F-218
SS–132–G–2
ESD–115–TT–05
(2.54 mm) .100"
SS, SD, ESD, ESS, HSS SERIES
PRECISION MACHINED SOCKET STRIPS
Mates with:
TS, TD, HTS, BBS,
BBD, BBL, BDL, BHS
TYPE
STRIP
1
NO. PINS
PER ROW
PLATING
OPTION
LEAD
STYLE
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?SS,
www.samtec.com?ESS,
www.samtec.com?SD,
www.samtec.com?ESD or
www.samtec.com?HSS
Insulator Material:
SS, SD, ESS, ESD=
Black G.F. Polyester
HSS=
Black Liquid Crystal Polymer
Contact:
BeCu
Shell:
Brass except Style 5A
Phosphor Bronze
Plating:
Au over 50 µ" (1.27 µm) Ni or
Sn over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C
Lead Size Range:
(0.38 mm to 0.56 mm)
.015" to .022" DIA
and most IC leads
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
01 thru 32
= SS, ESS Series
= HSS, SD & ESD Series
= 10 µ" (0.25 µm) Gold contact,
Tin shell
(Styles 2 & 22 only)
–S
–T
–L
Locking
=
Socket
–N
= Non
Flush
01 thru 36
Add –L suffix for locking
lead socket in end positions.
Requires
Style -2
or
-22
and
.035" ± .003 DIA board hole.
(0.76)
.030
REF
= 30 µ" (0.76 µm) Gold contact,
Tin shell
= Standard
= High Temp
Single Row Socket Single Row Socket
SS
HSS
= 30 µ" (0.76 µm) Gold contact,
10 µ" (0.25 µm) Gold shell
–G
(7.62)
.300
(3.43)
.135
Requires -T Plating Option
N/A Style –5A
= Elevated Single Row Socket
Styles – 5A & –05 socket
heads not countersunk.
(2.54) .100 x No. of Positions
(2.54)
.100
(2.54)
.100 TYP
(2.54)
.100
ESS
= Tin contact and shell
(Styles 1, 2, 4, and 05
except LIF N/A)
–TT
ALSO AVAILABLE
(MOQ Required)
• Locking lead option on ESS
and ESD series
Contact Samtec.
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
For LIF specify –21A, –21B or –21C
(SS, HSS, SD)
(1.83)
.072 DIA
(4.90)
.193
(1.32)
.052
DIA
Y
(0.64)
.025 SQ
–1A, –1B or –1C
–03, –04, –05
For LIF specify –23
(ESS, ESD)
FILE NO. E111594
(2.54) .100 x No. of Positions
(2.54)
.100
(0.76)
.030
LEAD STYLE
–1A or –21A
–1B or –21B
–1C or –21C
Y
(9.14)
.360
(12.95)
.510
(6.60)
.260
A
B
(0.76)
.030
=
(2.54)
Standard Double
(5.08)
.100
.200
Row Socket
SD
(2.54)
(2.54) .100 x No. of Positions
.100 TYP
= Elevated Double
(2.54)
Row Socket
.100
ESD
C
(2.54)
.100
Style –
(2.54)
not available.
5A
.100 TYP
Styles –5A & –05 socket
heads not countersunk.
(2.54) .100 x No. of Positions
*For LIF specify –22 or –38 (SS, HSS, SD)
(2.54)
.100
–2, –22*,–5A,
or –38*
LEAD
STYLE
Z
(0.64)
.025
SQ
(5.08)
.200
(2.54)
.100 TYP
(2.54)
.100
(1.83)
.072
DIA
(0.76)
.030
(1.32)
.052
DIA
DIA
X
Y
Z
LEAD
STYLE
–05
–03 or
–23
–04
A
B
C
–2 or –22
–38
–5A
Y
(0.51) (3.18) (7.62)
.020
.125
.300
(0.51) (4.57) (8.89)
.020
.180
.350
(0.89) (12.95) (17.86)
.035
.510
.703
(17.86) (13.46) (4.39)
.703
.530 .173
(11.51) (8.38) (3.12)
.453
.330 .123
(14.05) (10.92) (3.12)
.553
.430 .123
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
X
LIF= Low Insertion Force
Locking lead available. See OPTION.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
