SOLID TANTALUM ELECTROLYTIC CAPACITORS
F92
Resin-molded Chip,
Compact Series
Type numbering system (Example: 6.3V 10µF)
1
2
3
4
5
6
7
8
9
10
11
Taping code
(Refer to page 213 for details)
Case code
Capacitance tolerance
Rated Capacitance Rated voltage
Series
F 9 2 0 J 1 0 6 M P
Drawing
L
H
W
1
W
2
S
S
(mm)
Marking
Rated Capacitance
Rated Capacitance (
µ
F)
Dimensions
A Case
G226
Rated voltage
(Voltage code)
Rated Capacitance
(Capacitance code)
Rated voltage (V)
J Case
J
P Case
AS
B Case
22
10V
Case code
J
P
A
B
1.6
2.0
3.2
3.4
L
W
1
± 0.1 0.8 ± 0.1
± 0.2 1.25 ± 0.1
± 0.2 1.6 ± 0.2
± 0.2 2.8 ± 0.2
W
2
0.6 ± 0.1
0.9 ± 0.1
1.2 ± 0.1
2.3 ± 0.1
0.8
1.1
1.1
1.1
H
± 0.1
± 0.1
± 0.1
± 0.1
0.4
0.5
0.8
0.8
S
± 0.1
± 0.2
± 0.2
± 0.2
5 seconds immension at 260
˚C
,10 seconds reflow at 260
˚C
Resistance
to Soldering Heat
Capacitance Change...
Within ±10% of initial value
(J case within ± 20%)
Dissipation Factor...150% of
Iess of initial specified value*1
Leakage Current...
Initial specified value or less
2.5V
4V
6.3V
e
G
J
10V
16V
20V
A
C
D
25V
35V
E
V
Within
±
5% of initial value
Initial specified value or less
Initial specified value or less
Capacitance code of “P” case products are as shown below.
Specifications
Item
Category
Temperature Range
Capacitance Tolerance
Dissipation Factor
(120Hz)
E.S.R. (100kHz)
Performance Characteristics
J
•
P Case
A
•
B Case
– 55 ~ +125˚C (Rated temperature : 85˚C)
± 20% (at 120Hz)
refer to P.216
refer to P.216
Surge
∗
After application of surge voltage in series with a 33
Ω
(For “J” “P” case:
1k
Ω
) resistor at the rate of 30 seconds ON, 30 seconds OFF, for 1000
successive test cycles at 85˚C, capacitors meet the characteristics
requirements listed below.
Capacitance Change...
Within ±10% of initial value
(J case within ± 20%)
Dissipation Factor...150% or
Iess of initial specified value*1
Leakage Current...
Initial specified value or less
Within ±5% of initial value
Initial specified value or less
•
After 1 minute's application of rated voltage, leakage current
at 20˚C is not more than 0.01CV or 0.5µA, whichever is greater.
Leakage Current
•
After 1 minute's application of rated voltage, leakage current
at 85˚C is not more than 0.1CV or 5µA, whichever is greater.
•
After 1 minute's application of derated voltage, leakage current
at 125˚C is not more than 0.125CV or 6.3µA, whichever is greater.
Capacitance Change
by Temperature
Damp Heat
(No voltage applied)
Temperature Cycles
+20% Max. (at +125
˚C
)
+15% Max. (at +125
˚C
)
+15% Max. (at +85
˚C
)
+10% Max. (at +85
˚C
)
--15% Max. (at --55
˚C
)
--10% Max. (at --55
˚C
)
At 40
˚C
90 ~ 95% R.H. 240 hours At 40
˚C
90 ~ 95% R.H. 500 hours
Capacitance Change...
Within ±10% of initial value
Within ±20% of initial value
Dissipation Factor...150% or
Initial specified value or less
Iess of initial specified value
Leakage Current...
Initial specified value or less
Initial specified value or less
--55
˚C
/ +125
˚C
30 minutes each 5 cycles
Capacitance Change...
Within ±5% of initial value
Within ±10% of initial value
(J case Within ±20%)
Dissipation Factor...150% of
Initial specified value or less
Iess of initial specified value
*1
Initial specified value or less
Leakage Current...
Initial specified value or less
Initial specified value or less
After 2000hours' application of
rated voltage in series with a
3
Ω
resistor at 85
˚C
, or derated
voltage in series with a 3
Ω
resistor at 125
˚C
, capacitors
meet the characteristic
Endurance
∗
requirements listed below.
Capacitance Change...
Within ±10
˚C
of initial value
Dissipation Factor...
Initial specified value or less
Leakage Current...
Initial specified value or less
After applying the pressure load of 5N for
10±1 seconds horizontally to the center
of capacitor side body which has no
Shear Test
electrode and has been soldered
5N (0.51kg
•
f)
beforehand on an aluminum substrate,
For 10
±
1seconds
there shall be found neither exfoliation
nor its sign at the terminal electrode.
Keeping a capacitor surface-mounted on a substrate upside
down and supporting the substrate at both of the opposite
bottom points 45mm apart from the center of the capacitor, the
pressure strength is applied with a
20
specified jig at the center of the
R230
Terminal Strength
substrate so that the substrate may
bend by 1mm as illustrated.
Then, there shall be found no
remarkable abnormality on the
45
45
capacitor terminals.
∗
As for the surge and derated voltage at 125
˚C
, refer to page 212 for details.
After 1000hours' application of
rated voltage in series with a
3
Ω
resistor at 85
˚C
, or derated
voltage in series with a 3
Ω
resistor at 125
˚C
, capacitors
meet the characteristic
requirements listed below.
Capacitance Change...
Within ±10
˚C
of initial value
(J case within ± 20%)
Dissipation Factor...150% or
less of initial specified value*1
Leakage Current...
Initial specified value or less
(J case 2 times value or less)
Standard ratings
V
Cap.(
µ
F
)
Code
2.5
0E
4
0G
6.3
0J
10
1A
16
1C
20
1D
25
1E
0.1
0.15
0.22
0.33
0.47
0.68
1
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
104
154
224
334
474
684
105
155
225
335
475
685
106
156
226
336
476
686
107
P
P
J·P·A
P·A
P·A
P·A
B
B
B
P
P·A
J·P·A
J·P·A
J·P·A
P·A
P·A
(P) · A · B
(A) · B
B
B
P
P
J·P·A
P·A
J·P·A
P·A
J·P·A
P·A
P·A·B
(A) · B
B
(B)
P
P·A
J·P·A
P·A
P·A
P·A
P·A·B
A·B
(A) · B
B
P
P
J·P·A
P·A
P·A·B
A·B
A·B
B
(A) · B
(B)
P·A
P·A
P·A
A
P·A
A·B
A·B
B
B
A
A
A
B
P·A·B
(B)
35
1V
A
A
A
A
B
B
(A)
(B)
Capacitance code
J
N
S
W
A
E
J
N
S
w
a
e
j
n
( ) The series in parentheses are being developed.
Please contact to your local Nichicon sales office when these
series are being designed in your application.
CAT.8100S
