Multi-Connector Tension Spring Type |
Through Terminal Block
ZRS2.5-1L1RS
- 2 Connections
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule
min
Stranded with Ferrule
max
Clamping Range min
Clamping Range max
0.5 mm²
4.0 mm²
0.5mm²
4.0 mm²
0.5 mm²
2.5 mm²
0.5mm²
4.0 mm²
Insulating Material
Material
Flammability Class
Temperatures
Working Temperature -40 - 120 °C
Dimensions
Stripped Length
Width
Height
Length
Height TS35 x 7.5
10.0 mm
5.1 mm
38.5 mm
54.0 mm
39.5 mm
PA 6.6
UL 94 V-0
Order Data
Article Designation
ZRS2.5-1L1RS-BE
ZRS2.5-1L1RS-BLUE
ZRS2.5-1L1RS-ORANGE
Article Number
43650.2
43650.5
43650.3
PU
100
100
100
Accessoires
Article Designation
End Plate ZAPS2.5/1A/1S
Cross-Connection insulated
ZQI2.5/2
Cross-Connection insulated
ZQI2.5/3
Cross-Connection insulated
ZQI2.5/4
Cross-Connection insulated
ZQI2.5/5
Article Number
493680.2
493710.8
493711.8
493712.8
493713.8
493714.8
493715.8
493716.8
493717.8
493718.8
493719.8
493740.2
493706.0
493811.2
494600.7
PU
50
50
50
20
20
20
20
10
10
10
1
10
20
50
500
Electrical Data
General
Cross Connection
Channels
Test Pick off
2
1
Cross-Connection insulated
ZQI2.5/6
Cross-Connection insulated
ZQI2.5/7
Cross-Connection insulated
ZQI2.5/8
Cross-Connection insulated
ZQI2.5/9
Cross-Connection insulated
ZQI2.5/10
Cross-Connection insulated
ZQI2.5/0.5/99
Test Adapter ZTA2.5
Four-Way Covers ZAD2.5/4/B
End Stopn ZES35/2
Quick Labelling PSB5/50
Colours
BEIGE, similar RAL 1019
BLUE, similar RAL 5015
ORANGE, similar RAL 2003
Connection Diagram
Ratings
Ratings
Rated Voltage
Rated Current
Rated Wire Size
Rated Impulse Voltage
Pollution Degree
300 V
20 A
AWG 20-12
300 V
20 A
AWG 20-12
500 V
24 A
2.5 mm²
8V
3
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
