328301D115: DescriptionElectromechanical Relay, 3PDT, Latched, 25A (Contact), 28VDC (Contact), AC/DC Output; CategoryMechanical and electronic products relay; File Size355KB，4 Pages; ManufacturerSTPI Siege Social

Download Datasheet Parametric View All

328301D115 Overview

Electromechanical Relay, 3PDT, Latched, 25A (Contact), 28VDC (Contact), AC/DC Output

328301D115 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
body width	26 mm
body height	25.7 mm
Body length or diameter	26 mm
Coil operating voltage (AC)	100 V
Coil release voltage (AC)	5 V
Maximum coil voltage (AC)	122 V
Nominal coil voltage	115 V
Coil/Input Power Type	AC
Contact (AC) maximum rated load I	15A@115VAC
Contact (AC) maximum rated R load	25A@115VAC
Maximum contact current (AC)	25 A
Maximum contact current (DC)	25 A
Contact (DC) maximum rated R load	25A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Dielectric strength between breaking contacts	1250 Vrms
Electrical life	50000 Cycle(s)
Insulation resistance	100000000 Ω
Number of terminals	11
operating hours	20 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
PCB hole count	11
physical size	26mm x 26mm x 25.7mm
Relay action	LATCHED
Relay style	3 FORM C
Relay function	3PDT
release time	50 ms
seal	HERMETICAL
Terminal length	0.0071 inch
Termination type	SOLDER
weight	97 g

Preview

Download Datasheet

View All

328 3

RT -

PDT

/25

RELAIS HERMETIQUES

MONOSTABLES

HERMETICALLY SEALED

NON LATCHING

RELAY

CARACTERISTIQUES GENERALES

GENERAL CHARACTERICS

Combinaison des contacts

Contact arrangement

3 RT

3PDT

Pouvoir de coupure 28 Vcc - 1 5 V/400 Hz

Contact rating 28 Vdc - 115 V/400 Hz

Circuit résistif

Resistive load

25 A

25 Amps

Circuit inductif (L/R = 5 ms)

Inductive load (L/R = 5 ms)

1 A (28 Vc) / 1 A (1 5 V - 400 Hz)

12 Amps (28 Vdc) / 15 Amps (115 V - 400 Hz)

Circuit moteur

Motor load

10 A

10 Amps

Circuit lampe

Lamp load

5 Amps

Alimentation

Supply

Courant continu (polarisé) ou alternatif 400Hz

Direct current (polarised) or alternative current 400 Hz

Masse

Weight

85 g à 97 g max.

85 g to 97 g max.

Normes applicables en annexe

See appendice for applicable specifications

ENVIRONNEMENT

ENVIRONMENT

Température de fonctionnement

Temperature range

- 65° à + 1

25°C

- 65° to + 125°C

Position de fonctionnement

Operating position

Indifférente

Any

Tenue aux vibrations

Resistance against vibrations

Sinus : 30 g - 10 - 3 000 Hz / Aléatoire : 0,4 g

/Hz - 50 - 2 000 Hz

Sinus : 30 g - 10 - 3 000 Hz / Random : 0,4 g

/Hz - 50 - 2 000 Hz

Tenue aux chocs

Shocks resistance

200 g - 6 ms / 100 g - 1 ms

200 g - 6 ms / 100 g - 11 ms

Tenue aux secousses

Shake resistance

40 g

Accélération

Acceleration

20 g

Taux de fuite

Leak rate

< 1.10

-8

/sec

< 1.10

-8

/sec

58 Av. Claude VELLEFAUX - 75010 PARIS - FRANCE

328 1/4

Tel : 33.(0)1.42.03.94.20 - Fax : 33.(0)1.42.03.52.85 - www.stpigroup.com
