4 Watt | DC-DC Converter
FEATURES:
•
•
•
•
Wide 2:1 input range
24 Pin DIP Package
Metal package
High efficiency up to 80%
•
•
•
•
Operating temperature -40
o
C to + 85
o
C
Input / Output isolation 1500 / 3500 VDC
Pin compatible with multiple manufacturers
Continuous short circuit protection
Series AM4T-VZ
Models
Single output
Model
AM4T-1205S-VZ
AM4T-1209S-VZ
AM4T-1212S-VZ
AM4T-1215S-VZ
AM4T-1224S-VZ
AM4T-2405S-VZ
AM4T-2409S-VZ
AM4T-2412S-VZ
AM4T-2415S-VZ
AM4T-2424S-VZ
AM4T-4805S-VZ
AM4T-4809S-VZ
AM4T-4812S-VZ
AM4T-4815S-VZ
AM4T-4824S-VZ
AM4T-1205SH35-VZ
AM4T-1209SH35-VZ
AM4T-1212SH35-VZ
AM4T-1215SH35-VZ
AM4T-1224SH35-VZ
AM4T-2405SH35-VZ
AM4T-2409SH35-VZ
AM4T-2412SH35-VZ
AM4T-2415SH35-VZ
AM4T-2424SH35-VZ
AM4T-4805SH35-VZ
AM4T-4809SH35-VZ
AM4T-4812SH35-VZ
AM4T-4815SH35-VZ
AM4T-4824SH35-VZ
Input Voltage
(V)
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
Output Voltage
(V)
5
9
12
15
24
5
9
12
15
24
5
9
12
15
24
5
9
12
15
24
5
9
12
15
24
5
9
12
15
24
Output Current
max (mA)
800
444
333
267
167
800
444
333
267
167
800
444
333
267
167
800
444
333
267
167
800
444
333
267
167
800
444
333
267
167
Capacitive load,
max (μF)
2200
470
470
470
220
2200
470
470
470
220
2200
470
470
470
220
2200
470
470
470
220
2200
470
470
470
220
2200
470
470
470
220
Efficiency
(%)
72
78
78
77
76
77
78
79
80
77
77
77
78
77
75
72
78
78
77
76
77
78
79
80
77
77
77
78
77
75
Models
Dual output
Model
AM4T-1205D-VZ
AM4T-1209D-VZ
AM4T-1212D-VZ
AM4T-1215D-VZ
AM4T-1224D-VZ
AM4T-2405D-VZ
AM4T-2409D-VZ
AM4T-2412D-VZ
AM4T-2415D-VZ
AM4T-2424D-VZ
AM4T-4805D-VZ
Input Voltage
(V)
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
36-72
Output Voltage
(V)
±5
±9
±12
±15
±24
±5
±9
±12
±15
±24
±5
Output Current
max (mA)
±400
±222
±167
±133
±83
±400
±222
±167
±133
±83
167
Capacitive load,
max (μF)
±1000
±220
±220
±220
±100
±1000
±220
±220
±220
±100
220
Efficiency
(%)
77
77
78
78
77
77
77
78
79
76
75
www.aimtec.com
F 051e R12.F
Tel: +1 514 620 2722
1 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
General Specifications
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Case material
Weight
Dimensions(L x W x H)
MTBF
4 Watt | DC-DC Converter
Conditions
Typical
100-400
-40 to +85
-40 to +125
Series AM4T-VZ
Units
KHz
o
C
o
C
o
C
%
Parameters
Maximum
Full Load (see derating chart)
Free air convection
100
95
Nickel coated copper
15
g
Tolerance ±0.5 mm or ±0.02 inches
1.25 x 0.8 x 0.4 inches
31.75 x 20.32 x 10.16 mm
>2,200,000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Safety Specifications
Parameters
Agency approvals
Standards
CE
Designed to meet IEC 60950-1
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Pin Out Specifications
Pin
2
3
9
11
14
16
22
23
-V Input
-V Input
No pin
N.C.
+V Output
-V Output
+V Input
+V Input
1500 & 3500 VDC
Single
Dual
-V Input
-V Input
Common
-V Output
+V Output
Common
+V Input
+V Input
Dimensions
31.75
(1.25)
0.50
(0.02)
22.86
(0.90)
20.32
(0.80)
Bottom View
23 22
2.54
(0.10)
16
14
5.08
(0.20)
Printed Face
Built-in Stand-offs to
ease PCB cleaning
10.16
(0.40)
www.aimtec.com
F 051e R12.F
3.05
(0.12)
Tel: +1 514 620 2722
3 of 4
15.24
(0.60)
2
3
9
11
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
4 Watt | DC-DC Converter
Derating
Series AM4T-VZ
Free Air Convection
85 º C
100
Output Power %
80
60
40
20
0
-40
0
25
50
75
85
100
Safe Operating Area
Ambient Temperature
º C
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
www.aimtec.com
F 051e R12.F
Tel: +1 514 620 2722
4 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
