636-2001: DescriptionBoard Connector, 20 Contact(s), 2 Row(s), Female, 0.1 inch Pitch, IDC Terminal, Black Insulator, Socket; CategoryThe connector The connector; File Size66KB，1 Pages; ManufacturerThomas & Betts Corporation; Websitehttp://www.tnb.com/

Download Datasheet Parametric View All

636-2001 Overview

Board Connector, 20 Contact(s), 2 Row(s), Female, 0.1 inch Pitch, IDC Terminal, Black Insulator, Socket

636-2001 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	WITH STRAIN RELIEF
body width	0.24 inch
subject depth	0.661 inch
body length	1.177 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Filter function	NO
IEC compliance	NO
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED THERMOPLASTIC
MIL compliance	NO
Manufacturer's serial number	636
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
Plating thickness	15u inch
Rated current (signal)	1 A
Guideline	UL, CSA
reliability	COMMERCIAL
Termination type	IDC
Total number of contacts	20
UL Flammability Code	94V-0
Maximum wire diameter	26 AWG
Minimum wire diameter	28 AWG

Preview

Download Datasheet

View All

IDC Systems

Female Sockets

FEMALE SOCKET CONNECTOR

WITH 15µ INCHES GOLD

.100" x .100" CENTERS

LR92984

E60980

P

HYSICAL

P

ROPERTIES

I

NSULATION

M

ATERIAL

:

Glass filled thermoplastic

rated UL 94V-0

C

OLOR

:

Black

C

ONTACTS

:

Phosphor bronze 15µ inches minimum

gold over 50µ inches nickel in contact zone;

tin/lead over nickel in termination area

E

LECTRICAL

P

ROPERTIES

C

URRENT

R

ATING

:

1 Amp

I

NSULATION

R

ESISTANCE

:

>1 x 10

9

0hms @ 500 VDC

D

IELECTRIC

S

TRENGTH

:

> 1000 VRMS at sea level

E

NVIRONMENTAL

P

ROPERTIES

T

EMPERATURE

R

ATING

:

-55°C to 125°C

C

ABLE

R

EQUIREMENTS

See Page 116-128

M

ATING

C

ONNECTORS

H

EADERS

:

See pages 26-44

M

ALE

IDC:

See pages 47-49

A

CCESSORIES

P

OLARIZATION

page 15

KEY

,

PULL TAB

&

STRAIN RELIEF

:

See

A

PPLICATION

T

OOLING

H

AND

T

OOL

:

use Die

B

ENCH

P

RESS

(

MANUAL

):

use Platen

use Base Plate

B

ENCH

P

RESS

(

PNEUMATIC

):

use Platen

use Base Plate

779-2100

779-2151

779-3200

779-3130

779-3151

779-3500XT

779-3130

779-3151

Ordering Information

SOCKET

CONN.

636-1000

636-1200

636-1400

636-1600

636-2000

636-2400

636-2600

636-3000

636-3400

636-4000

636-5000

636-5600

636-6000

636-6400

CATALOG NUMBERS

SOCKET

POLARIZED

CONN. W/

SOCKET

SOCKET W/

STRAIN RELIEF

CONN.

STRAIN RELIEF

636-1001

636-1201

636-1401

636-1601

636-2001

636-2401

636-2601

636-3001

636-3401

636-4001

636-5001

636-5601

636-6001

636-6401

636-1030

636-1230

636-1430

636-1630

636-2030

636-2430

636-2630

636-3030

636-3430

636-4030

636-5030

636-5630

636-6030

636-6430

636-1041

636-1241

636-1441

636-1641

636-2041

636-2441

636-2641

636-3041

636-3441

636-4041

636-5041

636-5641

636-6041

636-6441

DIMENSIONS IN MM (INCHES)

NO.

OF

POS.

10

12

14

16

20

24

26

30

34

40

50

56

60

64

A

17.20 (.677)

19.74 (.777)

22.28 (.877)

24.81 (.977)

29.90 (1.177)

34.96 (1.377)

37.52 (1.477)

42.40 (1.677)

47.68 (1.877)

55.30 (2.177)

68.00 (2.677)

76.38 (2.977)

80.70 (3.177)

85.78 (3.377)

B

10.16 (.400)

12.70 (.500)

15.24 (.600)

17.78 (.700)

22.86 (.900)

27.94 (1.100)

30.48 (1.200)

35.56 (1.400)

40.64 (1.600)

48.26 (1.900)

60.95 (2.400)

68.56 (2.700)

73.66 (2.900)

78.74 (3.100)

C

3.20 (.126)

3.80 (.150)

Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312

Dimensions shown are for reference only. Dimensions are in millimeters (inches).
