Absolute Maximum Ratings (Ta=25°C, All voltages are with respect to ground)
Parameter
Supply Voltage
Output Current
All Other Input Pins
Operating Temperature
Storage Temperature
Power Dissipation
Junction Temperature
Symbol
V
CC
I
OMAX
V
IN
Topr
Tstg
Pd
Tjmax
Rating
18
0.5
(Note 1)
/ 1.0
(Note 2)
/ 2.0
(Note 3)
-0.3 to V
CC
-40 to +85
-55 to +150
0.68
(Note 4)
/ 1.6
(Note 5)
/ 1.4
(Note 6)
150
Unit
V
A
V
°C
°C
W
°C
(Note 1) BD6220 / BD6225. Do not exceed Pd or ASO.
(Note 2) BD6221 / BD6226. Do not exceed Pd or ASO.
(Note 3) BD6222. Do not exceed Pd or ASO.
(Note 4) SOP8 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 5.5mW/°C for Ta above 25°C.
(Note 5) HRP7 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 12.8mW/°C for Ta above 25°C.
(Note 6) HSOP25 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 11.6mW/°C for Ta above 25°C.
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions (Ta=25°C)
Parameter
Supply voltage
VREF voltage
Symbol
V
CC
V
REF
Rating
6 to 15
3 to 15
Unit
V
V
Electrical Characteristics (Unless otherwise specified, Ta=25°C and V
