ZLED7012
Low-Voltage Four-Channel LED Driver
Block Diagram
Typical Applications
LED backlighting for portable devices
LED lighting for cell phones, smartphones. PDAs
Illumination of digital photo frames
Backlighting for GPS / navigation systems
Low voltage LED lighting fixtures
General purpose low-voltage industrial and consumer applications
Ordering Information
Product Sales Code
ZLED7012-ZI1R
ZLED7012KIT-E1
Description
ZLED7012 – Low-Voltage Four-Channel LED Driver
ZLED7012 Evaluation Board
Kit
Package
UTQFN12 (2x2)mm Tape & Reel
