ST336RAA120GLZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> ST336RAA120GLZ

ST336RAA120GLZ: DescriptionChip Inductors for Critical Applications; CategoryPassive components inductor; File Size98KB，2 Pages; ManufacturerCOILCRAFT; Websitehttp://www.coilcraft.com/; Environmental Compliance

Download Datasheet Parametric View All

ST336RAA120GLZ Overview

Chip Inductors for Critical Applications

ST336RAA120GLZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	COILCRAFT
package instruction	0907
Reach Compliance Code	compliant
ECCN code	EAR99
uppercase and lowercase codes	0907
structure	Chip
core material	CERAMIC
DC Resistance	0.15 Ω
Nominal inductance(L)	0.012 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
Maximum operating temperature	140 °C
Minimum operating temperature	-40 °C
Package height	1.52 mm
Package length	2.29 mm
Package form	SMT
Package width	1.73 mm
method of packing	TR, Plastic, 7 Inch
Minimum quality factor (at nominal inductance)	46
Maximum rated current	0.6 A
self resonant frequency	3180 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Silver/Palladium/Platinum - with Glass frit
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	2%

Preview

Download Datasheet

View All

0805 CHIP INDUCTORS

Chip Inductors for Critical Applications

ST336RAA

The ST336RAA inductors provide exceptional Q values,

even at high frequencies. They have a ceramic body and

Inductance

(nH)

2.8 @

3.0 @

3.3 @

5.6 @

6.8 @

7.5 @

8.2 @

10 @

12 @

15 @

18 @

22 @

24 @

27 @

33 @

36 @

39 @

43 @

47 @

56 @

68 @

82 @

91 @

100 @

110 @

120 @

150 @

180 @

220 @

240 @

270 @

330 @

390 @

250 MHz

200 MHz

150 MHz

100 MHz

wire wound construction to provide the highest SRFs

available in 0805 size.

SRF min

(MHz)

5000

4760

4440

3840

3560

3460

3180

2560

2480

2080

1920

2060

1720

1520

1600

1440

1360

1280

1200

1060

1000

880

730

650

610

580

520

480

Part

number

Percent

tolerance

5,2

5,2,1

5,2

5,2,1

5,2

57 @

61 @

48 @

75 @

54 @

56 @

63 @

57 @

46 @

41 @

48 @

59 @

56 @

64 @

57 @

44 @

45 @

44 @

49 @

52 @

51 @

49 @

54 @

38 @

52 @

33 @

37 @

36 @

34 @

min

DCR max

(Ohms)

0.06

0.08

0.11

0.14

0.12

0.10

0.15

0.17

0.20

0.22

0.25

0.27

0.29

0.34

0.31

0.34

0.38

0.42

0.48

0.46

0.48

0.51

0.56

0.64

0.70

1.00

1.40

1.50

Imax

(mA)

800

600

500

470

460

440

400

390

380

340

330

270

260

230

210

Color

code

Gray

White

Black

Orange

Brown

Green

Red

Blue

Orange

Yellow

Green

Blue

Gray

Violet

Gray

Orange

White

Yellow

Black

Brown

Red

Orange

Black

Yellow

Brown

Green

Blue

Violet

Gray

Red

White

Black

Brown

ST336RAA020JLZ

ST336RAA3N0JLZ

ST336RAA030JLZ

ST336RAA050JLZ

ST336RAA060JLZ

ST336RAA070JLZ

ST336RAA080_LZ

ST336RAA100_LZ

ST336RAA120_LZ

ST336RAA150_LZ

ST336RAA180_LZ

ST336RAA220_LZ

ST336RAA240_LZ

ST336RAA270_LZ

ST336RAA330_LZ

ST336RAA360_LZ

ST336RAA390_LZ

ST336RAA430_LZ

ST336RAA470_LZ

ST336RAA560_LZ

ST336RAA680_LZ

ST336RAA820_LZ

ST336RAA910_LZ

ST336RAA101_LZ

ST336RAA111_LZ

ST336RAA121_LZ

ST336RAA151_LZ

ST336RAA181_LZ

ST336RAA221_LZ

ST336RAA241_LZ

ST336RAA271_LZ

ST336RAA331_LZ

ST336RAA391_LZ

1000 MHz

500 MHz

250 MHz

100 MHz

1. When ordering, specify

tolerance, termination

and

testing

codes:

ST336RAA821GLZ

Tolerance:

= 1%

= 2%

= 5%

Termination: L

= RoHS compliant silver-palladium-platinum glass frit.

Special order:

= Tin-lead (63/37) over silver-platinum-glass frit.

= Tin-silver-copper (95.5/4/0.5) over silver-platinum-

glass frit.

= Tin-lead (63/37) over tin over nickel over silver-

platinum-glass frit.

= Tin-silver-copper (95.5/4/0.5) over tin over nickel

over silver-platinum-glass frit.

Testing:

= COTS

= Screening per Coilcraft CP-SA-10001

2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/

HP 4286A impedance analyzer or equivalent with Coilcraft-provided cor-

relation pieces.

3. Q measured using an Agilent/HP 4291A with an Agilent/HP 16197A

test fixture or equivalents.

4. SRF measured on an Agilent 8753ES or equivalent with a Coilcraft

CCF1297 test fixture.

5. DCR measured on a Keithley micro-ohmmeter or equivalent and a

Coilcraft CCF858 test fixture.

6. Electrical specifications at 25°C.

Refer to Doc 362 “Soldering Surface Mount Components” before soldering.

Document ST100-1 Revised 11/06/12

1102 Silver Lake Road

Cary, IL 60013

Phone 800-981-0363

Fax 847-639-1508

Email cps@coilcraft.com

www.coilcraft-cps.com

This product may not be used in medical or high

risk applications without prior Coilcraft approval.

Specifications subject to change without notice.

Please check our web site for latest information.
