SL
,
SLN
,
TSL
surface mount molded current sense resistors
resistors
EU
features
•
Surface mount type
•
Flameproof UL94V0 molded polymer case
•
Excellent dimension accuracy, mountability
and shock resistance
•
Low profile type available (TSL)
•
Marking: Black body color with white marking or laser marking
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
AEC-Q200 Qualified
dimensions and construction
L
W
b
t
c
Molded Resistive
Resin
Element
c
a
Electrode
Size
Code
SL07
(2010)
Dimensions
inches
(mm)
L
W
t
a
b
c
.197±.012 .098±.008 .067±.008 .079±.008 .047±.008 .035±.012
(5.0±0.3) (2.5±0.2) (1.7±0.2) (2.0±0.2) (0.9±0.2) (1.2±0.3)
.075±.008 .094±.008 .047±.008 .047±.012
(1.9±0.2) (2.4±0.2) (1.2±0.2) (1.2±0.3)
.098±.008 .197±.008 .067±.008 .102±.02
(2.5±0.2) (5.0±0.2) (1.7±0.2) (2.6±0.5)
.094±.008
(2.4±0.2)
.098±.008
(2.5±0.2)
.217±.008
(5.5±0.2)
.197±.008
(5.0±0.2)
.063±.008
(1.6±0.2)
.067±.008
(1.7±0.2)
.100±.016
(2.55±0.4)
.102±.02
(2.6±0.5)
SL1/SLZ1
.248±.012 .122±.008
(6.3±0.3) (3.1±0.2)
(2512)
.453±.012 .276±.008
SL2
(11.5±0.3) (7.0±0.2)
(4528)
SLN2
(4528)
SL3
(4528)
TSL1
(2512)
.453±.012
(11.5±0.3)
.453±.012
(11.5±0.3)
.276±.008
(7.0±0.2)
.276±.008
(7.0±0.2)
.248±.012 .122±.008 .039±.008 .094±.008 .028±.008 .047±.012
(6.3±0.3) (3.1±0.2) (1.0±0.2) (2.4±0.2) (0.7±0.2) (1.2±0.3)
ordering information
New Part #
SL
Type
SL
SLN
SLZ
TSL
1
Size
07: 0.75W
1: 1W
2: 2W
3: 3W
T
Termination
Material
T: Sn
L: SnPb (SL1,
SL2, SL3, SLZ,
TSL only)
TE
Packaging
SL07, SL1, SLZ1, TSL-
(TE: 7" embossed plastic)
SL2, SLN2, SL3-
TE: 10" embossed plastic
For further information on
packaging please refer to
Appendix A
20L0
Nominal
Resistance
±2%, ±5%: 2 significant figures
+ 1 multiplier “R” indicates decimal
on value <10Ω
±0.5%, ±1%: 3 significant figures
+ 1 multiplier “R” indicates decimal
on value <100Ω
All values less than 0.1Ω (100mΩ)
are expressed in mΩ with “L”
as decimal
Example: 20mΩ, 1% = 20L0
F
Tolerance
D: ±0.5%
F: ±1%
G: ±2%
J: ±5%
applications and ratings
Part
Designation
Power
Rating
T.C.R.
(ppm/°C)
Max.***
0~200: R=<10mΩ
0~150: R=>11mΩ
Resistance
Range
Resistance
Tolerance
E-24*
(F: ±1%)
(J: ±5%)
(D: ±0.5%)
(F: ±1%)
(G: ±2%)
(J: ±5%)
Absolute
Maximum
Working
Voltage
––
Absolute
Maximum
Overload
Voltage
––
-55°C to +180°C
200V
400V
Operating
Temperature
Range
SL07
0.75W
5mΩ - 100mΩ
10mΩ - 1MΩ
5mΩ - 1MΩ
3mΩ, 4mΩ
3mΩ ~ 22MΩ
SL1
1W
±180: R=<13mΩ
±100: R=>15mΩ
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/17/13
50
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
surface mount molded current sense resistors
applications and ratings
(continued)
Part
Designation
Power
Rating
T.C.R.
(ppm/°C)
Max.***
±180: R=<10mΩ
±100: R=>11mΩ
Resistance
Range
10mΩ - 1MΩ
5mΩ ~ 1MΩ
3mΩ, 4mΩ
3mΩ - 22MΩ
5mΩ - 200mΩ
10mΩ - 100mΩ
SL3
3W
±180: R=<10mΩ
±100: R=>11mΩ
4000 Max.
±180: R=<13mΩ
±100: R=>15mΩ
5mΩ - 100mΩ
0.5mΩ Max.
10mΩ - 100mΩ
TSL1
1W
5mΩ - 100mΩ
Resistance
Tolerance
E-24*
(D: ±0.5%)
(F: ±1%)
(G: ±2%)
(J: ±5%)
(D: ±0.5%)
(F: ±1%)
(J: ±5%)
(D: ±0.5%)
(F: ±1%)
(J: ±5%)
––
(D: ±0.5%)
(F: ±1%)
(J: ±5%)
––
––
––
––
––
––
Absolute
Maximum
Working
Voltage
500V
Absolute
Maximum
Overload
Voltage
1000V
Operating
Temperature
Range
SL2
2W
SLN2
2W
±110: R<10mΩ
±75: R=>10mΩ
––
––
-55°C to +180°C
SLZ1**
––
* 3m, 4m, 5m, 6m, 7m, 8m, 9m resistance values also available
** SLZ1: Current rating: 44A
*** Please contact factory for T.C.R.: ±50ppm/°C
environmental applications
Derating Curve
Surface Temperature Rise
100
200
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
SL2 (2)
SL1/SL2
150
125
Temperature Rise
(°C)
100
75
175
Temperature Rise
(°C)
150
TSL1/SLN2
SLN2 (2)
TSL1 (2)
2
SLN2 (1)
TSL1 (1)
1
125
SL1 (2)
SL2 (1)
SL1 (1)
* 33mΩ
10mm pattern
100
75
50
25
0
0
25
50
75
50
25
0
* TSL1: 20mΩ
SLN2: 110mΩ
10mm pattern
0
20 40 60 80 100 120 140 160 180
70
Ambient Temperature
(°C)
100
0
25
50
75
100
For resistors operated at an ambient temperature of 70°C
or above, a power rating shall be derated in accordance
with the above derating curve.
% Rated Power
% Rated Power
Regarding the temperature rise, the value of the temperature varies per conditions and
board for use since the temperature is measured under our measuring conditions.
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload
(Short time)
Resistance
to Solder Heat
Rapid Change
of Temperature
Moisture
Resistance
Endurance at 70°C
Low Temperature Exposure
Requirement
∆
R ±%
Limit
Typical
Within specified
—
tolerance
Within specified
—
T.C.R.
SL07, TSL1,SL1, SL07, TSL1,SL1,
SL2: ±1%
SL2: ±1%
SLN2: ±0.5%
SLN2: ±0.25%
SL07, TSL1,SL1, SL07, TSL1,SL1,
SL2: ±1%
SL2: ±1%
SLN2: ±0.5%
SLN2: ±0.5%
SL07, TSL1,SL1, SL07, TSL1,SL1,
SL2: ±1%
SL2: ±0.5%
SLN2: ±0.5%
SLN2: ±0.25%
SL07, TSL1,SL1, SL07, TSL1,SL1,
SL2: ±2%
SL2: ±0.5%
SLN2: ±0.5%
SLN2: ±0.25%
SL07, TSL1,SL1,
SL2: ±2%
±0.5%
SLN2: ±1%
±0.5%
±0.25%
Test Method
25°C
+25°C/+125°C
SL07: Rated power x 4 for 5 seconds, TSL1: Rated power x 2.5 for 5 seconds,
SL1, SL2, SLN2: Rated power x 5 for 5 seconds,
260°C ± 5°C, 10 ± 1 second
260°C ± 5°C, 10~12 seconds
-55°C (30 minutes), +150°C (30 minutes), 100 cycles
-55°C (15 minutes), +150°C (15 minutes), 1000 cycles
40°C ± 2°C, 90%~95%RH, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
85°C ± 2°C, 85% ±3%RH, 1000 hours, Rated power x 0.1
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
SL07, TSL1, SL1, SL2: -55°C, 1 hour; SLN2: -65°C, 24 hours
12/17/12
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
51
