LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
LSU
LSU
SERIES
85℃ 5000 hours, Screw Terminal Type
◆FEATURES
・
Load Life : 85℃ 5000 hours.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−25∼＋85℃
350∼500V.DC
±20％
（20℃，
120Hz）
WV φD
350∼450
500
51
0.20
0.25
64
0.25
0.30
77
0.25
0.30
90
0.25
0.30
(tanδ)
Dissipation Factor(MAX)
(
20℃,
)
120Hz
I＝3
CV or 5mA whichever is smaller.(After 5 minutes application of rated voltage)
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(V)
After applying rated voltage with rated ripple current for 5000 hours at 85℃,
the capacitors shall meet the following requirements.
Capacitance Change
Within ±20％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
Endurance
Dissipation Factor
Leakage Current
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency Coefficient
Frequency
（Hz）
Coefficient
350∼450WV
500WV
60
0.80
0.80
120
1.00
1.00
300
1.17
1.15
500
1.23
1.20
1k
1.30
1.25
10k≦
1.40
1.30
◆PART NUMBER
□□□
Rated Voltage
LSU
Series
□□□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Clamp Code
D×L
Case Size
◆Dimensions in mm (not to scale)
〈I type〉
Plate
Mounting
Clamp
Case
Sleeve
Screw
Terminal Bolt
W4
W2±2
Clamp
Bolt
W3
〈Y type〉
Vent
Plate
W1±2
Mounting
Clamp
Sleeve
Case Screw
Terminal
Bolt
Vent
Clamp
Bolt
W3
W4
W2±2
W1±2
D±2
D±2
F±1
F±1
M5 P=0.8Bolt
L±3
W5
M5 P=0.8Bolt
L±3
Y type
I type
W5
φD
51
64
77
90
51
64
77
90
W1
34.0
40.0
47.0
54.0
32.5
38.0
44.5
50.8
W2
40.0
45.0
53.0
60.0
37.5
43.0
49.0
56.0
W3
3.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
W4
6.0
7.0
6.0
6.0
6.0
8.0
7.0
8.0
W5
12
12
12
14
12
14
14
16
(mm)
F
21.8
28.2
31.4
31.4
21.8
28.2
31.4
31.4
LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
LSU
※
Please refer to page 149 about recommended tightening torque and permissible current of terminal.
◆STANDARD SIZE
WV
（V.DC）
Cap μF）
（
350V
400V
51×98
51×98
6.9
7.7
8.6
9.5
11.5
12.7
13.8
15.8
15.4
17.5
19.2
22.9
21.4
25.4
27.9
31.5
35.8
38.9
450V
6.5
7.4
8.3
10.1
11.3
12.5
15.3
17.0
18.1
17.4
19.2
21.0
25.1
27.9
30.0
500V
51×98
51×118
51×148
64×119
64×139
64×149
77×131
77×151
90×121
90×131
77×191
90×151
90×191
90×221
90×241
5.6
6.3
7.1
8.5
9.6
10.5
13.3
14.8
17.8
19.5
18.1
21.7
24.5
27.4
30.1
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
51×98
51×118
51×138
51×148
64×119
64×139
77×121
64×189
77×141
77×151
90×121
77×191
90×141
90×191
90×191
90×221
7.8
8.7
9.8
10.8
12.9
14.3
17.8
17.7
19.8
21.8
25.8
24.6
28.8
30.6
36.2
40.1
51×118
51×138
64×119
64×139
64×149
77×121
77×141
90×121
77×151
77×191
90×141
90×191
90×221
90×241
51×118
51×138
51×148
64×119
64×139
64×149
77×121
64×189
77×141
77×151
90×121
77×191
90×141
90×151
90×191
90×221
90×241
Ripple Current (A r.m.s./120Hz, 85℃)
Case Size φD×L(mm)
