12A TRIACS
GENERAL DESCRIPTION
BTA/BTB12-700C
Available either in through-hole or surface-mount packages, the BTA/BTB12 - 700C triac series is
suitable for general purpose AC switching. They can be used as an ON/OFF function in applications
such as static relays, heating regulation, induction motor starting circuits... or for phase control
operation in light dimmers, motor speed controllers, ...
The snubberless versions (BTA/BTB...W series) are specially recommended for use on
inductive loads, thanks to their high commutation performances. By using an internal ceramic pad,
the BTA series provides voltage insulated tab (rated at 2500V RMS) complying with UL standards.
ABSOLUTE MAXIMUM RATINGS ( Ta = 25 C)
PARAMETER
Repetitive peak off-state voltages
peak off-state reverse voltages
RMS on-state current
Non-repetitive peak on-state current
Max. Operating Junction Temperature
Storage Temperature
Symbol
V
DRM
V
RRM
I
T
I
TSM
T
j
T
stg
Value
700
700
12.0
120
110
-45~150
Unit
V
V
A
A
o
O
A1 A2 G
C
o
TO-220AB
C
ELECTRICAL CHARACTERISTICS ( Ta = 25 C)
PARAMETER
Repetitive peak off-state
voltages
Repetitive peak off-state
current
On-state voltage
Holding current
T2+G+
Gate trigger
Current
T2+G-
T2-G-
T2-G+
T2+G+
Gate trigger
Voltage
T2+G-
T2-G-
T2-G+
Symbol
Test Conditions
I
D
=0.1mA
Min.
700
Max
Unit
V
O
V
DRM
I
DRM
V
TM
I
H
V
DRM
=620V
I
T
=17A
I
T
=0.5A,I
GT
=20mA
10
1.55
25
25
uA
V
mA
I
GT
25
V
AK
=12V
R
L
=30
mA
25
50
1.3
V
GT
V
D
=12V
R
L
=30
1.3
1.3
1.3
V
