Features

Product Name: 3.0A SILICON RECTIFIERS 3.0 ampere silicon rectifier

Product model: 1N5408

product features:

Low forward voltage drop

High current capability

High reliability

High surge current capability

Mechanical data:

Cases:Molded plastic

Epoxy:UL 94V-0 rate flame retardant

Lead:Axial leads,solderable per MIL-STD-202, Method 208 guaranteed

Polarity:Color band denotes cathode end

High temperature soldering guaranteed;

250?C /10 seconds/.375”,(9.5mm)lead

Lengths at 5 lbs.,(2.3kg) tension

Weight: 1.2 grams

Maximum Ratings and Electrical Characteristics:

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%

product data:

Maximum Repetitive Peak Reverse Voltage VRRM Maximum reverse peak voltage: 1000V

Maximum RMS Voltage VRMS Voltage effective value: 700 V

Maximum DC blocking Voltage VDC Maximum DC blocking voltage: 1000V

Maximum Average Forward Rectified Current .375”(9.5mm) Lead length @TA=75℃ IF(AV) Maximum forward current: 3.0 A

Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Super imposed on Rated Load IFSM Maximum forward surge current: 200 A

Maximum Instantaneous Forward Voltage @ 3.0A VF Maximum forward voltage drop: 1.0 V

Maximum Reverse Current at Rated @TA=25℃ IR Maximum reverse leakage current: 5.0μA

DC blocking voltage @TA= 100℃ IR Maximum reverse leakage current: 100μA

Typical Thermal Resistance (Note) RθJA Thermal resistance coefficient: 18 ℃/W

Operating Temperature Range TJ Operating Junction Temperature: -65 to +125 ℃

Storage Temperature Range TSTG Storage Temperature Range: -65 to +150 ℃

Package: DO-201AD
