TIGER ELECTRONIC CO.,LTD
Product specification
Complementary Silicon Power Ttransistors
( Ta = 25 C)
DESCRIPTION
O
2SB546A / 2SD401A
The 2SB546A and 2SD401A are high voltage triple diffused silicon transistors,
These devices are designed for use in line-operated color TV vertical defiection of
complementary symmetry circuit,
The 2SB546A and 2SD401A are complementary transistors, consisting of straight leads
Parameter
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Peak Current
Total Dissipation at
Max. Operating Junction Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
C(peak)
P
tot
T
j
T
stg
Value
200
150
5
2.0
3.0
30
150
-55~150
Unit
V
V
V
A
A
W
o
o
C
C
TO-220
Storage Temperature
ELECTRICAL CHARACTERISTICS
T SEMICONDUCTOR CO., LTD
Parameter
Collector Cutoff Current
Emitter Cut-off Current
Collector-Emitter Sustaining Voltage
DC Current Gain
Collector-Emitter Saturation Voltage
Collector capacitance
Transition Frequency
Symbol
Test Conditions
V
CB
=150V, I
E
=0
V
EB
=4.0V, I
C
=0
I
C
=10mA, I
B
=0
V
CE
=10V, I
C
=400mA
Min.
—
—
150
40
—
—
—
Typ.
—
—
—
—
—
75/45
7.0
Max.
50
50
—
—
2.0
—
—
V
pF
MHz
Unit
uA
uA
V
I
CBO
I
EBO
V
CEO
h
FE(1)
C
C
f
T
V
CE(sat)
I
C
=500mA,I
B
=50mA
V
CB
=10V,f=1.0MHz, I
E
=0
V
CE
=10V,I
C
=400mA
