DMN100
N-CHANNEL ENHANCEMENT MODE MOSFET
Features
•
•
•
•
•
•
•
Extremely Low On-Resistance: 170mΩ @ V
GS
= 4.5V
High Drain Current: 1.1A
Ideal for Notebook Computer, Portable Phone, PCMCIA
Cards, and Battery Powered Circuits
ESD Protected Gate
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
Case: SC59
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish - Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
Terminal Connections: See Diagram
Weight: 0.014 grams (approximate)
Drain
SC59
D
Gate
Gate
Protection
Diode
Source
G
S
ESD PROTECTED
Top View
Equivalent Circuit
Top View
Ordering Information
(Note 3)
Part Number
DMN100-7-F
Notes:
Case
SC59
Packaging
3000/Tape & Reel
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. No purposely added lead. Halogen and Antimony free.
2. Diodes Inc.`s “Green” Policy can be found on our website at http://www.diodes.com.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
M11
M11 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: T = 2006)
M = Month (ex: 9 = September)
Date Code Key
Year
2006
Code
T
Month
Code
Jan
1
2007
U
Feb
2
2008
V
Mar
3
2009
W
Apr
4
YM
2010
X
May
5
2011
Y
Jun
6
2012
Z
Jul
7
2013
A
Aug
8
2014
B
Sep
9
2015
C
Oct
O
2016
D
Nov
N
2017
E
Dec
D
DMN100
Document number: DS30049 Rev. 9 - 2
1 of 4
www.diodes.com
March 2012
© Diodes Incorporated
DMN100
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Drain-Source Voltage
Gate-Source Voltage
Drain Current
Continuous
Continuous
Pulsed
Symbol
V
DSS
V
GSS
I
D
Value
30
±20
1.1
4.0
Units
V
V
A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Total Power Dissipation
Thermal Resistance, Junction to Ambient
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
500
250
-55 to +150
Units
mW
K/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
OFF CHARACTERISTICS (Note 4)
Drain-Source Breakdown Voltage
Zero Gate Voltage Drain Current
Gate-Body Leakage
ON CHARACTERISTICS (Note 4)
Gate Threshold Voltage
Static Drain-Source On-Resistance
Forward Transconductance
DYNAMIC CHARACTERISTICS
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Total Gate Charge
Gate-to-Source Charge
Gate-to-Drain Charge
SWITCHING CHARACTERISTICS
Turn-On Delay Time
Turn-Off Delay Time
Turn-On Rise Time
Turn-Off Fall Time
SOURCE-DRAIN RATINGS (BODY DIODE)
Continuous Source Current
Pulse Source Current
Forward Voltage
Reverse Recovery Time
Notes:
4. Pulse width
≤
300μs, duty cycle
≤
2%.
Symbol
BV
DSS
@ T
J
= 25°C
@ T
J
= 125°C
I
DSS
I
GSS
V
GS(th)
R
DS (ON)
g
FS
C
iss
C
oss
C
rss
Q
g
Q
gs
Q
gd
t
D(ON)
t
D(OFF)
t
r
t
f
I
S
I
SM
V
SD
t
rr
Min
30
—
—
1.0
—
1.3
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
—
2.4
150
90
30
5.5
0.8
1.3
10
25
15
45
—
—
—
35
Max
—
1.0
10
±
100
3.0
0.170
0.150
⎯
—
—
—
—
—
—
—
—
—
—
0.54
4.0
1.2
—
Unit
V
μA
nA
V
Ω
S
pF
pF
pF
nC
nC
nC
ns
ns
ns
ns
A
A
V
ns
Test Condition
V
GS
= 0V, I
D
= 250μA
V
DS
= 24V, V
GS
= 0V
V
GS
=
±
12V, V
DS
= 0V
V
DS
= 10V, I
D
= 1.0mA
V
GS
= 4.5V, I
D
= 0.5A
V
GS
= 10V, I
D
= 1.0A
V
DS
= 10V, I
D
= 0.5A
V
DS
= 10V, V
GS
= 0V
f = 1.0MHz
V
DS
= 24V, I
D
= 1.0A,
V
GS
= 10V
V
DD
= 10V, I
D
= 0.5A,
V
GS
= 5.0V, R
GEN
= 50Ω
—
—
I
F
= 1.0A, V
GS
= 0V
I
F
= 1.0A, di/dt = 50A/μs
DMN100
Document number: DS30049 Rev. 9 - 2
2 of 4
www.diodes.com
March 2012
© Diodes Incorporated
DMN100
4.0
1.0
R
DS(ON)
, NORMALIZED
DRAIN-SOURCE ON-RESISTANCE
3.5
I
D
, DRAIN CURRENT (A)
3.0
2.5
2.0
1.5
1.0
0.5
0
0
1
2
3
4
V
DS
, DRAIN-SOURCE VOLTAGE (V)
Fig. 1 On-Region Characteristics
5
V
GS
= 4.5V
0.1
V
GS
= 10V
0.01
0
1
3
2
I
D
, DRAIN CURRENT (A)
Fig. 2 On-Resistance vs. Drain Current
4
0.30
R
DS(ON)
, NORMALIZED
DRAIN-SOURCE ON-RESISTANCE
4.0
R
DS(ON)
, NORMALIZED
DRAIN-SOURCE ON-RESISTANCE
0
50
100
150
T
j
, JUNCTION TEMPERATURE (
°
C)
Fig. 3 On-Resistance vs. Junction Temperature
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
0
2
3
4
5
1
V
GS
, GATE TO SOURCE VOLTAGE (V)
Fig. 4 On-Resistance vs. Gate-Source Voltage
0.25
0.20
0.15
0.10
0.05
0
-50
Package Outline Dimensions
A
B C
G
H
K
M
N
J
D
L
SC59
Dim
Min
Max
Typ
A
0.35
0.50
0.38
B
1.50
1.70
1.60
C
2.70
3.00
2.80
D
-
-
0.95
G
-
-
1.90
H
2.90
3.10
3.00
J
0.013 0.10
0.05
K
1.00
1.30
1.10
L
0.35
0.55
0.40
M
0.10
0.20
0.15
N
0.70
0.80
0.75
0°
8°
-
α
All Dimensions in mm
DMN100
Document number: DS30049 Rev. 9 - 2
3 of 4
www.diodes.com
March 2012
© Diodes Incorporated
DMN100
Suggested Pad Layout
Y
Z
C
Dimensions Value (in mm)
Z
3.4
X
0.8
Y
1.0
C
2.4
E
1.35
X
E
