Ordering number : ENA1771B
SMA4306
SANYO Semiconductors
DATA SHEET
SMA4306
Features
•
•
•
Si Monolithic Linear IC
Oscillator IC for Laser Diode
Noise Suppression Applications
Frequency specification with LC : Added LC sets the operating frequency
Ultra small package : 1.6×1.6×0.56mm
Halogen free compliance
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Supply Voltage
Circuit Current
Power Dissipation
Operating Temperature
Storage Temperature
Symbol
VCC
ICC
PD
Topr
Tstg
Conditions
Ratings
6
50
280
-
-40 to +85
--55 to +150
Unit
V
mA
mW
°C
°C
Package Dimensions
unit : mm (typ)
7028-008
1.6
0.05
0.2
Product & Package Information
• Package
: SCH6
• JEITA, JEDEC
: SOT-563
• Minimum Packing Quantity : 5,000 pcs./reel
SMA4306-TL-H
0.2
Packing Type : TL
Marking
LOT No.
LOT No.
6 5 4
GU
1.6
1.5
0.05
1
0.56
2 3
0.5
TL
1 : VCC
2 : GND
3 : LC
4 : NC
5 : GND
6 : OUT
SANYO : SCH6
0.25
http://semicon.sanyo.com/en/network
70412 TKIM/30911 TKIM/22311AM TKIM TC-00002575 No. A1771-1/6
SMA4306
Recommended Operating Conditions
at Ta=25°C
Parameter
Supply Voltage
Symbol
VCC
Conditions
Ratings
min
3
typ
5
max
5.5
Unit
V
Electrical Characteristics
at Ta=25°C
Parameter
Circuit Current
Oscillating Power
Torerance of Oscillating Frequency
Symbol
ICC
Posc
fmod
Conditions
VCC=5V, RL=50Ω, fosc=400MHz
VCC=5V, RL=50Ω,
Specified Test Circuit (L=47nH, C=10pF)
Ratings
min
29
4.5
--10
typ
34
6.4
max
39
8.5
10
Unit
mA
dBm
%
Note 1 : Oscillation frequency mainly depends on the external LC (The LC is attached additionally to the LC terminal in series).
Note 2 : Recommended oscillation frequency 350MHz to 450MHz .
Test Circuit
SMA4306
VCC
1000pF
47pF
RF
OUTPUT
GU
10pF
47nH
IT15713
Ordering Information
Device
SMA4306-TL-H
Package
SCH6
Shipping
5,000pcs./reel
memo
Pb Free and Halogen Free
45
40
ICC -- VCC
L=47nH
C=10pF
Oscillating Power , Posc -- dBm
10
8
6
4
2
0
--2
--4
--6
2.0
Posc -- VCC
L=47nH
C=10pF
Circuit Current, ICC -- mA
35
30
25
20
15
10
5
0
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
Supply Voltage, VCC -- V
IT16331
Supply Voltage, VCC -- V
IT16332
No. A1771-2/6
SMA4306
450
fosc -- VCC
Harmonic Power Level,
P
harmonic -- dBm
Oscillating Frequency , fosc -- MHz
440
430
420
410
400
390
380
370
360
350
2.0
2.5
3.0
3.5
4.0
4.5
5.0
L=47nH
C=10pF
10
0
--10
--20
--30
--40
--50
--60
Harmonics
VCC=5.0V
L=47nH
C=10pF
5.5
6.0
0
1
2
3
4
5
6
7
8
9
10
Supply Voltage, VCC -- V
10
9
IT16333
400
Posc -- Temp.
fosc -- Temp.
L=47nH
C=10pF
VCC=3.0V
Harmonic
IT16334
Oscillating Power , Posc -- dBm
8
7
6
5
4
3
2
1
0
--40
--20
VC
C
=5.0
V
Oscillating Frequency , fosc -- MHz
L=47nH
C=10pF
398
396
394
392
390
388
386
384
382
380
--40
--20
0
20
40
60
4.0V
4.0V
5.0V
3.0V
0
20
40
60
80
100
IT16335
80
100
IT16336
Temperature, Temp. --
°C
10
9
8
7
6
5
4
3
2
1
0
--1
--2
--3
--4
1.0
2
3
5
7
10
2
3
5
Posc -- L
Temperature, Temp. --
°C
1100
fosc -- L
C=10pF
VCC=5.0V
Oscillating Frequency , fosc -- MHz
C=10pF
VCC=5.0V
1000
900
800
Oscillating Power , Posc -- dBm
3.0V
3.0V
700
600
500
400
300
200
1.0
2
3
5
7
2
3
5
7 100
IT16350
Inductance, L -- nH
100
IT16349
7
10
Inductance, L -- nH
No. A1771-3/6
SMA4306
Taping Specification
SMA4306-TL-H
No. A1771-4/6
SMA4306
Outline Drawing
SMA4306-TL-H
Mass (g) Unit
0.004 mm
* For reference
Land Pattern Example
Unit: mm
0.3
0.4
1.4
0.5 0.5
No. A1771-5/6
