LD-520-120MG
•
Direct Emitting Green Laser Diode
Description
LD-520-120MG
is a direct emitting,
GaN based,
520nm green laser diode in TO56 package
without
photodiode.
It offers single transverse mode emission and >100 Mhz modulation bandwidth. It is an
efficient radiation source for many applications like
laser projection,
holography, metrology,
biomedical application…
Maximum Ratings
Parameter
Operating Current
Reverse Voltage
Operating Temperature
Storage Temperature
Soldering Temperature
Symbol
I
F
V
R
T
CASE
T
STG
T
SOLDER
+ 10
- 40
Values
Min.
Max.
480
2
+ 60
+ 85
260
Unit
mA
V
°C
°C
°C
Laser Characteristics
(T
Parameter
Emission Wavelength
Optical Output Power
Spectral Width
Treshold Current
Operating Current
Operating Voltage
Beam Divergence (FWHM)
Polarization
Modulation Frequency
CASE
=
25°C, P
O
= 50 mW)
Values
Typ.
520
120
2
140
340
6
4x18
20:1
>100
20
MHz
K/W
7x23
11x26
200
Symbol
λ
peak
P
O
∆λ
I
th
I
F
V
F
Ө
II
x Ө
┴
P
GR
f
R
th
Min.
515
Max.
530
Unit
nm
mW
nm
mA
mA
V
deg
Thermal Resistance (junction to case)
www.roithner-laser.com
-1-
12/05/14
Drawing
Dimensions in mm
Electrical Connection
Lead
Pin 1
Pin 2
Pin 3
Description
LD Anode
Case
LD Cathode
Mounting Instruction
In order to maintain lifetime and stability of the laser diode it is essential to provide efficient heat
management. Heat dissipation is possible through the base plate only. For long time stable operation
proper contact between laser diode base plate and heat sink is mandatory
Safety Advice
This laser diode emits highly concentrated visible light which can be
hazardous to the human eye.
This diode is classified as
Class 3B laser product
according to
IEC 60825-1.
Actual laser light
emitted and precautions necessary strongly depend on mode of operation.
