CMPDM303NH
SURFACE MOUNT
N-CHANNEL
ENHANCEMENT-MODE
SILICON MOSFET
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMPDM303NH
is a high current N-Channel enhancement-mode
silicon MOSFET, manufactured by the N-Channel
DMOS process, and is designed for high speed pulsed
amplifier and driver applications. This MOSFET offers
high current, low rDS(ON), low threshold voltage, and
low leakage current.
MARKING CODE: 303C
SOT-23F CASE
APPLICATIONS:
•
Load/Power switches
•
Power supply converter circuits
•
Battery powered portable equipment
MAXIMUM RATINGS:
(TA=25°C)
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (Steady State)
Maximum Pulsed Drain Current, tp=10μs
Power Dissipation
Operating and Storage Junction Temperature
Thermal Resistance
FEATURES:
•
Low rDS(ON) (0.078Ω MAX @ VGS=2.5V)
•
High current (ID=3.6A)
•
Logic level compatibility
SYMBOL
VDS
VGS
ID
IDM
PD
TJ, Tstg
Θ
JA
30
12
3.6
14.4
350
-55 to +150
357
UNITS
V
V
A
A
mW
°C
°C/W
ELECTRICAL CHARACTERISTICS:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP
I
GSSF, IGSSR VGS=12V, VDS=0
IDSS
BVDSS
VGS(th)
rDS(ON)
rDS(ON)
gFS
Crss
Ciss
Coss
Qg(tot)
Qgs
Qgd
ton
toff
VDS=20V, VGS=0
VGS=0, ID=250μA
VGS=VDS, ID=250μA
VGS=4.5V, ID=1.8A
VGS=2.5V, ID=1.8A
VDS=5.0V, ID=3.6A
VDS=10V, VGS=0, f=1.0MHz
VDS=10V, VGS=0, f=1.0MHz
VDS=10V, VGS=0, f=1.0MHz
VDD=10V, VGS=4.5V, ID=3.6A
VDD=10V, VGS=4.5V,
VDD=10V, VGS=4.5V,
VDD=10V, VGS=4.0V,
ID=3.6A
ID=3.6A
30
0.6
0.033
0.042
11.8
55
590
50
5.0
0.9
1.0
15
29
MAX
10
1.0
1.2
0.04
0.078
UNITS
μA
μA
V
V
Ω
Ω
S
pF
pF
pF
13
1.4
2.7
nC
nC
nC
ns
ns
ID=3.6A, RG=10Ω
VDD=10V, VGS=4.0V, ID=3.6A, RG=10Ω
R2 (11-December 2012)
