Polyester
Film Capacitors
F
EATURES
•
•
High stability and reliability
Excellent environmental performance
Low ESR and minimized dissipation factor
TPEN
Series
(Axial Tubular)
MERITEK
•
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-40
o
C to +85
o
C
0.001μF to 0.47μF
±5%(J), ±10%(K), ±20%(M)
50VDC, 250VDC, 400VDC, 630VDC
0.8% max. at 1KHz, 25
o
C
>20000MΩ (C < 0.1μF)
<2000MΩ
μF
(C > 0.1μF)
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
TPEN
102
J
2E
TPEN
are constructed with polyester film
dielectric, aluminum foil electrodes, tinned copper
leads, and an outer wrapping of non-inductive
polyester film. Both ends are sealed using an epoxy
resin. TPEN are suitable for use in timing, delay,
and oscillation circuits. Ideal applications include
instruments for telecommunications, i.e. signal
coupling and decoupling.
ations
are
subject to change without notice.
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
Rated Voltage
CODE
1H
50V
2E
250V
2G
400V
2J
630V
Tape & Reel
/
Tape & Ammo available
for diameter
10 mm
or smaller
Please contact factory for part number
Dimensions in millimeters (mm)
Rated Voltage
DIM.
CAP(
μ
F)
0.0010
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
ØD
5.0
5.0
5.0
5.0
5.0
5.5
5.5
6.5
6.0
6.5
6.5
7.5
8.0
9.0
10.0
10.5
12.0
50VDC
L
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
18.0
18.0
21.0
21.0
24.0
24.0
27.0
33.0
33.0
dØ
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
ØD
5.0
5.0
5.0
5.0
5.5
5.5
6.0
7.0
7.0
7.0
7.5
8.0
8.5
9.5
10.0
14.0
16.0
250VDC
L
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
18.0
21.0
21.0
21.0
24.0
24.0
33.0
33.0
34.0
dØ
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
ØD
5.0
5.0
5.0
6.0
6.0
7.5
8.5
10.0
9.0
9.5
11.0
10.5
12.5
14.0
16.0
400VDC
L
15.0
15.0
18.0
18.0
18.0
18.0
18.0
18.0
21.0
24.0
24.0
27.0
27.0
33.0
35.0
dØ
0.5
0.5
0.5
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
ØD
5.0
6.0
6.0
6.0
7.0
7.5
7.5
7.5
8.5
9.5
11.0
13.0
15.0
630VDC
L
15.0
15.0
21.0
21.0
21.0
21.0
21.0
24.0
24.0
27.0
27.0
27.0
35.0
dØ
0.5
0.5
0.5
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
Custom sizes available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
