885062
2.4 GHz WLAN/BT LTE Co-Existence Filter
Applications
•
WiFi bandpass filter that enables the coexistence
of 3G/4G/LTE/TD-LTE & WiFi signals
•
High-power WLAN Access Points and Small Cells
•
Band-edge filtering of WiFi signal emissions
•
Smart Meters and 2.4GHz ISM Applications
•
Set Top Box, Gateways and WiFi Routers
CSP-5CT package: 1.4 x 1.2 x 0.46 mm
Product Features
•
Low Loss in WLAN band with extended upper
corner for inclusion of Bluetooth
•
High Rejection in B38/B40 bands
•
Industry leading small size: 1.4 x 1.2 x 0.46 mm
•
Performance over -40 to +95 ºC
•
Ceramic chip-scale Package (CSP)
•
Hermetically sealed
Pb
•
RoHS compliant, Pb-free
Functional Block Diagram
Top View
Gnd
5
Input
1
2
3
Gnd
Output
4
Gnd
General Description
The 885062 is a high-performance, high power Bulk
Acoustic Wave (BAW) band-pass filter with
extremely steep skirts, simultaneously exhibiting low
loss in the WiFi band and high band-edge & near-in
rejection.
The 885062 enables coexistence of WiFi and LTE
signals within the same device or in close proximity
to one another. Its unique power handling capability
allows for implementation into access points, small
cell base stations, and other high power ISM band
applications.
The 885062 uses common module packaging
techniques to achieve the industry standard 1.4 x
1.2 x 0.46 mm footprint. The filter exhibits excellent
power handling capabilities.
Pin Configuration
Pin No.
1
4
2,3,5
Label
Input
Output
Ground
Ordering Information
Part No.
885062
885062-EVB
Description
Packaged part
Evaluation board
Standard T/R size = 15,000 units/reel
Data Sheet: Rev G 02/10/15
© 2015 TriQuint
-
1 of 8
-
Disclaimer: Subject to change without notice
885062
2.4 GHz WLAN/BT LTE Co-Existence Filter
Absolute Maximum Ratings
Parameter
Storage Temperature
(2)
Operable Temperature
(1)
Rating
-55 to +125 °
C
-40 to +95 °
C
MTTF
Input Power
+ 28 dBm
(3)
+
70
°
C
+
85
°
C
+
95
°
C
> 14M hours > 5M hours > 2M hours
1. Operation of this device outside the parameter ranges given may cause permanent damage.
2. Specifications are not guaranteed over all operable conditions.
3. Input Power with WLAN OFDM signal applied.
Electrical Specifications
(1)
Conditions unless otherwise noted: Device Temperature = -30° to +85°
C
C.
Parameter
(2)
Insertion Loss
Conditions
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2481.5 MHz (WiFi Ch.1-13)
2401 – 2483 MHz
100 – 2300 MHz
(5)
2300 – 2365 MHz
(5)
2365 – 2370 MHz
(5)
2370 – 2375 MHz (+25 to +85˚C)
(5)
2370 – 2375 MHz (-30 to +25˚C)
(5)
2375 – 2380 MHz (+25 to +85˚C)
(5)
2375 – 2380 MHz (-30 to +25˚C)
(5)
2500 – 2505 MHz (+25 to +85˚C)
(5)
2500 – 2505 MHz (-30 to +25˚C)
(5)
2505 – 2570 MHz (+25 to +85˚C)
(5)
2505 – 2570 MHz (-30 to +25˚C)
(5)
2570 – 2620 MHz
(5)
2620 – 2690 MHz
4800 – 5000 MHz
7200 – 7500 MHz
CW Tone = 2442 MHz @ 22.5 dBm
CW Tone = 2442 MHz @ 22.5 dBm
Min
-
Typ (+25°
C)
1.7
1.5
1.5
1.6
1.7
0.8
0.8
0.9
0.4
0.6
1.9
160
37
53
58
61
61
49
49
41
41
55
55
48
46
43
40
60
138
Max
2.2
2.0
1.9
2.1
2.2
1.5
1.1
1.1
1.0
1.8
2.2
200
-
-
-
-
-
-
-
-
-
-
-
-
-
Units
dB
(3)
Amplitude Variation
-
dB
Input/Output VSWR
(4)
Impulse Response Length
Attenuation
2 Harmonics
rd
3 Harmonics
nd
-
-
35
48
54
45
56
25
34
29
20
49
38
45
44
38
36
-
-
-
ns
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBc
dBc
Notes:
1. In production, devices will be tested at room temperature to a guard-banded specification to ensure electrical compliance
over temperature.
2. Electrical margin has been built into the design to account for the variations due to temperature drift and manufacturing
tolerances.
3. Data is the integrated value of the linear s-parameter over the indicated band at the specified temperature.
4. Duration in ns between the maxima and the point 40 dB below the maxima.
5. Data is the integrated value of the linear s-parameter over 5 MHz range at the specified temperature.
6. An external impedance matching network with ±2 % tolerance will be necessary to achieve the stated specifications.
7. This is the optimum impedance in order to achieve the performance shown.
Data Sheet: Rev G 02/10/15
© 2015 TriQuint
-
2 of 8
-
Disclaimer: Subject to change without notice
885062
2.4 GHz WLAN/BT LTE Co-Existence Filter
Electrical Specifications
(1)
Conditions unless otherwise noted: Device Temperature = -40° to +95°
C
C.
Parameter
(2)
Insertion Loss
Conditions
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2481.5 MHz (WiFi Ch.1-13)
2401 – 2483 MHz
100 – 2300 MHz
(5)
2300 – 2365 MHz
(5)
2365 – 2370 MHz
(5)
2370 – 2375 MHz (+25 to +95˚C)
(5)
2370 – 2375 MHz (-40 to +25˚C)
(5)
2375 – 2380 MHz (+25 to +95˚C)
(5)
2375 – 2380 MHz (-40 to +25˚C)
(5)
2500 – 2505 MHz (+25 to +95˚C)
(5)
2500 – 2505 MHz (-40 to +25˚C)
(5)
2505 – 2570 MHz (+25 to +95˚C)
(5)
2505 – 2570 MHz (-40 to +25˚C)
(5)
2570 – 2620 MHz
(5)
2620 – 2690 MHz
4800 – 5000 MHz
7200 – 7500 MHz
CW Tone = 2442 MHz @ 22.5 dBm
CW Tone = 2442 MHz @ 22.5 dBm
Min
-
Typ (+25°
C)
1.7
1.5
1.5
1.6
1.7
0.8
0.8
0.9
0.4
0.6
1.9
160
37
53
58
61
61
49
49
41
41
55
55
48
46
43
40
60
138
Max
2.2
2.0
2.1
2.2
2.4
1.8
1.1
1.1
1.0
1.8
2.2
200
-
-
-
-
-
-
-
-
-
-
-
-
-
Units
dB
(3)
Amplitude Variation
-
dB
Input/Output VSWR
(4)
Impulse Response Length
Attenuation
2 Harmonics
rd
3 Harmonics
nd
-
-
35
48
54
43
56
23
34
29
18
49
35
45
44
38
36
-
-
-
ns
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBc
dBc
Notes:
1. In production, devices will be tested at room temperature to a guard-banded specification to ensure electrical compliance
over temperature.
2. Electrical margin has been built into the design to account for the variations due to temperature drift and manufacturing
tolerances.
3. Data is the integrated value of the linear s-parameter over the indicated band at the specified temperature.
4. Duration in ns between the maxima and the point 40 dB below the maxima.
5. Data is the integrated value of the linear s-parameter over 5 MHz range at the specified temperature.
6. An external impedance matching network with ±2 % tolerance will be necessary to achieve the stated specifications.
7. This is the optimum impedance in order to achieve the performance shown.
Data Sheet: Rev G 02/10/15
© 2015 TriQuint
-
3 of 8
-
Disclaimer: Subject to change without notice
885062
2.4 GHz WLAN/BT LTE Co-Existence Filter
Electrical Specifications
(1)
Conditions unless otherwise noted: Device Temperature = 0° to +70°
C
C.
Parameter
(2)
Insertion Loss
Conditions
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2421.5 MHz (WiFi Ch.1)
2407.5 – 2426.5 MHz (WiFi Ch.2)
2412.5 – 2471.5 MHz (WiFi Ch.3-11)
2457.5 – 2476.5 MHz (WiFi Ch.12)
2462.5 – 2481.5 MHz (WiFi Ch.13)
2402.5 – 2481.5 MHz (WiFi Ch.1-13)
2401 – 2483 MHz
100 – 2300 MHz
(5)
2300 – 2365 MHz
(5)
2365 – 2370 MHz
(5)
2370 – 2375 MHz (+25 to +70˚C)
(5)
2370 – 2375 MHz (0 to +25˚C)
(5)
2375 – 2380 MHz (+25 to +70˚C)
(5)
2375 – 2380 MHz (0 to +25˚C)
(5)
2500 – 2505 MHz (+25 to +70˚C)
(5)
2500 – 2505 MHz (0 to +25˚C)
(5)
2505 – 2570 MHz (+25 to +70˚C)
(5)
2505 – 2570 MHz (0 to +25˚C)
(5)
2570 – 2620 MHz
(5)
2620 – 2690 MHz
4800 – 5000 MHz
7200 – 7500 MHz
CW Tone = 2442 MHz @ 22.5 dBm
CW Tone = 2442 MHz @ 22.5 dBm
Min
-
Typ (+25°
C)
1.7
1.5
1.5
1.6
1.7
0.8
0.8
0.9
0.4
0.6
1.9
160
37
53
58
61
61
49
49
41
41
55
55
48
46
43
40
60
138
Max
2.2
2.0
1.9
2.1
2.2
1.5
1.1
1.1
1.0
1.6
2.2
200
-
-
-
-
-
-
-
-
-
-
-
-
-
Units
dB
(3)
Amplitude Variation
-
dB
Input/Output VSWR
(4)
Impulse Response Length
Attenuation
2 Harmonics
rd
3 Harmonics
Notes:
1.
2.
3.
4.
5.
6.
7.
nd
-
-
35
48
54
46
56
27
34
29
26
49
40
45
44
38
36
-
-
-
ns
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBc
dBc
In production, devices will be tested at room temperature to a guard-banded specification to ensure electrical
compliance over temperature.
Electrical margin has been built into the design to account for the variations due to temperature drift and manufacturing
tolerances.
Data is the integrated value of the linear s-parameter over the indicated band at the specified temperature.
Duration in ns between the maxima and the point 40 dB below the maxima.
Data is the integrated value of the linear s-parameter over 5 MHz range at the specified temperature.
An external impedance matching network with ±2 % tolerance will be necessary to achieve the stated specifications.
This is the optimum impedance in order to achieve the performance shown.
Data Sheet: Rev G 02/10/15
© 2015 TriQuint
-
4 of 8
-
Disclaimer: Subject to change without notice
885062
2.4 GHz WLAN/BT LTE Co-Existence Filter
Evaluation Board
Notes:
1. Matching component values shown are for the specified TriQuint evaluation board. Value adjustment may be required in
end user product circuits depending on component manufacturer and PCB material.
2. PCB: .500 x.500 x .062; Construction: ½ oz
Cu
Top Layer;
TLY-5A
(.0075) ½ oz
Cu
Middle Layer,
FR4;
½ oz
Cu
Bottom
Layer. (dimensions are in inches)
Bill of Material
Reference Des.
L1
L2
SMA
PCB
Value
9.1 nH
6.8 nH
N/A
N/A
Description
Chip Inductor, 0201, +/- 2 %
Chip Inductor, 0201, +/- 2 %
SMA connector
3-layer
Manuf.
Murata
Murata
Radiall USA
Multiple
Part Number
LQP03TN9N1J02
LQP03TN6N8J02
9602-1111-018
960999
Data Sheet: Rev G 02/10/15
© 2015 TriQuint
-
5 of 8
-
Disclaimer: Subject to change without notice
