driver used to translate TTL control inputs into gate
voltages for GaAs FET microwave switches and
attenuators. High speed analog CMOS technology is
utilized to achieve low power dissipation at moderate
to high speeds, encompassing most microwave
switching applications.
Pin Configuration
Pin No.
1
2
3
Function
A3
B3
A4
B4
V
EE
V
CC
C4
C3
Pin No.
9
10
11
12
13
14
15
16
Function
C2
C1
GND
GND
A1
B1
A2
B2
Ordering Information
Part Number
MADRCC0004
MADRCC0004TR
Package
Bulk Packaging
1000 piece reel
4
5
6
7
8
Note: Reference Application Note M513 for reel size
information.
Guaranteed Operating Ranges
Symbol
V
CC
V
EE
T
A
I
OH
I
OL
T
rise
, T
fall
Parameter
1
Positive DC Supply Voltage
Negative DC Supply Voltage
Operating Ambient Temperature
DC Output Current - HIGH
DC Output Current - LOW
Maximum Input Rise or Fall Time
Unit
V
V
°C
mA
mA
nS
Min
4.5
-5.5
-40
—
—
—
Typical
5.0
-5.0
+25
—
—
—
Max
5.5
-4.5
+85
-1.0
1.0
500
1. All voltages are relative to GND.
1
* Restrictions on Hazardous Substances, European Union Directive 2002/95/EC.
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MADRCC0004
Quad Driver for GaAs FET Switches and Attenuators
Rev. V3
AC & DC Characteristics Over Guaranteed Operating Range
Symbol
V
IH
V
IL
V
OH
V
OL
I
IN
I
CC
I
CC
T
PHL,
T
PLH
T
THL,
T
TLH
Parameter
Input HIGH Voltage
Input LOW Voltage
Output HIGH Voltage
Output LOW Voltage
Input Current
Quiescent Supply Current
Additional Supply Current, per TTL
Input pin
Propagation Delay
Output Transition Time
Delay Skew, Output A to Output B
Test Conditions
Guaranteed HIGH Input Voltage
Guaranteed LOW Input Voltage
I
OH
= -1 mA
I
OL
= 1 mA
V
IN
= V
CC
or GND
V
CC
= Max
V
CC
= Max
V
EE
= Max
V
EE
= Max
V
EE
= Min
V
EE
= Min
V
IN
= V
CC
or GND
V
IN
= V
CC
- 2.1V
Units
V
V
V
V
µA
µA
mA
nS
nS
nS
Min
2.0
-
- 0.1
—
-10
—
—
—
—
—
Typ
—
—
—
—
0
—
—
—
—
—
Max
-
0.8
-
V
EE
+ 0.1
10
400
1.0
50
25
8
Guaranteed -40° C to + 85° C
Guaranteed -40° C to + 85° C
Guaranteed -40° C to + 85° C
Switching Waveforms
INPUT
C
V
IN
90%
1.3 V
10%
LOGIC 0
Absolute Maximum Ratings
2,3
Parameter
LOGIC 1
T
F
T
R
Absolute Maximum
- .5V to + 6.0 V
- 6.0 V to - .5 V
12 V
V
CC
+ .5 V
V
EE
- .5 V
-65°C to +150°C
-40°C to +85°C
V
CC
V
EE
T
PLH
OUTPUT A
V
OUT
50%
OUTPUT B
10%
90%
T
PHL
GND
V
CC
- V
EE
V
IN 4
V
OUT
Storage Temperature
T
TLH
T
THL
V
EE
Operating Temperature
2.
3.
4.
Note: See Switching Wave Forms for the definition of the
switching terms. Supplies must be by-passed with .01 µF
Capacitors.
Note: Unused inputs must be tied to Ground
Exceeding any one or combination of these limits may cause
permanent damage to this device.
M/A-COM does not recommend sustained operation near
these survivability limits.
Standard CMOS TTL interface, latch-up will occur if logic
signal is applied prior to power supply.
Handling Procedures
Please observe the following precautions to avoid
damage:
Truth Table
Input
C
X
0
1
A
X
V
EE
GND
Outputs
B
X
GND
V
EE
Static Sensitivity
Silicon Integrated Circuits are sensitive to
electrostatic discharge (ESD) and can be damaged
by static electricity. Proper ESD control techniques
should be used when handling these devices.
2
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MADRCC0004
Quad Driver for GaAs FET Switches and Attenuators
Rev. V3
Lead-Free,
SOIC-16
†
†
Reference Application Note M538 for lead-free solder reflow
recommendations.
3
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MADRCC0004
Quad Driver for GaAs FET Switches and Attenuators
Rev. V3
M/A-COM Technology Solutions Inc. All rights reserved.
Information in this document is provided in connection with M/A-COM Technology Solutions Inc ("MACOM")
products. These materials are provided by MACOM as a service to its customers and may be used for
informational purposes only. Except as provided in MACOM's Terms and Conditions of Sale for such products or
in any separate agreement related to this document, MACOM assumes no liability whatsoever. MACOM
assumes no responsibility for errors or omissions in these materials. MACOM may make changes to
specifications and product descriptions at any time, without notice. MACOM makes no commitment to update
the information and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future
changes to its specifications and product descriptions. No license, express or implied, by estoppels or otherwise,
to any intellectual property rights is granted by this document.
THESE MATERIALS ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, RELATING TO SALE AND/OR USE OF MACOM PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, CONSEQUENTIAL OR
INCIDENTAL DAMAGES, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR
OTHER INTELLECTUAL PROPERTY RIGHT. MACOM FURTHER DOES NOT WARRANT THE ACCURACY
OR COMPLETENESS OF THE INFORMATION, TEXT, GRAPHICS OR OTHER ITEMS CONTAINED WITHIN
THESE MATERIALS. MACOM SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR LOST PROFITS,
WHICH MAY RESULT FROM THE USE OF THESE MATERIALS.
MACOM products are not intended for use in medical, lifesaving or life sustaining applications. MACOM
customers using or selling MACOM products for use in such applications do so at their own risk and agree to
fully indemnify MACOM for any damages resulting from such improper use or sale.
4
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
