Z86E6120PSG datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> Z86E6120PSG

Z86E6120PSG: DescriptionMicrocontroller, CMOS,; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，70 Pages; ManufacturerIXYS; Environmental Compliance

Download Datasheet Parametric Compare View All

Z86E6120PSG Overview

Microcontroller, CMOS,

Z86E6120PSG Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
Has ADC	NO
Address bus width	15
bit size	8
maximum clock frequency	16 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
length	52.33 mm
Number of I/O lines	32
Number of terminals	40
PWM channel	NO
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
rom(word)	16384
speed	20 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

CMOS Z8 16K/32K EPROM MCUs

Z86E61/Z86E63

Microcontrollers

Product Specification

PS014404-0212

www.zilog.com

Z86E61/Z86E63 Microcontrollers

Product Specification

Table of Contents

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii

List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Pin Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Pin Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Address Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Program Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Data Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Register File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Counter/Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Z86E61/Z86E63 User Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Z86E63 Signal Description for EPROM Program/Read . . . . . . . . . . . . . . . . . . . . . 30

Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Standard Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

DC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Supply Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Standby Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

AC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Z8 Instruction Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Instruction Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Instruction Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Op Code Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Part Number Suffix Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

PS014404-0212

Table of Contents

Z86E6120PSG Related Products

	Z86E6120PSG	Z86E6316VSG	Z86E6116PSG	Z86E6116ASG	Z86E6316ASG	Z86E6116VSG	Z86E6316PSG	Z86E6120VSG
Description	Microcontroller, CMOS,	Microcontroller, 8-Bit, UVPROM, Z8 CPU, 16MHz, CMOS, PQCC44,	Microcontroller, 8-Bit, UVPROM, Z8 CPU, 16MHz, CMOS, PDIP40,	Microcontroller, CMOS,	Microcontroller, CMOS,	Microcontroller, 8-Bit, UVPROM, Z8 CPU, 16MHz, CMOS, PQCC44,	Microcontroller, 8-Bit, UVPROM, Z8 CPU, 16MHz, CMOS, PDIP40,	Microcontroller, CMOS,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
bit size	8	8	8	8	8	8	8	8
Number of terminals	40	44	40	44	44	44	40	44
encapsulated code	DIP	QCCJ	DIP	QFP	QFP	QCCJ	DIP	QCCJ
Package shape	RECTANGULAR	SQUARE	RECTANGULAR	SQUARE	SQUARE	SQUARE	RECTANGULAR	SQUARE
Package form	IN-LINE	CHIP CARRIER	IN-LINE	FLATPACK	FLATPACK	CHIP CARRIER	IN-LINE	CHIP CARRIER
rom(word)	16384	32768	16384	16384	32768	16384	32768	16384
speed	20 MHz	16 MHz	16 MHz	16 MHz	16 MHz	16 MHz	16 MHz	20 MHz
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	YES	NO	YES	YES	YES	NO	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Terminal form	THROUGH-HOLE	J BEND	THROUGH-HOLE	GULL WING	GULL WING	J BEND	THROUGH-HOLE	J BEND
Terminal pitch	2.54 mm	1.27 mm	2.54 mm	0.8 mm	0.8 mm	1.27 mm	2.54 mm	1.27 mm
Terminal location	DUAL	QUAD	DUAL	QUAD	QUAD	QUAD	DUAL	QUAD
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Has ADC	NO	NO	NO	NO	NO	-	NO	NO
Address bus width	15	15	15	15	15	-	15	15
maximum clock frequency	16 MHz	16 MHz	16 MHz	16 MHz	16 MHz	-	16 MHz	16 MHz
DAC channel	NO	NO	NO	NO	NO	-	NO	NO
DMA channel	NO	NO	NO	NO	NO	-	NO	NO
External data bus width	8	8	8	8	8	-	8	8
length	52.33 mm	16.59 mm	52.33 mm	10 mm	10 mm	-	52.33 mm	16.59 mm
Number of I/O lines	32	32	32	32	32	-	32	32
PWM channel	NO	NO	NO	NO	NO	-	NO	NO
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	-	5.5 V	5.5 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	-	4.5 V	4.5 V
width	15.24 mm	16.59 mm	15.24 mm	10 mm	10 mm	-	15.24 mm	16.59 mm
Maker	-	IXYS	IXYS	IXYS	IXYS	-	IXYS	-
Base Number Matches	-	1	1	1	1	1	-	-
