05300
EM1609-04DLP
EMI FILTER/TVS ARRAY
APPLICATIONS
✔
✔
✔
✔
✔
✔
Cellular Phones
Color LCD Display Panel
Notebooks
Personal Digital Assistant (PDA)
Ground Positioning System (GPS)
SMART Cards
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
DFN-8LP
FEATURES
✔
ESD Protection > 25 kilovolts
✔
EMI Filtering/TVS Low Pass Filters
✔
> 35db Attenuation from 800MHz to 3GHz
✔
Protects up to Four(4) Data Lines
✔
RoHS Compliant
MECHANICAL CHARACTERISTICS
✔
DFN-8LP Package
✔
Lead-Free Pure-Tin Plating(Annealed)
✔
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
✔
Flammability Rating UL 94V-0
✔
Device Marking: Marking Code
✔
12mm Tape and Reel Per EIA Standard 481
PIN CONFIGURATION
For Each Line
For Each Line
I/On
100 Ohm
I/On
1
2
3
4
15pF
GND
15pF
GND
8
Note:
I/O connected from pins 1-8, 2-7, 3-6, and 4-5.
7
6
5
BOTTOM VIEW
05300.R0 10/08
1
www.protekdevices.com
EM1609-04DLP
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
DC Power Per Resistor
Typical Resistance @ ± 20%
Soldering Temperature for 10 seconds
SYMBOL
T
A
T
STG
P
R
T
L
VALUE
-40 to 85
-55 to 150
100
100
265
UNITS
°C
°C
mW
OHMS
°C
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
DEVICE
MARKING
CODE
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
REVERSE
LEAKAGE
CURRENT
@3V
I
D
µA
0.5
@ 25°C Unless Otherwise Specified
MINIMUM
ATTENUATION
CUT-OFF
FREQUENCY
(50 OHMS I/O)
ZERO BIAS
TYPICAL
CAPACITANCE
(See Note 1)
TYPICAL
FORWARD
VOLTAGE
V
WM
VOLTS
EM1609-04SLP
14D
5.0
@ 1mA
V
(BR)
VOLTS
6.0
@10mA
V
F
VOLTS
0.8
@
800-3000 MHz
dB
25
fC
MHz
110
@2.5V, 1MHz
C
pF
30
Note 1:
32pF @ 0V, 1MHz, ±20% tolerance.
FIGURE 1
INSERTION LOSS
0
-5
-10
Gain (dB)
-15
-20
-25
-30
-35
0.1
1
10
100
2.5 Volts
0 Volts
1000
10000
Frequency (MHz)
05300.R0 10/08
2
www.protekdevices.com
EM1609-04DLP
GRAPHS
1.100
FIGURE 1
RESISTANCE VS TEMPERATURE
(Normalized to Resistance at 25°C)
Normalized Resistance
1.060
1.020
0.980
0.940
0.900
-40
-20
0
20
40
Temperature °C
60
80
100
1.6
C
j
- Capacitance (Normalized)
FIGURE 3
CAPACITANCE VS REVERSE VOLTAGE
(Normalized to Capacitance at 2.5V DC & 25°C)
1.4
1.2
1
0.8
0.6
0.4
0.2
0
0
1
2
3
4
5
6
V
R
- Reverse Voltage - Volts
FIGURE 4
OVERSHOOT & CLAMPING VOLTAGE (through the filter)
35
5 Volts per Division
25
15
5
-5
ESD Test Pulse: +15 kilovolt, 1/30ns (waveform)
05300.R0 10/08
3
www.protekdevices.com
EM1609-04DLP
DFN-8LP PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
P1
DIM
P1
P2
P3
L1
PACKAGE DIMENSIONS
MILLIMETERS
MIN
1.90
1.50
0.50
0.23
0.25
0.13
0.50
0.90
0.30
MAX
2.10
1.70
0.60
0.30
0.40
0.18
0.50
1.45
0.42
INCHES
MIN
0.075
0.059
0.020
0.009
0.010
0.005
0.020
0.035
0.012
MAX
0.083
0.067
0.024
0.012
0.016
0.007
0.020
0.058
0.016
P2
L2
L3
p
TOP VIEW
L3
END VIEW
G1
G2
SIDE VIEW
L2
p
L1
P3
NOTES:
1. Controlling dimensions in millimeters
2. Dimension b applies to terminal and is measured
between 0.25 and 0.30mm from terminal.
3. Coplanarity applies to the exposed pad as well as the
terminals.
4. Dimension p is BSC.
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in
accordance with EIA 481.
2. Suffix-T71 = 7 Inch Reel - 1,000 pieces per 8mm
tape, i.e.,
EM1609-04DLP-T71.
3. Suffix-T73 = 7 Inch Reel - 3,000 pieces per 8mm
tape, i.e.,
EM1609-04DLP-T73.
4. Suffix - LF = Lead-Free, Pure Tin Plating,
i.e., EM1609-04DLP-LF-T73.
G2
G1
BOTTOM VIEW
Outline & Dimensions: Rev 1 - 10/06, 06068
Tape & Reel Specifications (Dimensions in millimeters)
Reel Dia.
178mm (7”)/330mm(13”)
Tape Width
8mm
A0
B0
K0
D
E
F
W
P0
P2
P
tmax
0.25
2.30± 0.10 2.30± 0.10 0.80 ± 0.10 1.50 ± 0.10 1.75 ± 0.10 3.50 ± 0.05 8.00 ±0.30 4.00 ±0.10 2.00 ±0.05 4.00 ±0.10
P0
t
D
P2
10 Pitches Cumulative
Tolerance on Tape. ± 0.2
E
Top cover tape
A0
K0
B0
Pin 1
Indicated
by Dot
F
W
P
User Direction of Feed
