tangent of loss angle (tan
δ)
Rated Voltage (V)
tan
δ
(MAX.)
6.3
0.22
10
0.19
6.3 · 10
—
—
4
16
0.16
16
—
—
3
25
0.14
35
0.12
50
0.10
63 to 100 160 to 350 400 · 450
0.08
0.20
0.25
250
—
6
—
315 · 350
—
8
—
400
—
10
—
450
15
—
—
120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance
Z– 40°C / Z+20°C
ratio (MAX.)
Z– 55°C / Z+20°C
25 · 35 50 to 100 160 · 200
—
—
—
4
—
—
—
3
2
Capacitance change
tan
δ
Leakage current
Endurance
Shelf Life
Marking
The specifications listed at right shall be met when the
capacitors are restored to 20°C after D.C. bias plus rated
ripple current is applied for 5000 hours (2000 hours for
φD=5
and 6.3, 3000 hours for
φD=8)
at 105°C, the peak voltage
shall not exceed the rated voltage.
After storing the capacitors under no load at 105°C
for 1000 hours and then performing voltage treatment based
on JIS C 5101-4 clause 4.1 at 20°C, they shall meet the
characteristic requirements listed at right.
Printed with white color letter on dark brown sleeve.
1
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Capacitance change
tan
δ
Leakage current
Within ±20% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Radial Lead Type
Sleeve (P.E.T.)
Type numbering system (Example : 25V 470
µ
F)
2
3
4
5
6
7
8
9 10
11 12
UPM 1 E 4 7 1 M PD
φ
d
Configuration
φD
+
0.5
MAX.
Size code
Type
Small Dia
Low Profile
Code
6
Capacitance tolerance (±20%)
P
±
0.5
Rated capacitance (470µF)
Rated voltage (25V)
Series name
Pressure
relief vent
(φ6.3up)
Type
L
+
MAX.
15
MIN
4
MIN
Configuration
φ
D
Pb-free leadwire
Pb-free PET sleeve
(φD < 10) 1.5
(φD > 10) 2.0
=
(mm)
5
6.3
8 · 10
12.5 to 18
DD
ED
PD
HD
Frequency coefficient
15000
10000
6800
15000
4700
10000
3300
6800
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
Frequency coefficient of
rated ripple current
Rated voltage
Rated voltage
Frequency coefficient
In case L > 25 for the
φ12.5
dia. unit, lead dia.
φ
d = 0.8mm.
•
Please refer to page 20 about the end seal configulation.
2200
1500
1000
680
470
4700
3300
2200
1500
330
1000
6.3 to 100V
(10kHz to
200kHz=1)
220
150
680
470
330
220
150
100
120Hz
68
47
33
120Hz
22
0
300Hz
1kHz
6.3 to 100V
(10kHz to
200kHz=1)
Cap.(
µ
F)
100
68
47
33
Cap.(
µ
F)
22
15
10
0.68
0.47
300Hz
0.9
1kHz
1.0
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
15
0.5
10
0.6
0.7
0.8
Frequency coefficient
Dimension table in next page.
160 to 450V
50Hz
0.80
120Hz
0.68
1.00
0.47
0
0.5
300Hz
1.25
1kHz
1.40
110kHz or more
1.60
0.9
1.0
0.6
0.7
0.8
Frequency coefficient
CAT.8100Y
