SS22 THRU SS210
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Reverse Voltage - 20 to 100 V
Forward Current - 2 A
Features
• The plastic package carries UL Flammability Classi-
fication 94V-0
• Metal silicon junction, majority carrier conduction
• Low power loss, high efficiency
• High forward surge current capability
• Built-in strain relief, ideal for automated placement
Mechanical Data
• Case: JEDEC DO-214AA molded plastic body
• Terminal: Leads solderable per MIL-STD-750,
Method 2026
• Polarity: Color band denotes cathode end
• Mounting Position: Any
Maximum Ratings and Electrical Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified. Single phase half-wave 60 Hz, resistive or
inductive load, for capacitive load current derate by 20%.
Parameter
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current 8.3 ms Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage at 2 A
Maximum DC Reverse Current at Rated
T
A
= 25
O
C
DC Blocking Voltage
T
A
= 100
O
C
Typical Junction Capacitance
Typical Thermal Resistance
2)
1)
Symbols
SS22 SS23 SS24 SS25 SS26 SS28 SS210
Unit
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
R
θJA
T
J
T
S
-65 to +125
0.55
20
14
20
30
21
30
40
28
40
50
35
50
2
50
0.7
0.5
20
220
75
-65 to +150
-65 to +150
10
180
O
60
42
60
80
56
80
100
70
100
V
V
V
A
A
0.85
V
mA
pF
C/W
O
Operating Junction Temperature Range
Storage Temperature Range
1)
C
C
O
2)
Measured at 1 MHz and applied reverse voltage of 4 VDC.
P.C.B mounted with 0.2 X 0.2"(5 X 5 mm) copper pad areas.
