BUK7Y9R9-80E

Description
89 A, 80 V, 0.0099 ohm, N-CHANNEL, Si, POWER, MOSFET, MO-235
Categorysemiconductor    Discrete semiconductor
File Size285KB,13 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Download Datasheet Parametric View All

BUK7Y9R9-80E Overview

89 A, 80 V, 0.0099 ohm, N-CHANNEL, Si, POWER, MOSFET, MO-235

BUK7Y9R9-80E Parametric

Parameter NameAttribute value
Minimum breakdown voltage80 V
Number of terminals4
Processing package descriptionPLASTIC, POWER-SO8, LFPAK56-4
EU RoHS regulationsYes
stateActive
Rated avalanche energy106 mJ
Shell connectionDRAIN
structureSINGLE WITH BUILT-IN DIODE
Maximum leakage current89 A
Maximum drain on-resistance0.0099 ohm
field effect transistor technologyMETAL-OXIDE SEMICONDUCTOR
jedec_95_codeMO-235
jesd_30_codeR-PSSO-G4
jesd_609_codee3
moisture_sensitivity_level1
Number of components1
operating modeENHANCEMENT MODE
Packaging MaterialsPLASTIC/EPOXY
packaging shapeRECTANGULAR
Package SizeSMALL OUTLINE
eak_reflow_temperature__cel_260
larity_channel_typeN-CHANNEL
Maximum leakage current pulse354 A
eference_standardAEC-Q101; IEC-60134
surface mountYES
terminal coatingTIN
Terminal formGULL WING
Terminal locationSINGLE
ime_peak_reflow_temperature_max__s_30
transistor applicationsSWITCHING
Transistor component materialsSILICON
dditional_featureAVALANCHE RATED
BUK7Y9R9-80E
20 February 2013
LF
PA
K
N-channel 80 V, 9.9 mΩ standard level MOSFET in LFPAK56
Product data sheet
1. General description
Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using
TrenchMOS technology. This product has been designed and qualified to AEC Q101
standard for use in high performance automotive applications.
2. Features and benefits
Q101 compliant
Repetitive avalanche rated
Suitable for thermally demanding environments due to 175 °C rating
True standard level gate with V
GS(th)
rating of greater than 1 V at 175 °C
3. Applications
12 V, 24 V and 48 V Automotive systems
Motors, lamps and solenoid control
Transmission control
Ultra high performance power switching
4. Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
V
GS
= 10 V; T
mb
= 25 °C;
Fig. 1
T
mb
= 25 °C;
Fig. 2
V
GS
= 10 V; I
D
= 25 A; T
j
= 25 °C;
Fig. 11
V
GS
= 10 V; I
D
= 25 A; V
DS
= 64 V;
Fig. 13; Fig. 14
-
14.4
-
nC
Min
-
-
-
Typ
-
-
-
Max
80
89
195
Unit
V
A
W
Static characteristics
drain-source on-state
resistance
-
7.3
9.9
Dynamic characteristics
Q
GD
gate-drain charge
