NRELX220M250V12.5X16F datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> capacitor> NRELX220M250V12.5X16F

Preview

NRELX220M250V12.5X16F: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 250V, 22uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size46KB，3 Pages; ManufacturerNIC Components Corp; Environmental Compliance

Download Datasheet Parametric View All

NRELX220M250V12.5X16F Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 250V, 22uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

NRELX220M250V12.5X16F Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	22 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	12.5 mm
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.32 mA
length	16 mm
Manufacturer's serial number	NRE-LX
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Radial
method of packing	Bulk
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	250 V
ripple current	156 mA
series	NRE-LX
surface mount	NO
Delta tangent	0.2
Terminal surface	Matte Tin (Sn)
Terminal pitch	5 mm
Terminal shape	WIRE

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

HIGH CV, RADIAL LEADS, POLARIZED

FEATURES

• EXTENDED VALUE AND HIGH VOLTAGE

• NEW REDUCED SIZES

CHARACTERISTICS

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

Max. Leakage Current @ 20°C

W.V. (Vdc)

S.V. (Vdc)

C<1,000µF

C=2,000µF

Max. Tan

δ

@ 120Hz/20°C

C=3,300µF

C=4,700µF

C=6,800µF

C=10,000µF

W.V. (Vdc)

Low Temperature Stability

Z-25°C/Z+20°C

Inpedance Ratio @ 120Hz

Z-40°C/Z+20°C

Load Life Test

at Rated W.V.

+85°C 2,000 Hours

6.3 ~ 250Vdc

4.7 ~ 10,000µF

-40 ~ +85°C

±20%(M)

6.3 ~ 50Vdc

0.01CV or 3µA

whichever is greater

after 2 minutes

6.3

10

16

25

8.0

13

20

32

0.26 0.22 0.18 0.16

0.28 0.24 0.20 0.18

0.30 0.26 0.22 0.20

0.32 0.28 0.24 0.22

0.36 0.32 0.28

-

0.44 0.40

-

6.3

10

16

25

6

4

3

12

10

8

6

Capacitance Change

Tan

δ

Leakage Current

CV<1,000µF

0.1CV + 40µA (1 min.)

.03CV + 15µA (5 min.)

35

44

0.14

0.16

0.18

-

35

2

4

50

63

0.12

014

-

50

2

3

NRE-LX Series

RoHS

Compliant

includes all homogeneous materials

*See Part Number System for Details

350 ~ 450Vdc

1.5 ~ 68µF

-25 ~ +85°C

CV>1,000µF

0.04CV + 100µA (1 min.)

0.02CV + 25µA (5 min.)

450

500

0.20

-

450

7

-

160

200

250

350

400

200

250

300

400

450

0.20

-

160

200

250

350

400

3

5

-

Within ±25% of initial measured value

Less than 200% of speciﬁed maximum value

Less than speciﬁed maximum value

STANDARD PRODUCT AND CASE SIZE TABLE D

φ

x L (mm)

Cap.

Code

(µF)

6.3

10

1.5

1R5

-

2.2

2R2

-

3.3

3R3

-

4.7

4R7

-

6.8

6R8

-

10

100

-

22

220

-

33

330

-

47

470

-

68

680

-

100

101

-

150

151

-

220

221

-

330

331

-

470

471

8x9

680

681

8x9

10x9

1,000 102

10x9

2,200 222 12.5x16 12.5x16

3,300 332 12.5x16 16x16

4,700 472

18x16

16x20

6,800 682

16x20

18x20

10,000 103

18x20

18x25

16

-

8x9

10x9

-

16x16

16x20

18x20

18x25

-

Working Voltage (Vdc)

25

35

50

160

200

250

350

400

450

-

8x9

-

8x9

10x9

-

8x9

10x9

-

8x9

10x9

-

8x9

10x9 12.5x16 12.5x16 12.5x16

-

10x9

10x9 12.5x16 12.5x16 16x16

-

12.5x16 16x16

18x16

16x20

-

12.5x16 12.5x16 16x16

18x16

16x20

18x20

-

12.5x16 16x16

18x16

16x20

18x20

18x25

-

16x16

18x16

16x20

18x25

-

8x9

16x20

18x20

-

8x9

10x9

18x20

18x25

-

8x9

10x9

-

18x25

-

10x9

-

10x9

-

12.5x16

-

12.5x16 12.5x16 16x16

-

12.5x16 16x16

16x20

-

16x20

18x20

18x25

-

18x20

18x25

-

18x25

-

®

Please review the notes on correct use, safety and precautions found on

pages T10

&

T11

of NIC’s

Electrolytic Capacitor catalog.

Also found at

www.niccomp.com/precautions

If in doubt or uncertainty, please review your speciﬁc application - process details with

NIC’s technical support personnel:

tpmg@niccomp.com

PRECAUTIONS

82

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com
