ASPC70
Power Shielded Inductors
Inches
(mm)
Dimensions:
0.725 Max
(18.42)
22 AWG/TCW
100K
0.300 Max
(7.62)
1.15 Nominal
(29.21)
Features
• Magnetically Shielded
• Epoxy End Caps for added Lead
Strength and Protection
Allied
Part
Number
L
(µh)
DCR
(Ω)
±20%
Rated
Current
(AC Amps)
Allied
Part
Number
L
(mh)
DCR
(Ω)
±20%
Rated
Current
(AC Amps)
Electrical
Inductance Range:
1.0µh ~ 4700µh
Tolerance:
10% across entire range
Tighter tolerances available
Test Frequency:
1KHz
Operating Temp:
-55ºC ~ +125ºC
Current Rating:
Based on a .33 watt power
dissipation for approximately 20ºC Temp Rise
Test Equipment
Inducatance
/
Q:
HP4342A
Current:
CH301 Current Source and DCR Meter
DCR:
CH301 Current Source and DCR Meter
SRF:
HP4191A / HP4291A
Physical
Packaging:
Bulk 100 per Bag
Marking:
EIA Inductance Code
ASPC70-1R0K-RC
ASPC70-1R2K-RC
ASPC70-1R5K-RC
ASPC70-1R8K-RC
ASPC70-2R2K-RC
ASPC70-2R7K-RC
ASPC70-3R3K-RC
ASPC70-3R9K-RC
ASPC70-4R7K-RC
ASPC70-5R6K-RC
ASPC70-6R8K-RC
ASPC70-8R2K-RC
ASPC70-100K-RC
ASPC70-120K-RC
ASPC70-150K-RC
ASPC70-180K-RC
ASPC70-220K-RC
ASPC70-270K-RC
ASPC70-330K-RC
ASPC70-390K-RC
ASPC70-470K-RC
ASPC70-560K-RC
ASPC70-680K-RC
ASPC70-820K-RC
ASPC70-101K-RC
ASPC70-121K-RC
ASPC70-151K-RC
ASPC70-181K-RC
ASPC70-221K-RC
ASPC70-271K-RC
ASPC70-331K-RC
ASPC70-391K-RC
ASPC70-471K-RC
ASPC70-561K-RC
ASPC70-681K-RC
ASPC70-821K-RC
ASPC70-102K-RC
ASPC70-122K-RC
ASPC70-152K-RC
ASPC70-182K-RC
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
0.011
0.012
0.012
0.012
0.012
0.013
0.013
0.014
0.014
0.017
0.018
0.018
0.020
0.022
0.024
0.030
0.032
0.034
0.036
0.038
0.040
0.046
0.047
0.050
0.064
0.068
0.073
0.078
0.082
0.098
0.132
0.142
0.170
0.222
0.235
0.247
0.440
0.470
0.640
0.700
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.707
0.556
0.556
0.556
0.437
0.437
0.437
0.350
0.280
0.277
0.277
ASPC70-222K-RC
ASPC70-272K-RC
ASPC70-332K-RC
ASPC70-392K-RC
ASPC70-472K-RC
ASPC70-562K-RC
ASPC70-682K-RC
ASPC70-822K-RC
ASPC70-103K-RC
ASPC70-123K-RC
ASPC70-153K-RC
ASPC70-183K-RC
ASPC70-223K-RC
ASPC70-273K-RC
ASPC70-333K-RC
ASPC70-393K-RC
ASPC70-473K-RC
ASPC70-563K-RC
ASPC70-683K-RC
ASPC70-823K-RC
ASPC70-104K-RC
ASPC70-124K-RC
ASPC70-154K-RC
ASPC70-184K-RC
ASPC70-224K-RC
ASPC70-274K-RC
ASPC70-334K-RC
ASPC70-394K-RC
ASPC70-474K-RC
ASPC70-564K-RC
ASPC70-684K-RC
ASPC70-824K-RC
ASPC70-105K-RC
ASPC70-125K-RC
ASPC70-155K-RC
ASPC70-185K-RC
ASPC70-225K-RC
ASPC70-275K-RC
ASPC70-335K-RC
ASPC70-395K-RC
ASPC70-475K-RC
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
0.925
1.02
1.16
1.61
1.89
2.42
2.67
3.19
4.16
4.32
4.96
5.28
8.06
9.12
12.18
14.66
17.18
18.71
27.36
31.32
42.84
47.16
61.58
69.12
90
100
117
125
183
206
282
356
410
568
634
950
964
987
1400
1682
1700
0.224
0.224
0.224
0.175
0.175
0.130
0.130
0.110
0.110
0.080
0.080
0.071
0.071
0.056
0.056
0.043
0.043
0.043
0.043
0.043
0.034
0.034
0.027
0.034
0.027
0.027
0.022
0.022
0.017
0.017
0.014
0.011
0.011
0.0086
0.0086
0.0069
0.0069
0.0054
0.0054
0.0054
0.0054
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 12/15/10
www.alliedcomponents.com
