CEDM8004
SURFACE MOUNT SILICON
P-CHANNEL
ENHANCEMENT-MODE
MOSFET
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CEDM8004 is an
enhancement-mode P-Channel MOSFET, manufactured
by the P-Channel DMOS process, designed for high
speed pulsed amplifier and driver applications. This
MOSFET offers low rDS(on) and low threshold voltage.
MARKING CODE: V
COMPLEMENTARY N-CHANNEL: CEDM7004
SOT-883L CASE
APPLICATIONS:
• Load/Power switches
• Power supply converter circuits
• Battery powered portable devices
MAXIMUM RATING:
(TA=25°C)
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
Power Dissipation
Operating and Storage Junction Temperature
FEATURES:
• ESD protection up to 2kV
• 0.4mm low package profile
• Low rDS(ON)
• Low threshold voltage
• Logic level compatible
• Small leadless surface mount package
SYMBOL
VDS
VGS
ID
PD
TJ, Tstg
UNITS
V
V
mA
mW
°C
30
8.0
450
100
-65 to +150
ELECTRICAL CHARACTERISTICS:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP
IGSSF, IGSSR VGS=8.0V, VDS=0
IDSS
VDS=30V, VGS=0
BVDSS
VGS(th)
VSD
rDS(ON)
rDS(ON)
rDS(ON)
gFS
Crss
Ciss
Coss
Qg(tot)
Qgs
Qgd
VGS=0, ID=100μA
VDS=VGS, ID=250μA
VGS=0, IS=100mA
VGS=4.5V, ID=430mA
VGS=2.5V,
VGS=1.8V,
ID=200mA
ID=100mA
200
8.9
45
8.5
0.88
0.35
0.128
30
0.5
1.0
1.6
2.6
MAX
3.0
1.0
1.0
1.1
1.1
2.0
3.3
10
55
15
UNITS
μA
μA
V
V
V
Ω
Ω
Ω
mS
pF
pF
pF
nC
nC
nC
VDS =10V, ID=100mA
VDS=25V, VGS=0, f=1.0MHz
VDS=25V, VGS=0, f=1.0MHz
VDS=25V, VGS=0, f=1.0MHz
VDS=10V, VGS=4.5V,
VDS=10V, VGS=4.5V,
VDS=10V, VGS=4.5V,
ID=1.0A
ID=1.0A
ID=1.0A
R6 (10-November 2014)
CEDM8004
SURFACE MOUNT SILICON
P-CHANNEL
ENHANCEMENT-MODE
MOSFET
SERVICES
• Bonded Inventory
• Custom Electrical Screening
• Custom Electrical Characteristic Curves
• SPICE Models
• Custom Packaging
• Package Base Options
• Custom Device Development / Multi Discrete Modules (MDM™)
• Bare Die for Hybrid Applications
