2SC6000
TOSHIBA Transistor
Silicon NPN Epitaxial Type
2SC6000
High Speed Switching Applications
DC-DC Converter Applications
•
•
•
High DC current gain: h
FE
= 250 to 400 (I
C
= 2.5 A)
Low collector-emitter saturation: V
CE (sat)
= 0.18 V (max)
High speed switching: t
f
= 13 ns (typ)
Unit: mm
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power
dissipation
Junction temperature
Storage temperature range
Tc = 25°C
DC
Pulse
Symbol
V
CBO
V
CEX
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
j
T
stg
Rating
120
120
50
6
7.0
10.0
0.5
20
150
−55
to 150
Unit
V
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
2-7J1A
Weight: 0.36 g (typ.)
Note: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in temperature, etc.) may cause this product to
decrease in the reliability significantly even if the operating conditions (i.e. operating
temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test report
and estimated failure rate, etc).
1
2006-11-13
2SC6000
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
DC current gain
Collector emitter saturation voltage
Base-emitter saturation voltage
Rise time
Switching time
Storage time
Fall time
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
h
FE (2)
V
CE (sat)
V
BE (sat)
t
r
t
stg
t
f
Test Condition
V
CB
= 120 V, I
E
= 0
V
EB
= 6 V, I
C
= 0
I
C
= 10 mA, I
B
= 0
V
CE
= 2 V, I
C
= 1 mA
V
CE
= 2 V, I
C
= 2.5 A
I
C
= 2.5 A, I
B
= 83 mA
I
C
= 2.5 A, I
B
= 83 mA
See Figure 1 circuit diagram
∼
V
CC
−
20 V, R
L
=
8.0
Ω
I
B1
=
83 mA, I
B2
= −166
mA
Min
―
―
50
160
250
―
―
―
―
―
Typ.
―
―
―
―
―
―
―
45
450
13
Max
100
100
―
―
400
0.18
1.10
―
―
―
Unit
nA
nA
V
V
V
ns
Figure 1 Switching Time Test Circuit & Timing Chart
VCC
20μs
RL
IB1
IB2
Duty cycle
＜
1%
IB1
Input
Output
IB2
Marking
C6000
Part No. (or abbreviation code)
Lot No.
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
2
2006-11-13
2SC6000
