0805 POWER INDUCTORS
Power Inductor for Critical Applications
ST336PHA
■
Shielded power inductors
■
Excellent current handling for a part this size; low DCR
Core material
Ceramic/Ferrite
Terminations
Silver-palladium-platinum-glass frit. Other termina-
tions available at additional cost.
Weight
57.6 – 62.4 mg
Ambient temperature
–40°C to +65°C with
Irms
current, +65°C to
+105°C with derated current
Storage temperature
Component: –55°C to +105°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +250 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Packaging
1500/7″reel; 7500/13″ reel Plastic tape: 8 mm wide,
0.23 mm thick, 4 mm pocket spacing, 2.34 mm pocket depth
L
2
±10% Q min
3
(µH) at 1 MHz
1.0
21
1.5
21
2.7
21
3.3
21
3.9
21
4.7
21
5.6
21
6.8
21
10
21
15
21
22
25
33
25
47
25
68
28
82
30
100
32
120
32
150
32
220
32
330
32
DCR
4
SRF
5
max
typ
(Ohms) (MHz)
0.14 340
0.18 265
0.35 190
0.50 180
0.74 165
0.85 155
0.91 143
1.37 118
1.51
66
2.04
34
2.48
22
3.00
17
3.85
15
4.42
12
6.00
12
6.96
9.0
7.51
7.7
8.33
5.0
13.71
5.0
20.53
3.5
Part
number
1
ST336PHA102KLZ
ST336PHA152KLZ
ST336PHA272KLZ
ST336PHA332KLZ
ST336PHA392KLZ
ST336PHA472KLZ
ST336PHA562KLZ
ST336PHA682KLZ
ST336PHA103KLZ
ST336PHA153KLZ
ST336PHA223KLZ
ST336PHA333KLZ
ST336PHA473KLZ
ST336PHA683KLZ
ST336PHA823KLZ
ST336PHA104KLZ
ST336PHA124KLZ
ST336PHA154KLZ
ST336PHA224KLZ
ST336PHA334KLZ
Isat
6
(A)
0.90
0.85
0.60
0.55
0.50
0.43
0.38
0.32
0.27
0.22
0.18
0.16
0.15
0.12
0.11
0.10
0.10
0.08
0.07
0.06
Irms
7
(A)
1.6
1.3
0.88
0.70
0.61
0.59
0.57
0.46
0.43
0.34
0.33
0.28
0.26
0.24
0.21
0.19
0.18
0.18
0.14
0.11
1. When ordering, please specify
termination
and
testing
codes:
ST336PHA334KLZ
Termination: L
= RoHS compliant silver-palladium-platinum-glass
frit. Special order:
T
= RoHS tin-silver-copper
(95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Testing:
Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
2. Inductance measured at 100 kHz, 0.1 Vrms, using a Coilcraft SMD-A
fixture in Agilent/HP 4263B LCR meter.
3. Q measured on an Agilent/HP 4291 with an Agilent/HP 16193 test
fixture.
4. DCR measured on a micro-ohmmeter and a Coilcraft CCF840 test
fixture.
5. SRF measured using an Agilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
6. DC current at which the inductance drops 10% (typ) from its value
without current.
7. Current that causes a 40°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document ST265-1
Revised 03/04/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2011
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
0805 POWER INDUCTORS
Power Inductor for Critical Applications – ST336PHA
Typical L vs Frequency
1000
330 µH
100 µH
Typical L vs Current
1000
330 µH
100 µH
100
100
Inductance (µH)
10
10 µH
3.3 µH
1 µH
Inductance (µH)
10
10 µH
3.3 µH
1 µH
1
1
0.1
0.01
0.1
1
10
0.1
1
10
100
1000
Frequency (MHz)
Current (mA)
Typical Q vs Frequency
70
60
50
330 µH
Irms Derating
120
110
100
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120
Q factor
40
100 µH
30
20
10
0
0.1
1
1 µH
3.3 µH
10 µH
10
Frequency (MHz)
B
F
C
D
I
A
G
E
J
I
Ambient temperature (°C)
H
Terminal wraparound:
approx 0.010/0,25 both ends
Recommended
Suggested
Land
Land Pattern
Pattern
A
B
C
max max max
D
E
F
G
H
I
J
0.133 0.118 0.079 0.053 0.080 0.050 0.020 0.070 0.040 0.030 inches
3,38 3,00 2,00 1,35 2,03 1,27 0,51 1,78 1,02 0,76 mm
Note: Height dimension is before optional solder application. For maxi-
mum height including solder, add 0.006 in / 0,15 mm.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document ST265-2
25°C
Revised 03/04/11
